Sony STR-DA3200ES - Page 102

102
STR-DA3200ES/DG1000
IC6102 SM5302AS-G-ET
1REF1
2VDD
3SDA
4SCL
5VSS
8IN1A
10ISET
6MUXSEL
7ADS
26 VCC1
27 REF3
28 REF2
25 OUT1A
24 OUT1B
23 GND1
I2C CONTROL
VREF
CURRENT
SOURCE
CLAMP/BIAS/DIRECT
9IN1B CLAMP/BIAS/DIRECT
MUX
5th ORDER
LOW-PASS
FILTER
(STANDARD FC)
11IN2A CLAMP/BIAS/DIRECT
12IN2B CLAMP/BIAS/DIRECT
MUX
CH-1
0dB/6dB
BYPASS
FILTER
0dB/6dB
BYPASS
FILTER
0dB/6dB
BYPASS
FILTER
CH-2
11IN3A CLAMP/BIAS/DIRECT
12IN3B CLAMP/BIAS/DIRECT
MUX
CH-3
22 VCC2
21 OUT2A
20 OUT2B
19 GND2
5th ORDER
LOW-PASS
FILTER
(STANDARD
/HALF FC)
18 VCC3
17 OUT3A
16 OUT3B
15 GND3
5th ORDER
LOW-PASS
FILTER
(STANDARD
/HALF FC)
IC6301, 6306 BA76622F-E2-A
1
2
3
4
8
7
6
5
GND
IN1
IN2
IN3
OUT2
OUT3
VCC
75OHM
DRIVER
75OHM
DRIVER
75OHM
DRIVER
