Sony STR-DA3200ES - Page 111

111
STR-DA3200ES/DG1000
Pin No.
Pin Name I/O Description
157
FL LAT O Serial data latch pulse output to the fluorescent indicator tube
158, 159
NO USE - Not used
160
LED MLT
ON/OFF
O LED drive signal output terminal
161
LED MLT DIM O LED drive signal output terminal
162
VSS - Ground terminal
163
VCC - Power supply terminal (+3.3V)
164
FSRATE I L/R sampling clock signal (44.1 kHz) input terminal
165, 166
NO USE - Not used
167
EEPROM SDA I/O Two-way data bus with the EEPROM
168
EEPROM SCL O Serial data transfer clock signal output to the EEPROM
169
+/- JOG1 I Jog dial pulse input terminal Not used
170
4/8 RELAY I Thermistor connection terminal for abnormal temperature detection (A/D input)
171
TE8200 RESET O System reset signal output to the sync separator
172
S_DET I Sync detection signal input terminal
173
4/8 SW - Not used
174
FL BCK I Blanking period signal output to the fluorescent indicator tube
175
VSS - Ground terminal
176
VCC - Power supply terminal (+3.3V)
