Sony STR-DB795 Service Manual

2
STR-DB795
4) INPUT SHORT.
5) Weighted network, input level.
Inputs (Digital)
Outputs
EQ
FM tuner section
Tuning range 87.5 - 108.0 MHz
Antenna FM wire antenna
Antenna terminals 75 ohms, unbalanced
Intermediate frequency 10.7 MHz
Sensitivity
Mono: 18.3 dBf, 2.2 µV/75 ohms
Stereo: 38.3 dBf, 22.5 µV/75 ohms
Useable sensitivity 11.2 dBf, 1 µV/75 ohms
S/N
Mono: 76 dB
Stereo: 70 dB
Harmonic distortion at 1 kHz
Mono: 0.3%
Stereo: 0.5%
Separation 45 dB at 1 kHz
Frequency response 30 Hz − 15 kHz,
+0.5/−2 dB
Selectivity 60 dB at 400 kHz
AM tuner section
Tuning range
Models of area code AEP, UK, SP, MY, TW, KR, AUS
With 9-kHz tuning scale 531 − 1,602 kHz
Antenna Loop antenna
Intermediate frequency 450 kHz
Usable sensitivity 50 dB/m (at 1,000 kHz or
999 kHz)
S/N 54 dB (at 50 mV/m)
Harmonic distortion 0.5% (50 mV/m, 400 Hz)
Selectivity
At 9 kHz: 35 dB
Video section
Inputs/Outputs
Video: 1 Vp-p, 75 ohms
S-video: Y: 1 Vp-p, 75 ohms
C: 0.286 Vp-p, 75 ohms
COMPONENT VIDEO: Y: 1 Vp-p, 75 ohms
B-Y: 0.7 Vp-p, 75 ohms
R-Y: 0.7 Vp-p, 75 ohms
80 MHz HD Pass Through
General
Power requirements
DVD (Coaxial) Impedance: 75 ohms
S/N: 100 dB
(A, 20 kHz LPF)
DVD, TV/SAT, MD,
VIDEO3 (Optical)
S/N: 100 dB
(A, 20 kHz LPF)
MD/TAPE (REC OUT),
VIDEO 1, 2
(AUDIO OUT)
Voltage: 150 mV
Impedance: 2.2 kilohms
SUB WOOFER Voltage: 2 V
Impedance: 1 kilohms
Gain levels ±10 dB, 1 dB step
Area code Power requirements
AEP, UK 230 V AC, 50/60 Hz
AUS 240 V AC, 50 Hz
SP, MY 220−230 V AC, 50/60 Hz
TW 110 V AC, 60 Hz
KR 220−230 V AC, 50/60 Hz
Power consumption
Power consumption (during standby mode)
0.3 W (when “POWER
SAVE” in the
CUSTOMIZE menu is set
to “ON”)
Dimensions 430 × 161 × 400 mm
including projecting parts
and controls
Mass (Approx.) 14.5 kg
Supplied accessories
FM wire antenna (1)
AM loop antenna (1)
Remote commander RM-PP413 (1)
R6 (size-AA) batteries (2)
Design and specifications are subject to change
without notice.
Area code Power consumption
AEP, UK, SP, MY, KR, AUS 270 W
TW 650 W
• Abbreviation
AUS: Australian model
KR : Korean model
MY : Malaysia model
SP : Singapore model
TW : Taiwan model

Sony STR-DB795 Specifications

General

Dimensions (WxDxH)	430 x 401 x 161 mm
Power requirements	230V, 50/60Hz
Supported radio bands	FM, MW
Radio Data System (RDS)	Yes
I/O ports	5.1 Analogue Input - 1.0 Audio Input - 3.0 Audio Input Front - 1 AV, S-Video Audio Output - 1.0 Control A1 / A1 II Digital Input: coaxial - 1.0 Digital Input: optical - 4.0 Digital Output: optical - 1.0 Headphone Output Monitor Output (Picture): FBAS - 1.0 Monitor Output (Picture): S-Video - 1.0 Phono Input Speaker Selector A S-Video Input - 4.0 S-Video Output - 1.0 Video Input - 5.0 Video Output - 2.0
Connectivity technology	Wired
Frequency range	20 - 20000 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	290 W

Weight and Dimensions

Weight	12500 g
