Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< IC >
IC901 8-759-333-83 IC NJM2103D
< TRANSISTOR >
Q901 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q902 8-729-209-15 TRANSISTOR 2SD2012
< RESISTOR >
! R901 1-202-725-00 SOLID 3.3M 10% 1/2W
(US,CND)
R902 1-249-429-11 CARBON 10K 5% 1/4W
R903 1-249-425-11 CARBON 4.7K 5% 1/4W F
R904 1-249-417-11 CARBON 1K 5% 1/4W F
R905 1-249-428-11 CARBON 8.2K 5% 1/4W F
R906 1-249-421-11 CARBON 2.2K 5% 1/4W F
R908 1-249-433-11 CARBON 22K 5% 1/4W
R909 1-249-439-11 CARBON 68K 5% 1/4W
R910 1-249-437-11 CARBON 47K 5% 1/4W
R912 1-249-430-11 CARBON 12K 5% 1/4W
< RELAY >
! RY901 1-515-999-11 RELAY, POWER
< TRANSFORMER >
! T902 1-429-236-11 TRANSFORMER, POWER (EXCEPT US,CND)
! T902 1-431-477-11 TRANSFORMER, POWER (US,CND)
**************************************************************
* A-4398-109-A SURR BOARD, COMPLETE (US,CND)
******************************
* A-4398-136-A SURR BOARD, COMPLETE (E,PX)
****************************
* A-4398-141-A SURR BOARD, COMPLETE (SP,MY)
*****************************
* A-4398-147-A SURR BOARD, COMPLETE (AUS)
***************************
< CAPACITOR >
C301 1-126-963-11 ELECT 4.7uF 20% 50V
C302 1-162-282-31 CERAMIC 100PF 10% 50V
C303 1-126-967-11 ELECT 47uF 20% 16V
C304 1-130-480-00 MYLAR 0.0056uF 5% 50V
C305 1-106-347-00 MYLAR 1500PF 5% 200V
C306 1-126-960-11 ELECT 1uF 20% 50V
C307 1-164-159-11 CERAMIC 0.1uF 50V
C351 1-126-963-11 ELECT 4.7uF 20% 50V
C352 1-162-282-31 CERAMIC 100PF 10% 50V
C353 1-126-967-11 ELECT 47uF 20% 16V
C354 1-130-480-00 MYLAR 0.0056uF 5% 50V
C355 1-106-347-00 MYLAR 1500PF 5% 200V
C356 1-126-960-11 ELECT 1uF 20% 50V
C357 1-164-159-11 CERAMIC 0.1uF 50V
C394 1-126-967-11 ELECT 47uF 20% 16V
C395 1-126-967-11 ELECT 47uF 20% 16V
C396 1-162-282-31 CERAMIC 100PF 10% 50V
C397 1-162-294-31 CERAMIC 0.001uF 10% 50V
C401 1-126-964-11 ELECT 10uF 20% 50V
C402 1-126-964-11 ELECT 10uF 20% 50V
C403 1-126-964-11 ELECT 10uF 20% 50V
C404 1-162-199-31 CERAMIC 10PF 5% 50V
C405 1-162-199-31 CERAMIC 10PF 5% 50V
C406 1-126-964-11 ELECT 10uF 20% 50V
C410 1-164-159-11 CERAMIC 0.1uF 50V
C413 1-126-964-11 ELECT 10uF 20% 50V
C420 1-136-165-00 FILM 0.1uF 5% 50V
C421 1-126-933-11 ELECT 100uF 20% 16V
C422 1-164-159-11 CERAMIC 0.1uF 50V
C423 1-126-933-11 ELECT 100uF 20% 16V
C424 1-164-159-11 CERAMIC 0.1uF 50V
C425 1-126-965-11 ELECT 22uF 20% 50V
C426 1-136-177-00 FILM 1uF 5% 50V
C427 1-136-153-00 FILM 0.01uF 5% 50V
C428 1-130-474-00 MYLAR 0.0018uF 5% 50V
C429 1-136-163-00 FILM 0.068uF 5% 50V
C430 1-136-165-00 FILM 0.1uF 5% 50V
C431 1-136-165-00 FILM 0.1uF 5% 50V
C432 1-136-163-00 FILM 0.068uF 5% 50V
C433 1-136-153-00 FILM 0.01uF 5% 50V
C434 1-130-474-00 MYLAR 0.0018uF 5% 50V
C435 1-136-165-00 FILM 0.1uF 5% 50V
C436 1-136-165-00 FILM 0.1uF 5% 50V
C437 1-130-467-00 MYLAR 470PF 5% 50V
C438 1-136-165-00 FILM 0.1uF 5% 50V
C439 1-130-470-00 MYLAR 820PF 5% 50V
C440 1-130-480-00 MYLAR 0.0056uF 5% 50V
C441 1-136-161-00 FILM 0.047uF 5% 50V
C442 1-136-175-00 FILM 0.68uF 5% 50V
C443 1-136-169-00 FILM 0.22uF 5% 50V
C444 1-136-169-00 FILM 0.22uF 5% 50V
C445 1-126-963-11 ELECT 4.7uF 20% 50V
C446 1-126-963-11 ELECT 4.7uF 20% 50V
C447 1-136-169-00 FILM 0.22uF 5% 50V
C448 1-136-169-00 FILM 0.22uF 5% 50V
C449 1-136-165-00 FILM 0.1uF 5% 50V
C450 1-136-161-00 FILM 0.047uF 5% 50V
C451 1-126-964-11 ELECT 10uF 20% 50V
C452 1-126-964-11 ELECT 10uF 20% 50V
C453 1-126-964-11 ELECT 10uF 20% 50V
C454 1-162-199-31 CERAMIC 10PF 5% 50V
C455 1-162-199-31 CERAMIC 10PF 5% 50V
C456 1-126-964-11 ELECT 10uF 20% 50V
C460 1-164-159-11 CERAMIC 0.1uF 50V
C463 1-126-964-11 ELECT 10uF 20% 50V
C469 1-126-963-11 ELECT 4.7uF 20% 50V
C470 1-136-161-00 FILM 0.047uF 5% 50V
C471 1-136-165-00 FILM 0.1uF 5% 50V
C472 1-136-165-00 FILM 0.1uF 5% 50V
C473 1-136-157-00 FILM 0.022uF 5% 50V
C474 1-136-157-00 FILM 0.022uF 5% 50V
C475 1-136-165-00 FILM 0.1uF 5% 50V
C476 1-130-469-00 MYLAR 680PF 5% 50V
C477 1-126-967-11 ELECT 47uF 20% 16V
C478 1-136-165-00 FILM 0.1uF 5% 50V
STAND BY
SURR
Les composants identifiés par
une marque ! sont critiques pour
la sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
