— 102 —
Sony Corporation
Home A&V Products Company
Ref. No. Part No. Description Remark
< RESISTOR >
R299 1-249-403-11 CARBON 68 5% 1/4W F
R316 1-249-417-11 CARBON 1K 5% 1/4W F
R366 1-249-417-11 CARBON 1K 5% 1/4W F
**************************************************************
* 1-665-628-11 VOL SEL BOARD (E,PX)
********************
< CONNECTOR >
CNP910 1-564-321-00 PIN, CONNECTOR 2P
* CNP911 1-564-687-11 PIN, CONNECTOR 3P
* CNP912 1-564-687-11 PIN, CONNECTOR 3P
< SWITCH >
! S902 1-571-437-11 SWITCH, POWER VOLTAGE CHANGE
(VOLTAGE SELECTOR)
**************************************************************
* 1-665-623-11 VOLUME BOARD
************
< CAPACITOR >
C497 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
CNP102 1-770-388-11 PIN, CONNECTOR (PC BOARD) 4P
CNS402 1-569-323-11 SOCKET, CONNECTOR 19P
CNS410 1-750-179-11 SOCKET, CONNECTOR 5P
< RESISTOR >
R499 1-249-411-11 CARBON 330 5% 1/4W
< VARIABLE RESISTOR >
RV401 1-225-445-11 RES, VAR, CARBON 100KX6 (MASTER VOLUME)
**************************************************************
MISCELLANEOUS
*************
! 7 1-569-008-11 ADAPTOR, CONVERSION 2P (E,PX)
72 1-773-041-11 WIRE (FLAT TYPE) (17 CORE)
73 1-773-108-11 WIRE (FLAT TYPE) (19 CORE)(10cm)
74 1-773-117-11 WIRE (FLAT TYPE) (19 CORE)(18cm)
75 1-773-131-11 WIRE (FLAT TYPE) (19 CORE)(33cm)
107 1-773-280-11 WIRE (FLAT TYPE) (29 CORE)
! CNJ909 1-251-416-11 OUTLET, A.C. (AUS)
! CNJ909 1-526-794-11 OUTLET, AC (SP,MY)
! CNP901 1-696-847-11 CORD, POWER (AUS)
! CNP901 1-769-743-11 CORD, POWER (US,CND)
! CNP901 1-769-744-11 CORD, POWER (E,PX,SP,MY)
! F901 1-532-504-51 FUSE TIME-LAG (T4.6AL/250V)(EXCEPT US,CND)
! F901 1-533-311-11 FUSE (8A/125V)(US,CND)
! F902 1-532-464-51 FUSE TIME-LAG (T2.5AL/250V)(SP,MY,AUS)
! F903 1-532-504-51 FUSE TIME-LAG (T4.0AL/250V)(E,PX)
! F950 1-532-506-51 FUSE, TIME-LAG (T6.3AL/250V)
(EXCEPT US,CND)
STR-D760Z/DE815G
! F950 1-533-311-11 FUSE (8A/125V) (US,CND)
! F951 1-532-506-51 FUSE, TIME-LAG (T6.3AL/250V)
(EXCEPT US,CND)
! F951 1-533-311-11 FUSE (8A/125V) (US,CND)
FL101 1-517-519-11 INDICATOR TUBE, FLUORESCENT
Q505 8-729-209-15 TRANSISTOR 2SD2012
Q506 8-749-010-25 IC MN2488-OPY-M
Q507 8-749-010-26 IC MP1620-OPY-M
Q555 8-729-209-15 TRANSISTOR 2SD2012
Q556 8-749-010-25 IC MN2488-OPY-M
Q557 8-749-010-26 IC MP1620-OPY-M
Q605 8-729-209-15 TRANSISTOR 2SD2012
Q606 8-749-010-25 IC MN2488-OPY-M
Q607 8-749-010-26 IC MP1620-OPY-M
Q706 8-749-010-25 IC MN2488-OPY-M
Q707 8-749-010-26 IC MP1620-OPY-M
Q756 8-749-010-25 IC MN2488-OPY-M
Q757 8-749-010-26 IC MP1620-OPY-M
! T901 1-431-314-11 TRANSFORMER, POWER (US)
! T901 1-431-315-11 TRANSFORMER, POWER (CND)
! T901 1-431-316-11 TRANSFORMER, POWER (AUS)
! T901 1-431-317-11 TRANSFORMER, POWER (E,PX)
! T901 1-431-318-11 TRANSFORMER, POWER (SP,MY)
**************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
1-475-133-11 REMOTE COMMANDER (RM-H501)(US,CND)
1-475-138-11 REMOTE COMMANDER (RM-VR101)
(E,PX,SP,MY,AUS)
1-475-324-11 RAY-CATCHER UNIT (WITH PLUG)
1-501-594-11 ANTENNA (FM)(DE815G:SP,MY,AUS)
1-501-721-11 ANTENNA (LOOP)
1-751-619-11 CORD, CONNECTION (VIDEO 1.5m)
(D760Z/DE815G:US,CND)
1-777-172-11 CORD, CONNECTION (CONTROL A1 1m)
(DE815G:US,CND)
3-810-765-11 MANUAL,COMMONNESS INSTRUCTION
(ENGLISH)(US,AUS)
3-810-765-21 MANUAL,COMMONNESS INSTRUCTION
(ENGLISH,FRENCH,GERMAN,SPANISH,DUTCH,
SWEDISH,ITALIAN,PORTUGUESE,CHINESE)
(CND,E,PX,SP,MY)
4-983-536-01 COVER, BATTERY (For RM-H501)
4-995-439-01 COVER, BATTERY (For RM-VR101)
**************************************************************
*************
HARDWARE LIST
*************
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 TT(B)
#2 7-685-881-09 SCREW +BVTT 4X8 (S)
#3 7-685-872-09 SCREW +BVTT 3X8 (S)
Ref. No. Part No. Description Remark
9-960-979-11
97F0943-1
Printed in Japan © 1997. 6
Published by General Engineering Dept.
(Shibaura)
VIDEO 3 VOLUMEVOL SEL
Les composants identifiés par
une marque ! sont critiques pour
la sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
