Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R536 1-247-897-11 CARBON 560K 5% 1/4W
R537 1-249-417-11 CARBON 1K 5% 1/4W F
R551 1-249-417-11 CARBON 1K 5% 1/4W F
R552 1-249-439-11 CARBON 68K 5% 1/4W
R553 1-249-439-11 CARBON 68K 5% 1/4W
R554 1-247-820-11 CARBON 360 5% 1/4W
(SP,MY)
R554 1-249-411-11 CARBON 330 5% 1/4W
(EXCEPT SP,MY)
R555 1-249-419-11 CARBON 1.5K 5% 1/4W F
! R556 1-249-393-11 CARBON 10 5% 1/4W F
! R557 1-249-393-11 CARBON 10 5% 1/4W F
R558 1-249-436-11 CARBON 39K 5% 1/4W
R559 1-247-903-00 CARBON 1M 5% 1/4W
R560 1-249-425-11 CARBON 4.7K 5% 1/4W F
R561 1-249-434-11 CARBON 27K 5% 1/4W
R563 1-249-426-11 CARBON 5.6K 5% 1/4W
R564 1-249-418-11 CARBON 1.2K 5% 1/4W F
R565 1-249-441-11 CARBON 100K 5% 1/4W
R566 1-247-843-11 CARBON 3.3K 5% 1/4W
R567 1-247-883-00 CARBON 150K 5% 1/4W
R568 1-249-427-11 CARBON 6.8K 5% 1/4W F
R569 1-249-413-11 CARBON 470 5% 1/4W F
R591 1-247-897-11 CARBON 560K 5% 1/4W
R592 1-249-425-11 CARBON 4.7K 5% 1/4W F
R593 1-249-435-11 CARBON 33K 5% 1/4W
R594 1-249-425-11 CARBON 4.7K 5% 1/4W F
R595 1-247-903-00 CARBON 1M 5% 1/4W
R596 1-249-419-11 CARBON 1.5K 5% 1/4W F
R599 1-249-425-11 CARBON 4.7K 5% 1/4W F
R601 1-249-417-11 CARBON 1K 5% 1/4W F
R602 1-249-439-11 CARBON 68K 5% 1/4W
R603 1-247-820-11 CARBON 360 5% 1/4W
(SP,MY)
R603 1-249-411-11 CARBON 330 5% 1/4W
(EXCEPT SP,MY)
R604 1-249-439-11 CARBON 68K 5% 1/4W
R605 1-249-413-11 CARBON 470 5% 1/4W F
< RELAY >
RY401 1-515-614-11 RELAY
< TERMINAL >
TM401 1-694-265-11 TERMINAL BOARD, ANT (ANTTENA)
(US,CND,E,PX)
TM401 1-694-266-11 TERMINAL BOARD, ANT (ANTENNA)(SP,MY,AUS)
< TUNER >
TU401 1-233-592-11 ENCAPSULATED COMPONENT (US,CND)
TU401 1-233-654-11 ENCAPSULATED COMPONENT (E,PX,SP,MY)
TU401 1-693-377-11 TUNER (AUS)
< VIBRATOR >
X401 1-567-819-11 VIBRATOR, CERAMIC (4MHz)
**************************************************************
* 1-665-500-11 SURR-AUDIO BOARD
*****************
< CONNECTOR >
CNP302 1-695-088-11 PIN, CONNECTOR (PC BOARD) 9P
CNS303 1-695-093-11 SOCKET, CONNECTOR 9P
**************************************************************
* 1-665-469-11 SW BOARD
*********
< CONNECTOR >
CNS103 1-770-397-11 HOUSING, CONNECTOR(PC BOARD)4P
< RESISTOR >
R169 1-249-411-11 CARBON 330 5% 1/4W
R170 1-249-413-11 CARBON 470 5% 1/4W F
R171 1-249-415-11 CARBON 680 5% 1/4W F
R172 1-249-417-11 CARBON 1K 5% 1/4W F
R173 1-249-419-11 CARBON 1.5K 5% 1/4W F
R174 1-249-421-11 CARBON 2.2K 5% 1/4W F
R175 1-249-425-11 CARBON 4.7K 5% 1/4W F
R176 1-249-411-11 CARBON 330 5% 1/4W
R177 1-249-413-11 CARBON 470 5% 1/4W F
R178 1-249-415-11 CARBON 680 5% 1/4W F
R179 1-249-417-11 CARBON 1K 5% 1/4W F
R180 1-249-419-11 CARBON 1.5K 5% 1/4W F
R181 1-249-421-11 CARBON 2.2K 5% 1/4W F
R182 1-249-411-11 CARBON 330 5% 1/4W
R183 1-249-413-11 CARBON 470 5% 1/4W F
R184 1-249-415-11 CARBON 680 5% 1/4W F
R185 1-249-417-11 CARBON 1K 5% 1/4W F
R186 1-249-419-11 CARBON 1.5K 5% 1/4W F
R187 1-249-421-11 CARBON 2.2K 5% 1/4W F
< SWITCH >
S105 1-762-751-11 SWITCH, TACTILE (DIRECT PASS)
S106 1-762-751-11 SWITCH, TACTILE (GENRE)
S107 1-762-751-11 SWITCH, TACTILE (SET UP)
S108 1-762-751-11 SWITCH, TACTILE (MODE)
S113 1-762-751-11 SWITCH, TACTILE (AUDIO FUNCTION <)
S114 1-762-751-11 SWITCH, TACTILE (SOUND FIELD ON/OFF)
S115 1-762-751-11 SWITCH, TACTILE (AUDIO FUNCTION >)
S120 1-762-751-11 SWITCH, TACTILE (VIDEO FUNCTION <)
S121 1-762-751-11 SWITCH, TACTILE (5.1 INPUT)
S122 1-762-751-11 SWITCH, TACTILE (VIDEO FUNCTION >)
**************************************************************
* 1-665-502-11 VIDEO 3 BOARD
*************
< CAPACITOR >
C299 1-164-159-11 CERAMIC 0.1uF 50V
< JACK >
J299 1-779-868-11 JACK, PIN 3P (VIDEO 3 INPUT)
