Sony STR-DA3200ES - Page 137

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
137
STR-DA3200ES/DG1000
BIAS
C1909 1-127-888-11 CERAMIC 0.1uF 10% 50V
C1910 1-135-800-11 CERAMIC 1uF 50V
C1913 1-135-800-11 CERAMIC 1uF 50V
< CONNECTOR >
CNP1501 1-784-923-11 PIN, CONNECTOR 7P
CNP1502 1-564-704-41 PIN, CONNECTOR (SMALL TYPE) 2P
CNP1551 1-784-923-11 PIN, CONNECTOR 7P
CNP1552 1-564-704-41 PIN, CONNECTOR (SMALL TYPE) 2P
CNP1601 1-784-923-11 PIN, CONNECTOR 7P
CNP1602 1-564-704-41 PIN, CONNECTOR (SMALL TYPE) 2P
CNP1701 1-784-923-11 PIN, CONNECTOR 7P
CNP1702 1-564-704-41 PIN, CONNECTOR (SMALL TYPE) 2P
CNP1751 1-784-923-11 PIN, CONNECTOR 7P
CNP1752 1-564-704-41 PIN, CONNECTOR (SMALL TYPE) 2P
CNP1801 1-784-923-11 PIN, CONNECTOR 7P
CNP1802 1-564-704-41 PIN, CONNECTOR (SMALL TYPE) 2P
CNP1851 1-784-923-11 PIN, CONNECTOR 7P
CNP1852 1-564-704-41 PIN, CONNECTOR (SMALL TYPE) 2P
< DIODE >
D1521 8-719-991-33 DIODE 1SS133T-77
D1522 8-719-991-33 DIODE 1SS133T-77
D1571 8-719-991-33 DIODE 1SS133T-77
D1572 8-719-991-33 DIODE 1SS133T-77
D1621 8-719-991-33 DIODE 1SS133T-77
D1622 8-719-991-33 DIODE 1SS133T-77
D1721 8-719-991-33 DIODE 1SS133T-77
D1722 8-719-991-33 DIODE 1SS133T-77
D1771 8-719-991-33 DIODE 1SS133T-77
D1772 8-719-991-33 DIODE 1SS133T-77
D1821 8-719-991-33 DIODE 1SS133T-77
D1822 8-719-991-33 DIODE 1SS133T-77
D1871 8-719-991-33 DIODE 1SS133T-77
D1872 8-719-991-33 DIODE 1SS133T-77
D1901 8-719-991-33 DIODE 1SS133T-77
D1902 8-719-991-33 DIODE 1SS133T-77
D1903 8-719-991-33 DIODE 1SS133T-77
D1904 8-719-991-33 DIODE 1SS133T-77
D1905 8-719-991-33 DIODE 1SS133T-77
D1906 8-719-109-93 DIODE RD6.2ESB2
< IC >
IC1901 8-759-167-88 IC NJM4565D
IC1903 6-710-072-01 IC LM61CIZ/LFT2
IC1905 6-710-072-01 IC LM61CIZ/LFT2
< TRANSISTOR >
Q1522 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q1523 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q1524 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q1572 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q1573 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q1574 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q1622 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q1623 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q1624 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q1722 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q1723 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q1724 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q1772 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q1773 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q1774 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q1822 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q1823 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q1824 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q1872 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q1873 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q1874 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q1904 8-729-281-53 TRANSISTOR 2SC1815-GR
Q1905 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q1906 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q1907 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q1908 8-729-029-86 TRANSISTOR DTC124ESA
< RESISTOR >
R1521 1-259-440-61 CARBON 3.3K 5% 1/6W
R1522 1-259-428-61 CARBON 1K 5% 1/6W
R1524 1-259-468-61 CARBON 47K 5% 1/6W
R1525 1-247-847-91 CARBON 4.7K 5% 1/4W
0 R1526 1-240-855-91 CARBON 6.2K 5% 1/4W F
R1527 1-249-420-11 CARBON 1.8K 5% 1/4W
R1528 1-249-431-11 CARBON 15K 5% 1/4W
R1529 1-247-862-11 CARBON 20K 5% 1/4W
R1530 1-247-834-11 CARBON 1.3K 5% 1/4W
R1531 1-249-437-11 CARBON 47K 5% 1/4W
R1532 1-249-431-11 CARBON 15K 5% 1/4W
R1533 1-249-437-11 CARBON 47K 5% 1/4W
R1534 1-247-863-11 CARBON 22K 5% 1/4W
R1535 1-249-439-11 CARBON 68K 5% 1/4W
R1536 1-247-895-00 CARBON 470K 5% 1/4W
R1571 1-259-440-61 CARBON 3.3K 5% 1/6W
R1572 1-259-428-61 CARBON 1K 5% 1/6W
R1574 1-259-468-61 CARBON 47K 5% 1/6W
R1575 1-247-847-91 CARBON 4.7K 5% 1/4W
0 R1576 1-240-855-91 CARBON 6.2K 5% 1/4W F
R1577 1-249-420-11 CARBON 1.8K 5% 1/4W
R1578 1-249-431-11 CARBON 15K 5% 1/4W
R1579 1-247-862-11 CARBON 20K 5% 1/4W
R1580 1-247-834-11 CARBON 1.3K 5% 1/4W
R1581 1-249-437-11 CARBON 47K 5% 1/4W
R1582 1-249-431-11 CARBON 15K 5% 1/4W
R1583 1-249-437-11 CARBON 47K 5% 1/4W
R1584 1-247-863-11 CARBON 22K 5% 1/4W
R1585 1-249-439-11 CARBON 68K 5% 1/4W
R1586 1-247-895-00 CARBON 470K 5% 1/4W
R1621 1-259-440-61 CARBON 3.3K 5% 1/6W
R1622 1-259-428-61 CARBON 1K 5% 1/6W
R1624 1-259-468-61 CARBON 47K 5% 1/6W
R1625 1-247-847-91 CARBON 4.7K 5% 1/4W
0 R1626 1-240-855-91 CARBON 6.2K 5% 1/4W F
R1627 1-249-420-11 CARBON 1.8K 5% 1/4W
R1628 1-249-431-11 CARBON 15K 5% 1/4W
R1629 1-247-862-11 CARBON 20K 5% 1/4W
R1630 1-247-834-11 CARBON 1.3K 5% 1/4W
R1631 1-249-437-11 CARBON 47K 5% 1/4W
