Frequency response
PHONO RIAA equalization curve
*OS dB
CDISACD, TAPE,
lOHz- 1OOkHz
MD/DAT, MD/TAPE,
+3 dB (with sound field,
TV/SAT, DVDILD, equalizer, and bass boost
VIDEO 1,2,3
bypassed)
Inputs (Analog)
PHONO
Sensitivity: 2.5 mV
Impedance: 50 kilohms
SiiP: 86 dB (A 2 5 mVS’)
1 .
Sensitivity: 150 mV
Impedance: 50 kilohms
S/N? 96 dB
(A, 150 mVs))
MULTICHIN(l, 2),
CDISACD, TAPE,
MD/DAT, MD/TAPE,
DVDILD, TV/SAT,
VIDEO 1,2,3
4) INPUT SHORT.
5) Weighted network, input level.
Inputs (Digital)
DVDiLD (Coaxial)
Sensitivity: -
Impedance: 75 ohms
S/N: 100 dB
(A, 20 kHz LPF)
DVDiLD, TV/SAT,
MD/DAT, MD/TAPE
(Optical)
Sensitivity: -
Impedance: -
S/N: 100 dB
(A, 20 kHz LPF)
outputs
TAPE, MD/DAT, MD/ Voltage: 150 mV
TAPE (REC OUT), Impedance: 1 kilohms
VIDEO 112 (AUDIO
OUT)
FRONT L/R, Voltage: 2 V
CENTER,
SURROUND L/R,
SURROUND BACK,
SUB WOOFER
Impedance: 1 kilohms
EQ
BASS:
MID:
TREBLE:
Gain levels:
99 Hz-l.OkHz
(21 steps)
198 Hz-10 kHz
(37 steps)
1.0 kHz-10 kHz
(23 steps)
r10 dB, 1 dB step
FM tuner section
Tuning range
Antenna terminals
Sensitivity
Mono:
Stereo:
Usable sensitivity
SIN
Mono:
Stereo:
87.5 - 108.0 MHz
75 ohms, unbalanced
18.3 dBf, 2.2 pV/75 ohms
38.3 dBf, 22.5 pV/75 ohms
11.2 dBf, 1 pV/75 ohms
76 dB
70 dB
Harmonic distortion at 1 kHz
Mono: 0.3%
Stereo: 0.5%
Separation 45 dB at 1 kHz
Frequency response 30 Hz - 15 kHz,
+0.5/-2 dB
Selectivity 60 dB at 400 kHz
AM tuner section
Tuning range
Models of area code U, CA
With lo-kHz tuning scale: 530 - 1.710 kHz@
With 9-kHz tuning scale: 531 - 1.710 kHz6’
Models of area code E
With lo&Hz tuning scale: 530 - 1.610 kH#
With Y-l&z tuning scale: 531 - 1.602 kHz6’
Models of area code CN, SP, CEL, TW
With 9-kHz tuning scale: 53 1 - 1.602 kHz
Antenna Loop antenna
Usable sensitivity 50 dB/m (at 1,000 kHz or
999 kHz)
SIN 54 dB (at 50 mV/m)
Harmonic distortion 0.5 % (50 mV/m,
400 kHz)
Selectivity
At 9 kHz:
At 10 kHz:
35 dB
4odB
6) You can change the AM tuning scale to 9 kHz or
10 kHz. After tuning in any AM station, turn off
the receiver. Hold down PRESET TUNING + and
press I/&. All preset stations will be erased when
you change the tuning scale. To reset the scale to
10 kHz (or 9 kHz), repeat the procedure.
continued
