Sony STR-DA3200ES - Page 117

117
STR-DA3200ES/DG1000
Pin No.
Pin Name I/O Description
104
INT O Interrupt signal output to the HDMI controller
105
CVCC18 - Power supply terminal (+1.8V)
106
CGND - Ground terminal
107
CLK48B O Data bus latch enable signal output terminal Not used
108
IOGND - Ground terminal
109
IOVCC - Power supply terminal (+3.3V)
110 to 113
Q23 to Q20 O Serial data output to the HDMI transmitter, progressive scan converter and video encoder
114
CVCC18 - Power supply terminal (+1.8V)
115
CGND - Ground terminal
116 to 119
Q19 to Q16 O Serial data output to the HDMI transmitter, progressive scan converter and video encoder
120
IOGND - Ground terminal
121
ODCK O Output data clock signal output to the HDMI transmitter
122
IOVCC - Power supply terminal (+3.3V)
123 to 126
Q15 to Q12 O Serial data output to the HDMI transmitter, progressive scan converter and video encoder
127
CGND - Ground terminal
128
CVCC18 - Power supply terminal (+1.8V)
129 to 133
Q11 to Q7 O Serial data output to the HDMI transmitter, progressive scan converter and video encoder
134
IOVCC - Power supply terminal (+3.3V)
135
IOGND - Ground terminal
136, 137
Q6, Q5 O Serial data output to the HDMI transmitter, progressive scan converter and video encoder
138
CGND - Ground terminal
139
CVCC18 - Power supply terminal (+1.8V)
140 to 144
Q4 to Q0 O Serial data output to the HDMI transmitter, progressive scan converter and video encoder
