Sony STR-DA3200ES - HDMI Board IC3509 Pin Functions

115
STR-DA3200ES/DG1000
HDMI BOARD IC3505 SII9033CTU (HDMI RECEIVER)
Pin No.
Pin Name I/O Description
1
DE O Data enable signal output to the HDMI transmitter
2
HSYNC O Horizontal synchronize signal output to the HDMI transmitter
3
VSYNC O Vertical synchronize signal output to the HDMI transmitter
4
IOGND - Ground terminal
5
IOVCC - Power supply terminal (+3.3V)
6 to 8
NC - Not used
9
EVNODD - Not used
10
DCLK - Not used
11 to 14
DR0, DL0, DR1,
DL1
-Compensation terminal
15
IOGND - Ground terminal
16
IOVCC - Power supply terminal (+3.3V)
17 to 20
DR2, DL2, DR3,
DL3
-Compensation terminal
21
CGND - Ground terminal
22, 23
CVCC18 - Power supply terminal (+1.8V)
24
CGND - Ground terminal
25
IOGND - Ground terminal
26
IOVCC - Power supply terminal (+3.3V)
27
CSDA I/O
I2C two-way data bus with the HDMI transmitter, HDMI controller, VIDEO A/D converter,
progressive scan converter and video encoder
28
CSCL I I2C clock signal input from the HDMI controller
29
DSDA1 I/O I2C two-way data bus with the HDMI ASSIGNABLE IN 2 jack
30
DSCL1 I I2C clock signal input from the HDMI ASSIGNABLE IN 2 jack
31
DSDA0 I/O I2C two-way data bus with the HDMI ASSIGNABLE IN 1 jack
32
DSCL0 I I2C clock signal input from the HDMI ASSIGNABLE IN 1 jack
33
R1PWR5V I HDMI ASSIGNABLE IN 2 jack detection signal input terminal
34
R0PWR5V I HDMI ASSIGNABLE IN 1 jack detection signal input terminal
35
CVCC18 - Power supply terminal (+1.8V)
36
CGND - Ground terminal
37
PVCC0 - Power supply terminal (+3.3V)
38
AVCC - Power supply terminal (+3.3V)
39
R0XC- I TMDS clock signal input from the HDMI ASSIGNABLE IN 1 jack
40
R0XC+ I TMDS clock signal input from the HDMI ASSIGNABLE IN 1 jack
41
AGND - Ground terminal
42
AVCC - Power supply terminal (+3.3V)
43
R0X0- I TMDS data input from the HDMI ASSIGNABLE IN 1 jack
44
R0X0+ I TMDS data input from the HDMI ASSIGNABLE IN 1 jack
45
AGND - Ground terminal
46
AVCC - Power supply terminal (+3.3V)
47
R0X1- I TMDS data input from the HDMI ASSIGNABLE IN 1 jack
48
R0X1+ I TMDS data input from the HDMI ASSIGNABLE IN 1 jack
49
AGND - Ground terminal
50
AVCC - Power supply terminal (+3.3V)
51
R0X2- I TMDS data input from the HDMI ASSIGNABLE IN 1 jack
52
R0X2+ I TMDS data input from the HDMI ASSIGNABLE IN 1 jack
53
AGND - Ground terminal
