Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
138
STR-DA3200ES/DG1000
BIAS CIS
R1632 1-249-431-11 CARBON 15K 5% 1/4W
R1633 1-249-437-11 CARBON 47K 5% 1/4W
R1634 1-247-863-11 CARBON 22K 5% 1/4W
R1635 1-249-439-11 CARBON 68K 5% 1/4W
R1636 1-247-895-00 CARBON 470K 5% 1/4W
R1721 1-259-440-61 CARBON 3.3K 5% 1/6W
R1722 1-259-428-61 CARBON 1K 5% 1/6W
R1724 1-259-468-61 CARBON 47K 5% 1/6W
R1725 1-247-847-91 CARBON 4.7K 5% 1/4W
0 R1726 1-240-855-91 CARBON 6.2K 5% 1/4W F
R1727 1-249-420-11 CARBON 1.8K 5% 1/4W
R1728 1-249-431-11 CARBON 15K 5% 1/4W
R1729 1-247-862-11 CARBON 20K 5% 1/4W
R1730 1-247-834-11 CARBON 1.3K 5% 1/4W
R1731 1-249-437-11 CARBON 47K 5% 1/4W
R1732 1-249-431-11 CARBON 15K 5% 1/4W
R1733 1-249-437-11 CARBON 47K 5% 1/4W
R1734 1-247-863-11 CARBON 22K 5% 1/4W
R1735 1-249-439-11 CARBON 68K 5% 1/4W
R1736 1-247-895-00 CARBON 470K 5% 1/4W
R1771 1-259-440-61 CARBON 3.3K 5% 1/6W
R1772 1-259-428-61 CARBON 1K 5% 1/6W
R1774 1-259-468-61 CARBON 47K 5% 1/6W
R1775 1-247-847-91 CARBON 4.7K 5% 1/4W
0 R1776 1-240-855-91 CARBON 6.2K 5% 1/4W F
R1777 1-249-420-11 CARBON 1.8K 5% 1/4W
R1778 1-249-431-11 CARBON 15K 5% 1/4W
R1779 1-247-862-11 CARBON 20K 5% 1/4W
R1780 1-247-834-11 CARBON 1.3K 5% 1/4W
R1781 1-249-437-11 CARBON 47K 5% 1/4W
R1782 1-249-431-11 CARBON 15K 5% 1/4W
R1783 1-249-437-11 CARBON 47K 5% 1/4W
R1784 1-247-863-11 CARBON 22K 5% 1/4W
R1785 1-249-439-11 CARBON 68K 5% 1/4W
R1786 1-247-895-00 CARBON 470K 5% 1/4W
R1821 1-259-440-61 CARBON 3.3K 5% 1/6W
R1822 1-259-428-61 CARBON 1K 5% 1/6W
R1824 1-259-468-61 CARBON 47K 5% 1/6W
R1825 1-247-847-91 CARBON 4.7K 5% 1/4W
0 R1826 1-240-855-91 CARBON 6.2K 5% 1/4W F
R1827 1-249-420-11 CARBON 1.8K 5% 1/4W
R1828 1-249-431-11 CARBON 15K 5% 1/4W
R1829 1-247-862-11 CARBON 20K 5% 1/4W
R1830 1-247-834-11 CARBON 1.3K 5% 1/4W
R1831 1-249-437-11 CARBON 47K 5% 1/4W
R1832 1-249-431-11 CARBON 15K 5% 1/4W
R1833 1-249-437-11 CARBON 47K 5% 1/4W
R1834 1-247-863-11 CARBON 22K 5% 1/4W
R1835 1-249-439-11 CARBON 68K 5% 1/4W
R1836 1-247-895-00 CARBON 470K 5% 1/4W
R1871 1-259-440-61 CARBON 3.3K 5% 1/6W
R1872 1-259-428-61 CARBON 1K 5% 1/6W
R1874 1-259-468-61 CARBON 47K 5% 1/6W
R1875 1-247-847-91 CARBON 4.7K 5% 1/4W
0 R1876 1-240-855-91 CARBON 6.2K 5% 1/4W F
R1877 1-249-420-11 CARBON 1.8K 5% 1/4W
R1878 1-249-431-11 CARBON 15K 5% 1/4W
R1879 1-247-862-11 CARBON 20K 5% 1/4W
R1880 1-247-834-11 CARBON 1.3K 5% 1/4W
R1881 1-249-437-11 CARBON 47K 5% 1/4W
R1882 1-249-431-11 CARBON 15K 5% 1/4W
R1883 1-249-437-11 CARBON 47K 5% 1/4W
R1884 1-247-863-11 CARBON 22K 5% 1/4W
R1885 1-249-439-11 CARBON 68K 5% 1/4W
R1886 1-247-895-00 CARBON 470K 5% 1/4W
R1909 1-249-429-11 CARBON 10K 5% 1/4W
R1910 1-249-417-11 CARBON 1K 5% 1/4W
R1911 1-247-863-11 CARBON 22K 5% 1/4W
R1912 1-249-429-11 CARBON 10K 5% 1/4W
R1913 1-249-429-11 CARBON 10K 5% 1/4W
R1914 1-247-863-11 CARBON 22K 5% 1/4W
R1915 1-247-863-11 CARBON 22K 5% 1/4W
R1916 1-249-430-11 CARBON 12K 5% 1/4W
R1917 1-247-895-00 CARBON 470K 5% 1/4W
R1918 1-249-437-11 CARBON 47K 5% 1/4W
R1919 1-249-429-11 CARBON 10K 5% 1/4W
R1928 1-249-427-11 CARBON 6.8K 5% 1/4W
< VARIABLE RESISTOR >
RV1501 1-238-595-11 RES, ADJ, CARBON 220
RV1551 1-238-595-11 RES, ADJ, CARBON 220
RV1601 1-238-595-11 RES, ADJ, CARBON 220
RV1701 1-238-595-11 RES, ADJ, CARBON 220
RV1751 1-238-595-11 RES, ADJ, CARBON 220
RV1801 1-238-595-11 RES, ADJ, CARBON 220
RV1851 1-238-595-11 RES, ADJ, CARBON 220
************************************************************
A-1183-234-A CIS BOARD, COMPLETE (DA3200ES)
********************
< CAPACITOR/JUMPER RESISTOR >
C801 1-126-947-11 ELECT 47uF 20% 35V
C802 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C803 1-126-961-11 ELECT 2.2uF 20% 50V
C804 1-126-947-11 ELECT 47uF 20% 35V
C805 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C831 1-126-960-11 ELECT 1uF 20% 50V
C851 1-126-767-11 ELECT 1000uF 20% 16V
C852 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C861 1-216-295-00 SHORT CHIP 0
C862 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C863 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C864 1-126-963-11 ELECT 4.7uF 20% 50V
C865 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C868 1-216-295-00 SHORT CHIP 0
C881 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C883 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C884 1-126-933-11 ELECT 100uF 20% 16V
C885 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C886 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C887 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C888 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
