Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
139
STR-DA3200ES/DG1000
< DIODE >
D801 8-719-988-61 DIODE 1SS355TE-17
D802 8-719-075-86 LED SID307BRTP19
(REMOTE CONTROL TRANSCEIVER)
D803 8-719-988-61 DIODE 1SS355TE-17
< EARTH TERMINAL >
EB801 1-537-738-21 TERMINAL, GROUND
EB802 1-537-738-21 TERMINAL, GROUND
< FERRITE BEAD >
FB881 1-469-152-11 FERRITE, EMI (SMD) (2012)
< IC >
IC801 6-600-349-21 IC NJL23H400A
IC802 8-759-671-94 IC MC74HC4053AFEL
IC861 8-759-470-63 IC NJM2145M-TE2
IC881 8-759-065-85 IC MAX232N
< JACK/CONNECTOR >
J801 1-563-330-11 JACK (IR REMOTE IR IN)
J802 1-563-330-11 JACK (IR REMOTE IR OUT 1)
J803 1-563-330-11 JACK (IR REMOTE IR OUT 2)
J831 1-563-330-11 JACK (TRIGGER OUT MAIN)
J861 1-563-330-11 JACK (CTRL S IN)
J862 1-563-330-11 JACK (CTRL S OUT)
J881 1-815-737-11 CONNECTOR, (D) SUB 9P (RS232C)
< JUMPER RESISTOR >
JW845 1-216-295-00 SHORT CHIP 0
JW861 1-216-295-00 SHORT CHIP 0
< TRANSISTOR >
Q831 8-729-140-93 TRANSISTOR 2SB733-34
Q832 8-729-027-43 TRANSISTOR DTC114EKA-T146
< RESISTOR/THERMISTOR >
R801 1-216-073-00 RES-CHIP 10K 5% 1/10W
R802 1-216-001-00 RES-CHIP 10 5% 1/10W
R803 1-216-097-11 RES-CHIP 100K 5% 1/10W
R804 1-216-073-00 RES-CHIP 10K 5% 1/10W
R805 1-216-097-11 RES-CHIP 100K 5% 1/10W
R806 1-216-025-11 RES-CHIP 100 5% 1/10W
R807 1-216-025-11 RES-CHIP 100 5% 1/10W
R831 1-801-726-11 THERMISTOR, POSITIVE
R832 1-216-073-00 RES-CHIP 10K 5% 1/10W
R833 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R834 1-216-073-00 RES-CHIP 10K 5% 1/10W
R845 1-216-025-11 RES-CHIP 100 5% 1/10W
R851 1-216-295-00 SHORT CHIP 0
R861 1-216-049-11 RES-CHIP 1K 5% 1/10W
R862 1-216-049-11 RES-CHIP 1K 5% 1/10W
R863 1-216-049-11 RES-CHIP 1K 5% 1/10W
R864 1-216-049-11 RES-CHIP 1K 5% 1/10W
R865 1-216-049-11 RES-CHIP 1K 5% 1/10W
R881 1-216-025-11 RES-CHIP 100 5% 1/10W
R882 1-216-025-11 RES-CHIP 100 5% 1/10W
************************************************************
CONNECTOR L BOARD
******************
< CONNECTOR >
CNP1206 1-784-038-21 CONNECTOR, BOARD TO BOARD 9P
CNP1207 1-784-038-21 CONNECTOR, BOARD TO BOARD 9P
************************************************************
CONNECTOR R BOARD
*****************
< CONNECTOR >
CNP1201 1-573-844-11 CONNECTOR, BOARD TO BOARD 12P
CNP1202 1-573-844-11 CONNECTOR, BOARD TO BOARD 12P
************************************************************
A-1221-148-A DCDC-1 BOARD, COMPLETE
***********************
4-974-510-11 SCREW (+BV 3X8 CU)
< CAPACITOR >
C1406 1-128-950-21 ELECT 1000uF 20% 16V
C1407 1-127-888-11 CERAMIC 0.1uF 10% 50V
C1412 1-128-950-21 ELECT 1000uF 20% 16V
C1413 1-115-871-11 ELECT 1uF 20% 50V
C1427 1-128-549-11 ELECT 3300uF 20% 35V
C1429 1-128-959-21 ELECT 1000uF 20% 35V
C1430 1-128-959-21 ELECT 1000uF 20% 35V
< CONNECTOR >
CN1410 1-691-769-11 PLUG (MICRO CONNECTOR) 7P
CNP1451 1-778-293-11 PLUG (MICRO CONNECTOR) 2P
< DIODE >
D1402 8-719-059-21 DIODE RK46LF-T2
D1404 8-719-301-45 DIODE RK14
D1409 8-719-510-53 DIODE D4SB60L
< FUSE HOLDER >
FH1403 1-533-313-11 FUSE HOLDER
FH1453 1-533-313-11 FUSE HOLDER
< IC >
IC1403 8-759-474-09 IC SI-8050S-LF1101
IC1404 6-701-021-01 IC SI-8120JF
< COIL >
L1401 1-456-721-11 INDUCTOR 100uH
L1402 1-456-545-11 INDUCTOR 100uH
L1403 1-456-545-11 INDUCTOR 100uH
L1404 1-456-545-11 INDUCTOR 100uH
< TRANSISTOR >
Q1409 8-729-029-86 TRANSISTOR DTC124ESA
CONNECTOR L
CIS CONNECTOR R DCDC-1
