Sony STR-DA7100ES - Additional Information; Menu Parameter Reference

122
GB
Menu list (LEVEL/SURR SET UP/EQUALIZER/TUNER/SPEAKER SET UP/
CUSTOMIZE/CIS/STREAM INFO)
Various configuration are possible using the menu list. The menu list is displayed by pressing
MENU.
Additional Information
Menu Item Parameter Initial
setting
Refer
page
LEVEL TEST TONE [xxx] OFF, AUTO, FIX OFF page 52,
99 - 101
*PHASE NOISE [xxx] OFF, L/C, C/R, R/SL, R/SR, SR/SL,
SL/L, SR/L
OFF
*PHASE AUDIO OFF, L/C, C/R, R/SL, R/SR, SR/SL,
SL/L, SR/L
OFF
FRONT L--- ---R 8.0dB (0.5dB step) 0dB
CENTER [xxx.x dB] –20.0dB to +10.0dB (0.5dB step) 0dB
SURROUND L [xxx.x dB] –20.0dB to +10.0dB (0.5dB step) 0dB
SURROUND R [xxx.x dB] –20.0dB to +10.0dB (0.5dB step) 0dB
SURR BACK [xxx.x dB] –20.0dB to +10.0dB (0.5dB step) 0dB
SURR BACK L [xxx.x dB] –20.0dB to +10.0dB (0.5dB step) 0dB
SURR BACK R [xxx.x dB] –20.0dB to +10.0dB (0.5dB step) 0dB
SUB WOOFER [xxx.x dB] –20.0dB to +10.0dB (0.5dB step) 0dB
MULTI CH SW [xxx] 0dB, +10.0dB 0dB
D. RANGE COMP. [xxx] OFF, STD, MAX OFF
SURR SET
UP
*C.WIDTH L----C----R 8 step 3 page 98
- 99
*DIMENSION F------S 7 step Center
*PANORAMA MODE [_ _ _] OFF, ON OFF
EFFECT LEVEL _ _ _% 20% to 120% (5% step) 100%
*SCREEN DEPTH [_ _ _] ON, OFF ON
*VIR. SPEAKERS [_ _ _] ON, OFF ON
*A. F. D. 2CH SW [xxx] CREATE, OFF OFF
EQUALIZER EQ PRESET [x] 1, 2, 3, 4, 5, OFF 1 page
104
FRONT BASS [xxx.x dB] –10.0dB to +10.0dB (1dB step) 0dB
FRONT TREBLE [xxx.x
dB]
–10.0dB to +10.0dB (1dB step) 0dB
CENTER BASS [xxx.x dB] –10.0dB to +10.0dB (1dB step) 0dB
CENTER MID [xxx.x dB] –10.0dB to +10.0dB (1dB step) 0dB
