Sony STR-DA3200ES - HDMI Board IC3516 Pin Functions

120
STR-DA3200ES/DG1000
HDMI BOARD IC3516 CXD9837R (PROGRESSIVE SCAN CONVERTER)
Pin No.
Pin Name I/O Description
1
DVDD - Power supply terminal (+3.3V) (for I/O)
2
CLKI I System clock input (27 MHz) terminal
3
TEST17 I Terminal for test Fixed at "L" in this set
4
PLL EN I PLL enable signal input terminal
5 to 14
PI0 to PI9 I Video data input from the video A/D converter
15
NHSI I Horizontal sync signal input from the video A/D converter
16
NVSI I Vertical sync signal input from the video A/D converter
17
OVSS - Ground terminal (for I/O)
18
THRM I Through mode setting terminal Fixed at "L" in this set
19
CVSS - Ground terminal (for core)
20
NVSO O Vertical sync signal output to the video encoder
21
NHSO O Horizontal sync signal output to the video encoder
22 to 25
PO9 to PO6
OVideo signal output terminal Not used
26
OVDD - Power supply terminal (+3.3V) (for I/O)
27
OVSS - Ground terminal (for I/O)
28 to 33
PO5 to PO0
OVideo signal output terminal Not used
34
TEST0 I Terminal for test Fixed at "L" in this set
35
OVSS - Ground terminal (for I/O)
36
OVDD - Power supply terminal (+3.3V) (for I/O)
37
CVDD - Power supply terminal (+2.5V) (for core)
38
TEST1 I Terminal for test Fixed at "L" in this set
39
TEST2 I Terminal for test Fixed at "L" in this set
40
CLKO O System clock output (27 MHz) to the video encoder
41 to 45
YO9 to YO5
OVideo signal output to the video encoder
46
OVDD - Power supply terminal (+3.3V) (for I/O)
47
OVSS - Ground terminal (for I/O)
48 to 52
YO4 to YO0
OVideo signal output to the video encoder
53
OVDD - Power supply terminal (+3.3V) (for I/O)
54
CVSS - Ground terminal (for core)
55
OVSS - Ground terminal (for I/O)
56 to 60
CO0 to CO4
OVideo signal output to the video encoder
61
OVDD - Power supply terminal (+3.3V) (for I/O)
62
OVSS - Ground terminal (for I/O)
63 to 67
CO5 to CO9
OVideo signal output to the video encoder
68
FILM
O Film sequence detection flag output terminal Not used
69
RFFI I MPEG flag (repeat first field flag) input terminal Not used
70
OVSS - Ground terminal (for I/O)
71
CVDD - Power supply terminal (+2.5V) (for core)
72
IVDD - Power supply terminal (+3.3V) (for I/O)
73
OVDD - Power supply terminal (+3.3V) (for I/O)
74 to 77
MD19 to MD16 I/O Two-way data bus terminal Not used
78
OVDD - Power supply terminal (+3.3V) (for I/O)
79
OVSS - Ground terminal (for I/O)
80 to 83
MA3, MA4,
MA2, MA5
OAddress signal output to the SD-RAM
