Sony STR-DA3200ES - Page 135

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
135
STR-DA3200ES/DG1000
ANALOG
C535 1-126-935-11 ELECT 470uF 20% 16V
C536 1-125-896-91 MYLAR 0.0091uF 5% 50V
C537 1-136-159-00 MYLAR 0.033uF 5% 50V
C538 1-126-961-11 ELECT 2.2uF 20% 50V
C541 1-126-965-11 ELECT 22uF 20% 50V
C546 1-126-965-11 ELECT 22uF 20% 50V
C551 1-126-965-11 ELECT 22uF 20% 50V
C552 1-126-961-11 ELECT 2.2uF 20% 50V
C582 1-163-125-00 CERAMIC CHIP 220PF 5% 50V
(DA3200ES: AEP, UK, TW)
C583 1-163-125-00 CERAMIC CHIP 220PF 5% 50V
(DA3200ES: AEP, UK, TW)
C585 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C586 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C587 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C588 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C597 1-112-089-11 ELECT 47uF 20% 25V
C598 1-112-089-11 ELECT 47uF 20% 25V
C599 1-112-089-11 ELECT 47uF 20% 25V
C615 1-163-025-11 CERAMIC CHIP 0.001uF 50V
C616 1-163-025-11 CERAMIC CHIP 0.001uF 50V
C617 1-163-025-11 CERAMIC CHIP 0.001uF 50V
C618 1-163-025-11 CERAMIC CHIP 0.001uF 50V
C619 1-163-025-11 CERAMIC CHIP 0.001uF 50V
C620 1-163-025-11 CERAMIC CHIP 0.001uF 50V
C621 1-163-025-11 CERAMIC CHIP 0.001uF 50V
C622 1-163-025-11 CERAMIC CHIP 0.001uF 50V
C623 1-163-025-11 CERAMIC CHIP 0.001uF 50V
C624 1-163-025-11 CERAMIC CHIP 0.001uF 50V
C625 1-163-025-11 CERAMIC CHIP 0.001uF 50V
C626 1-163-025-11 CERAMIC CHIP 0.001uF 50V
C627 1-163-025-11 CERAMIC CHIP 0.001uF 50V
C631 1-163-033-00 CERAMIC CHIP 0.022uF 50V
C632 1-163-033-00 CERAMIC CHIP 0.022uF 50V
C633 1-126-947-11 ELECT 47uF 20% 35V
C634 1-126-947-11 ELECT 47uF 20% 35V
C641 1-112-089-11 ELECT 47uF 20% 25V
C642 1-112-089-11 ELECT 47uF 20% 25V
C643 1-163-025-11 CERAMIC CHIP 0.001uF 50V
C644 1-163-025-11 CERAMIC CHIP 0.001uF 50V
C645 1-126-947-11 ELECT 47uF 20% 35V
C646 1-126-947-11 ELECT 47uF 20% 35V
C647 1-163-025-11 CERAMIC CHIP 0.001uF 50V
C648 1-163-025-11 CERAMIC CHIP 0.001uF 50V
C662 1-163-025-11 CERAMIC CHIP 0.001uF 50V
C663 1-163-025-11 CERAMIC CHIP 0.001uF 50V
C692 1-112-093-11 ELECT 2200uF 20% 25V
C693 1-112-093-11 ELECT 2200uF 20% 25V
C694 1-126-948-11 ELECT 100uF 20% 35V
< CONNECTOR >
CN601 1-794-006-11 CONNECTOR 20P
CN602 1-784-922-11 PIN, CONNECTOR 5P
CN603 1-784-923-11 PIN, CONNECTOR 7P
CN604 1-784-922-21 PIN, CONNECTOR 5P
(DA3200ES: US, CND/DG1000)
CN606 1-784-927-11 PIN, CONNECTOR 12P
CN608 1-779-978-11 PIN, CONNECTOR 3P
CNP401 1-564-320-00 PIN, CONNECTOR (3.96mm PITCH) 2P
< DIODE >
D641 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC301 8-759-710-97 IC NJM4565M-D
IC401 6-709-810-01 IC TC9274CNG-015
IC501 6-709-810-01 IC TC9274CNG-015
IC611 8-759-710-97 IC NJM4565M-D
IC613 8-759-710-97 IC NJM4565M-D
IC615 8-759-710-97 IC NJM4565M-D
IC616 8-759-710-97 IC NJM4565M-D
IC617 8-759-710-97 IC NJM4565M-D
IC619 8-759-710-97 IC NJM4565M-D
IC621 8-759-710-97 IC NJM4565M-D
IC643 8-759-710-97 IC NJM4565M-D
IC644 8-759-710-97 IC NJM4565M-D
< JACK >
J604 1-815-045-11 JACK, PIN 2P (PHONO IN)
J605 1-784-429-11 JACK, PIN 4P (SA-CD/CD IN, MD/DAT OUT)
J606 1-784-920-11 JACK, PIN 6P (MD/DAT/TAPE/CD-R IN, TAPE/
CD-R OUT)
J607 1-784-920-11 JACK, PIN 6P (TV/SAT/DVD AUDIO IN,
VIDEO 2 AUDIO OUT)
J608 1-784-920-11 JACK, PIN 6P (VIDEO 1/VIDEO 2 AUDIO IN,
VIDEO 1 AUDIO OUT)
J609 1-815-045-11 JACK, PIN 2P (SA-CD/CD/MD/TAPE IN, MD/
TAPE OUT)
< JUMPER RESISTOR >
JW450 1-216-295-00 SHORT CHIP 0
JW536 1-216-295-00 SHORT CHIP 0
JW554 1-216-295-00 SHORT CHIP 0
JW672 1-216-295-00 SHORT CHIP 0
JW673 1-216-295-00 SHORT CHIP 0
< TRANSISTOR >
Q540 8-729-230-49 TRANSISTOR 2SC2712-YG
< RESISTOR >
R411 1-208-437-41 RES-CHIP 1K 2% 1/10W
R412 1-208-437-41 RES-CHIP 1K 2% 1/10W
R413 1-208-437-41 RES-CHIP 1K 2% 1/10W
R414 1-208-437-41 RES-CHIP 1K 2% 1/10W
R415 1-208-437-41 RES-CHIP 1K 2% 1/10W
R416 1-208-437-41 RES-CHIP 1K 2% 1/10W
R417 1-208-437-41 RES-CHIP 1K 2% 1/10W
R418 1-208-437-41 RES-CHIP 1K 2% 1/10W
R419 1-208-437-41 RES-CHIP 1K 2% 1/10W
R420 1-208-437-41 RES-CHIP 1K 2% 1/10W
R421 1-208-437-41 RES-CHIP 1K 2% 1/10W
R422 1-208-518-41 RES-CHIP 22K 2% 1/10W
R423 1-208-518-41 RES-CHIP 22K 2% 1/10W
R424 1-208-518-41 RES-CHIP 22K 2% 1/10W
R425 1-208-518-41 RES-CHIP 22K 2% 1/10W
