STR-DA3200ES/DG1000
AC ANALOG
< IC >
IC51 6-703-547-01 IC TA7805LS (DA3200ES: AEP, UK)
IC51 8-759-450-47 IC BA05T (DA3200ES: US, CND, TW/DG1000)
< JACK >
0 J02 1-251-718-11 OUTLET (2 GANG), AC (AC OUTLET)
(DA3200ES: US, CND/DG1000)
0 J02 1-785-285-11 OUTLET, AC (1P) (AC OUTLET)
(DA3200ES: AEP)
< TRANSISTOR >
Q51 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q52 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q53 8-729-029-86 TRANSISTOR DTC124ESA
Q54 8-729-140-97 TRANSISTOR 2SB734-34
Q55 8-729-029-86 TRANSISTOR DTC124ESA
< RESISTOR >
0 R01 1-219-237-91 SOLID 3.3M 20% 1/2W F
(DA3200ES: US, CND/DG1000)
R51 1-249-429-11 CARBON 10K 5% 1/4W
R52 1-249-427-11 CARBON 6.8K 5% 1/4W
R53 1-247-863-11 CARBON 22K 5% 1/4W
R54 1-249-421-11 CARBON 2.2K 5% 1/4W
R55 1-249-429-11 CARBON 10K 5% 1/4W
R58 1-247-843-11 CARBON 3.3K 5% 1/4W
R59 1-249-429-11 CARBON 10K 5% 1/4W
0 R60 1-249-389-11 CARBON 4.7 5% 1/4W F
R61 1-249-415-11 CARBON 680 5% 1/4W
< RELAY >
0 RY01 1-755-266-11 RELAY, AC POWER
< TRANSFORMER >
0 T02 1-435-162-21 TRANSFORMER, POWER
(DA3200ES: US, CND/DG1000)
0 T02 1-435-163-21 TRANSFORMER, POWER (DA3200ES: AEP, UK)
0 T02 1-437-477-12 TRANSFORMER, POWER (DA3200ES: TW)
************************************************************
A-1183-233-A ANALOG BOARD, COMPLETE
(DA3200ES: AEP, UK, TW)
A-1183-461-A ANALOG BOARD, COMPLETE
(DA3200ES: US, CND/DG1000)
***********************
< CAPACITOR >
C411 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
C412 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(DA3200ES: US, CND/DG1000)
C412 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
(DA3200ES: AEP, UK, TW)
C413 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
C414 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(DA3200ES: US, CND/DG1000)
C414 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
(DA3200ES: AEP, UK, TW)
C415 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
C416 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
C417 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
C418 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(DA3200ES: US, CND/DG1000)
C418 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
(DA3200ES: AEP, UK, TW)
C419 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
C420 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(DA3200ES: US, CND/DG1000)
C420 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
(DA3200ES: AEP, UK, TW)
C421 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
C431 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C432 1-163-125-00 CERAMIC CHIP 220PF 5% 50V
C433 1-126-961-11 ELECT 2.2uF 20% 50V
C434 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C435 1-126-935-11 ELECT 470uF 20% 16V
C436 1-125-896-91 MYLAR 0.0091uF 5% 50V
C437 1-136-159-00 MYLAR 0.033uF 5% 50V
C438 1-126-961-11 ELECT 2.2uF 20% 50V
C441 1-126-965-11 ELECT 22uF 20% 50V
C446 1-126-965-11 ELECT 22uF 20% 50V
C451 1-126-965-11 ELECT 22uF 20% 50V
C452 1-126-961-11 ELECT 2.2uF 20% 50V
C482 1-163-125-00 CERAMIC CHIP 220PF 5% 50V
(DA3200ES: AEP, UK, TW)
C483 1-163-125-00 CERAMIC CHIP 220PF 5% 50V
(DA3200ES: AEP, UK, TW)
C485 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C486 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C487 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C488 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C497 1-112-089-11 ELECT 47uF 20% 25V
C498 1-112-089-11 ELECT 47uF 20% 25V
C499 1-112-089-11 ELECT 47uF 20% 25V
C511 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
C512 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(DA3200ES: US, CND/DG1000)
C512 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
(DA3200ES: AEP, UK, TW)
C513 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
C514 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(DA3200ES: US, CND/DG1000)
C514 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
(DA3200ES: AEP, UK, TW)
C515 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
C516 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
C517 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
C518 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(DA3200ES: US, CND/DG1000)
C518 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
(DA3200ES: AEP, UK, TW)
C519 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
C520 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(DA3200ES: US, CND/DG1000)
C520 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
(DA3200ES: AEP, UK, TW)
C521 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
C531 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C532 1-163-125-00 CERAMIC CHIP 220PF 5% 50V
C533 1-126-961-11 ELECT 2.2uF 20% 50V
C534 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
