Sony STR-DA3200ES - Page 116

116
STR-DA3200ES/DG1000
Pin No.
Pin Name I/O Description
54
TMDSPGND - Ground terminal
55
PVCC1 - Power supply terminal (+3.3V)
56
RSVD_A - Not used
57
AVCC - Power supply terminal (+3.3V)
58
R1XC- I TMDS clock signal input from the HDMI ASSIGNABLE IN 2 jack
59
R1XC+ I TMDS clock signal input from the HDMI ASSIGNABLE IN 2 jack
60
AGND - Ground terminal
61
AVCC - Power supply terminal (+3.3V)
62
R1X0- I TMDS data input from the HDMI ASSIGNABLE IN 2 jack
63
R1X0+ I TMDS data input from the HDMI ASSIGNABLE IN 2 jack
64
AGND - Ground terminal
65
AVCC - Power supply terminal (+3.3V)
66
R1X1- I TMDS data input from the HDMI ASSIGNABLE IN 2 jack
67
R1X1+ I TMDS data input from the HDMI ASSIGNABLE IN 2 jack
68
AGND - Ground terminal
69
AVCC - Power supply terminal (+3.3V)
70
R1X2- I TMDS data input from the HDMI ASSIGNABLE IN 2 jack
71
R1X2+ I TMDS data input from the HDMI ASSIGNABLE IN 2 jack
72
AGND - Ground terminal
73
CGND - Ground terminal
74
CVCC18 - Power supply terminal (+1.8V)
75
IOGND - Ground terminal
76
IOVCC - Power supply terminal (+3.3V)
77
MUTEOUT O Audio muting signal output terminal
78
SPDIF O S/PDIF signal output to the digital audio interface and HDMI transmitter
79
CVCC - Power supply terminal (+1.8V)
80
CGND - Ground terminal
81 to 84
SD3 to SD0 O Serial data output to the DSP and HDMI transmitter
85
WS O Word select signal output to the DSP and HDMI transmitter
86
SCK O Serial clock signal output to the DSP and HDMI transmitter
87
NC - Not used
88
MCLK O Audio master clock signal output to the DSP and HDMI transmitter
89
IOVCC - Power supply terminal (+3.3V)
90
IOGND - Ground terminal
91
CGND - Ground terminal
92
CVCC18 - Power supply terminal (+1.8V)
93
NC - Not used
94
AUDPVCC18 - Power supply terminal (+1.8V)
95
AUDPGND - Ground terminal
96
XTALOUT O System clock output terminal (28.322 MHz)
97
XTALIN I System clock input terminal (28.322 MHz)
98
XTALVCC - Power supply terminal (+3.3V)
99
REGVCC - Power supply terminal (+3.3V)
100
NC - Not used
101
RSVDL - Not used
102
RESET# I Reset signal input from the HDMI controller "L": reset
103
SCDT - Not used
