Sony STR-DA3200ES - Page 110

110
STR-DA3200ES/DG1000
Pin No. Pin Name
I/O Description
109
SP-B-RY O Relay drive signal (for front-B) output terminal
110
C-RY O Relay drive signal (for center) output terminal
111
SB-RY O Relay drive signal (for surround back) output terminal
112
REAR-RY O Relay drive signal (for surround) output terminal
113
PROTECTOR I Protect signal input terminal
114
VSS - Ground terminal
115
VCC - Power supply terminal (+3.3V)
116
DSP MISO I Serial data input from the DSP or serial flash
117
DSP MOSI O Serial data output to the DSP or serial flash
118
DSP CLK O Serial data transfer clock signal output to the DSP
119
XM UART TX I UART communication transfer data input from the XM receiver
120
XM UART RX O UART communication receive data output to the XM receiver
121
XM RESET O System reset signal output to the XM receiver
122
HDMI TX I Serial data input from the HDMI controller
123
HDMI RX O Serial data output to the HDMI controller
124
HDMI RESET O System reset signal output to the HDMI controller
125
FLASH SI I Serial data input from the RS-232C connector
126
FLASH SO O Serial data output to the RS-232C connector
127
XM COMMAND O Commande mode select signal output to the XM receiver
128
XM REQUEST I Interrupt request signal input from the XM receiver
129
FL DATA O Serial data output to the fluorescent indicator tube
130
FL CLK O Serial data transfer clock signal output to the fluorescent indicator tube
131
NO USE - Not used
132
END FLAG O End flag output terminal Not used
133
RST TRG O Reset signal output terminal
134
NMIX - Not used
135
XA-OUT - Not used
136
VSS - Ground terminal
137
XA-IN - Not used
138 to 140
MD2 to MD0 I Model destination signal input terminal
141
X-IN I Main system clock input terminal (12.5 MHz)
142
VCC - Power supply terminal (+3.3V)
143
X-OUT O Main system clock output terminal (12.5 MHz)
144
XRESET I System reset signal input terminal "L": reset
145
VSS - Ground terminal
146
VCC - Power supply terminal (+3.3V)
147
NO USE - Not used
148
POWER RY2 O Relay drive signal (for main power) output terminal "H": relay on
149, 150
FUNCTION
JOG1,
FUNCTION
JOG2
I Jog dial pulse input from the rotary encoder (for INPUT SELECTOR)
151, 152
VOL JOG1,
VOL JOG2
I Jog dial pulse input from the rotary encoder (for MASTER VOLUME)
153
H.P. IN
I
Headphone detection signal input terminal "H": headphone is connected
154
LED STB O LED drive signal output terminal
155
LED DCS O LED drive signal output terminal
156
FL CLR O Clear signal output terminal Not used
