121
STR-DA3200ES/DG1000
Pin No.
Pin Name I/O Description
84
OVDD - Power supply terminal (+3.3V) (for I/O)
85
OVSS - Ground terminal (for I/O)
86 to 89
MA1, MA6,
MA0, MA7
OAddress signal output to the SD-RAM
90
OVSS - Ground terminal (for I/O)
91
TEST5 - Ground terminal (for I/O)
92
CVSS - Ground terminal (for core)
93
OVDD - Power supply terminal (+3.3V) (for I/O)
94 to 97
MA10, MA8,
MA11, MA9
OAddress signal output to the SD-RAM
98
OVDD - Power supply terminal (+3.3V) (for I/O)
99
OVSS - Ground terminal (for I/O)
100
RAS O Row address strobe signal output to the SD-RAM
101
DQM O Data mask signal output to the SD-RAM
102
CAS O Column address strobe signal output to the SD-RAM
103
MCLK O Serial data transfer clock signal output to the SD-RAM
104
WE O Write enable signal output to the SD-RAM
105
TEST3 I Terminal for test Fixed at "L" in this set
106
TEST4 I Terminal for test Fixed at "L" in this set
107
OVSS - Ground terminal (for I/O)
108
OVDD - Power supply terminal (+3.3V) (for I/O)
109
CVDD - Power supply terminal (+2.5V) (for core)
110 to 113
MD7, MD8,
MD6, MD9
I/O Two-way data bus with the SD-RAM
114
OVDD - Power supply terminal (+3.3V) (for I/O)
115
OVSS - Ground terminal (for I/O)
116 to 119
MD5, MD10,
MD4, MD11
I/O Two-way data bus with the SD-RAM
120
OVDD - Power supply terminal (+3.3V) (for I/O)
121
OVSS - Ground terminal (for I/O)
122 to 125
MD3, MD12,
MD2, MD13
I/O Two-way data bus with the SD-RAM
126
OVSS - Ground terminal (for I/O)
127
CVSS - Ground terminal (for core)
128
OVDD - Power supply terminal (+3.3V) (for I/O)
129 to 132
MD1, MD14,
MD0, MD15
I/O Two-way data bus with the SD-RAM
133
SLV I
MPU interface slave address setting terminal
Slave address setting: 0 x 72 when SLV is "0", 0 x 70 when SLV is "1"
134
RFFO O MPEG flag (repeat first field flag) output terminal Not used
135
SDA I/O
I2C two-way data bus with the HDMI receiver, HDMI transmitter, HDMI controller, VIDEO A/D
converter and video encoder
136
SCL I Serial data transfer clock signal input from the HDMI controller
137
SRN I System reset signal input from the HDMI controller "L": reset
138
OVSS - Ground terminal (for I/O)
139
CVDD - Power supply terminal (+2.5V) (for core)
140
PLL VDD - Power supply terminal (+2.5V) (for PLL)
141
VPDX - Not used
