— 91 —
R162 1-249-429-11 CARBON 10K 5% 1/4W
R163 1-249-401-11 CARBON 47 5% 1/4W F
R164 1-249-429-11 CARBON 10K 5% 1/4W
R165 1-249-429-11 CARBON 10K 5% 1/4W
R166 1-249-429-11 CARBON 10K 5% 1/4W
R167 1-249-441-11 CARBON 100K 5% 1/4W F
R188 1-249-411-11 CARBON 330 5% 1/4W
R189 1-249-413-11 CARBON 470 5% 1/4W F
R190 1-249-415-11 CARBON 680 5% 1/4W F
R191 1-249-417-11 CARBON 1K 5% 1/4W F
R192 1-249-419-11 CARBON 1.5K 5% 1/4W F
R193 1-249-421-11 CARBON 2.2K 5% 1/4W F
R194 1-249-425-11 CARBON 4.7K 5% 1/4W F
R195 1-249-411-11 CARBON 330 5% 1/4W
R196 1-249-413-11 CARBON 470 5% 1/4W F
R197 1-249-415-11 CARBON 680 5% 1/4W F
R198 1-249-417-11 CARBON 1K 5% 1/4W F
R199 1-249-419-11 CARBON 1.5K 5% 1/4W F
RR10 1-249-425-11 CARBON 4.7K 5% 1/4W F
(EXCEPT E,PX)
RR11 1-249-411-11 CARBON 330 5% 1/4W
RR12 1-249-413-11 CARBON 470 5% 1/4W F
RR13 1-249-415-11 CARBON 680 5% 1/4W F
(EXCEPT US,CND)
RR14 1-249-417-11 CARBON 1K 5% 1/4W F
(EXCEPT US,CND)
RR15 1-249-419-11 CARBON 1.5K 5% 1/4W F
(EXCEPT US,CND)
RR16 1-249-421-11 CARBON 2.2K 5% 1/4W F
(EXCEPT US,CND)
RR17 1-249-425-11 CARBON 4.7K 5% 1/4W F
(SP,MY,AUS)
RR18 1-249-429-11 CARBON 10K 5% 1/4W
(AUS)
< SWITCH >
S123 1-762-751-11 SWITCH, TACTILE (<)
S124 1-762-751-11 SWITCH, TACTILE (>)
S125 1-762-751-11 SWITCH, TACTILE (DISPLAY)
S126 1-762-751-11 SWITCH, TACTILE (FM MODE)
S127 1-762-751-11 SWITCH, TACTILE (FM/AM)
S128 1-762-751-11 SWITCH, TACTILE (SHIFT)
S129 1-762-751-11 SWITCH, TACTILE (∧)
S130 1-762-751-11 SWITCH, TACTILE (∨)
S131 1-762-751-11 SWITCH, TACTILE (PRESET TUNING –)
S132 1-762-751-11 SWITCH, TACTILE (TUNING –)
S133 1-762-751-11 SWITCH, TACTILE (PRESET TUNING +)
S134 1-762-751-11 SWITCH, TACTILE (TUNING +)
S151 1-762-751-11 SWITCH, TACTILE (POWER)(EXCEPT SP,MY)
< VIBRATOR >
X101 1-567-819-11 VIBRATOR, CERAMIC (4MHz)
**************************************************************
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
DISPLAY H.P
MEMORY
L.B SWJOINT (OSD)
JOINT (B)
* 1-665-625-11 H.P BOARD
*********
< CONNECTOR >
* CNP702 1-564-518-11 PLUG, CONNECTOR 3P
< JACK >
J701 1-568-519-41 JACK, LARGE TYPE (PHONES)
**************************************************************
* 1-666-632-11 JOINT (B) BOARD
***************
< CONNECTOR >
CNP213 1-750-180-11 PIN, CONNECTOR (PC BOARD) 5P
CNP216 1-750-180-11 PIN, CONNECTOR (PC BOARD) 5P
**************************************************************
* 1-666-159-11 JOINT (OSD) BOARD
*****************
< CONNECTOR >
CNP211 1-695-089-11 PIN, CONNECTOR (PC BOARD) 11P
CNP212 1-695-089-11 PIN, CONNECTOR (PC BOARD) 11P
**************************************************************
* 1-665-622-11 L.B SW BOARD
************
< DIODE >
D117 8-719-313-45 DIODE SEL6810A-TH10 (BASS BOOST)
< RESISTOR >
R160 1-249-411-11 CARBON 330 5% 1/4W
< SWITCH >
S135 1-762-751-11 SWITCH, TACTILE (BASS BOOST)
**************************************************************
* A-4398-133-A MEMORY BOARD, COMPLETE
***********************
< CAPACITOR >
C288 1-164-159-11 CERAMIC 0.1uF 50V
C289 1-164-159-11 CERAMIC 0.1uF 50V
C290 1-126-967-11 ELECT 47uF 20% 16V
C291 1-164-159-11 CERAMIC 0.1uF 50V
C294 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CNS205 1-779-768-11 SOCKET, CONNECTOR 29P
< IC >
IC216 8-759-916-94 IC SN74HC373AN
IC218 8-759-916-94 IC SN74HC373AN
