* You must connect the HDMI OUT or MONITOR
OUT jack to your TV to watch the selected input
image (page 27).
F VIDEO/AUDIO INPUT/OUTPUT
section (page 27, 30, 31, 32, 33, 37)
AUDIO IN/OUT jacks
VIDEO IN/OUT* jacks
AUDIO OUT jacks
VIDEO OUT jack
(page 72)
SUBWOOFER jacks
Connect to an external subwoofer(s).
G UWA-C4Z
Connect the supplied Lighting Control
Adapter (UWA-C4Z) to this port.
H COMPONENT VIDEO INPUT/
OUTPUT section (page 27, 30, 32)
Y, P
B
, P
R
IN/OUT* jacks
I SPEAKERS section (page 25)
