3a: Connecting the audio components
This section describes how to hook up your
components to this receiver. Before you begin,
refer to “Component to be connected” below
for the pages which describe how to connect
each component.
After hooking up all your components,
proceed to “4: Connecting the antennas” (page
43).
a)
Model with a DIGITAL OPTICAL OUTPUT or DIGITAL COAXIAL OUTPUT jack, etc.
b)
Model with MULTI CH OUTPUT jacks, etc. This connection is used to output audio decoded by the
component’s internal multi-channel decoder through this receiver.
c)
Model equipped only with AUDIO OUT L/R jacks, etc.
If you have Sony components with
CONTROL A1II/CONTROL S jacks
See “Operating Sony components” on page
87.
How to hook up your
components
Component to
be connected
Super Audio CD player/ CD
player
With digital audio output
a)
page 26
With multi-channel audio output
b)
page 28
With i.LINK jack page 29
With analog audio output only
c)
page 31
MD/DAT With digital audio output
a)
page 26
With analog audio output only
c)
page 31
Tape deck, Analog disc turntable page 31
