— 89 —
* A-4398-122-A DISPLAY BOARD, COMPLETE (DE815G:US,CND)
**************************************
* A-4398-137-A DISPLAY BOARD, COMPLETE (E,PX)
*******************************
* A-4398-143-A DISPLAY BOARD, COMPLETE (SP,MY)
********************************
* A-4398-148-A DISPLAY BOARD, COMPLETE (AUS)
******************************
* A-4398-153-A DISPLAY BOARD, COMPLETE (D760Z)
********************************
* 4-921-941-01 CUSHION (FL)
* 4-981-656-01 HOLDER (C), FL INDICATION TUBE
< CAPACITOR >
C101 1-164-159-11 CERAMIC 0.1uF 50V
C102 1-164-159-11 CERAMIC 0.1uF 50V
C103 1-164-159-11 CERAMIC 0.1uF 50V
C104 1-164-159-11 CERAMIC 0.1uF 50V
C105 1-164-159-11 CERAMIC 0.1uF 50V
C106 1-164-159-11 CERAMIC 0.1uF 50V
C107 1-164-159-11 CERAMIC 0.1uF 50V
C108 1-126-796-11 ELECT 22uF 20% 35V
C109 1-162-282-31 CERAMIC 100PF 10% 50V
C110 1-126-786-11 ELECT 47uF 20% 16V
C111 1-126-786-11 ELECT 47uF 20% 16V
C112 1-162-282-31 CERAMIC 100PF 10% 50V
C113 1-126-786-11 ELECT 47uF 20% 16V
C114 1-164-159-11 CERAMIC 0.1uF 50V
C115 1-104-905-11 CAPACITOR 0.22F 5.5V
C116 1-164-159-11 CERAMIC 0.1uF 50V
C117 1-164-159-11 CERAMIC 0.1uF 50V
C132 1-126-177-11 ELECT 100uF 20% 10V
C133 1-164-159-11 CERAMIC 0.1uF 50V
C134 1-162-282-31 CERAMIC 100PF 10% 50V
C135 1-126-795-11 ELECT 10uF 20% 50V
C140 1-126-786-11 ELECT 47uF 20% 16V
C141 1-164-159-11 CERAMIC 0.1uF 50V
C142 1-164-159-11 CERAMIC 0.1uF 50V
C143 1-162-294-31 CERAMIC 0.001uF 10% 50V
< CONNECTOR >
CNP101 1-779-365-11 CONNECTOR, PC BOARD (PLUG) 8P
CNP103 1-779-366-11 CONNECTOR, BOARD TO BOARD 4P
CNS102 1-770-397-11 HOUSING, CONNECTOR(PC BOARD)4P
CNS104 1-569-308-11 SOCKET, CONNECTOR (L TYRE) 19P
CNS105 1-691-650-11 SOCKET, CONNECTOR 19P
CNS107 1-568-438-11 SOCKET, CONNECTOR 17P
< DIODE >
D100 8-719-987-63 DIODE IN4148M
D101 8-719-313-45 DIODE SEL6810A-TH10 (PHONO)
D102 8-719-313-45 DIODE SEL6810A-TH10 (TUNER)
D103 8-719-313-45 DIODE SEL6810A-TH10 (CD)
D104 8-719-313-45 DIODE SEL6810A-TH10 (DAT/MD)
D105 8-719-313-45 DIODE SEL6810A-TH10 (TAPE)
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
DISPLAY
BALANCE
AUDIO SW
< CONNECTOR >
CNP410 1-750-180-11 PIN, CONNECTOR (PC BOARD) 5P
CNS403 1-695-093-11 SOCKET, CONNECTOR 9P
CNS404 1-695-094-11 SOCKET, CONNECTOR 11P
< IC >
IC405 8-759-634-50 IC M5218AL
IC406 8-759-805-15 IC LC7823
< TRANSISTOR >
Q401 8-729-922-37 TRANSISTOR 2SD2144S
Q403 8-729-922-37 TRANSISTOR 2SD2144S
Q451 8-729-922-37 TRANSISTOR 2SD2144S
< RESISTOR >
R410 1-247-887-00 CARBON 220K 5% 1/4W
R411 1-249-417-11 CARBON 1K 5% 1/4W F
R412 1-249-425-11 CARBON 4.7K 5% 1/4W F
R413 1-249-441-11 CARBON 100K 5% 1/4W
R416 1-249-441-11 CARBON 100K 5% 1/4W
R417 1-249-417-11 CARBON 1K 5% 1/4W F
R418 1-249-425-11 CARBON 4.7K 5% 1/4W F
R460 1-247-887-00 CARBON 220K 5% 1/4W
R461 1-249-417-11 CARBON 1K 5% 1/4W F
R462 1-249-425-11 CARBON 4.7K 5% 1/4W F
R463 1-249-441-11 CARBON 100K 5% 1/4W
R466 1-249-441-11 CARBON 100K 5% 1/4W
R467 1-249-417-11 CARBON 1K 5% 1/4W F
R468 1-249-417-11 CARBON 1K 5% 1/4W F
R469 1-249-441-11 CARBON 100K 5% 1/4W
R476 1-249-425-11 CARBON 4.7K 5% 1/4W F
R477 1-249-417-11 CARBON 1K 5% 1/4W F
R478 1-249-441-11 CARBON 100K 5% 1/4W
R479 1-249-429-11 CARBON 10K 5% 1/4W
R480 1-249-441-11 CARBON 100K 5% 1/4W
R481 1-247-807-31 CARBON 100 5% 1/4W
R482 1-247-807-31 CARBON 100 5% 1/4W
**************************************************************
* 1-665-624-11 BALANCE BOARD
**************
< VARIABLE RESISTOR >
RV402 1-225-447-11 RES, VAR, CARBON 100K/100K (BALANCE)
**************************************************************
