Sony STR-DB795 Service Manual

61
STR-DB795
– MAIN Board –
IC401, 501, 601, 651 CXD9725M
TRIM VOLUME
0-+24dB/
1dB STEP
TRIM VOLUME
0-+24dB/
1dB STEP
5 to 25 DECODER
&
LATCH CIRCUIT
4 to 13 DECODER
&
LATCH CIRCUIT
4 to 16 DECODER
&
LATCH CIRCUIT
24 BIT
SHIFT REGISTER
CIRCUIT
LEVEL SHIFT
CIRCUIT
5 to 25 DECODER
&
LATCH CIRCUIT
4 to 13 DECODER
&
LATCH CIRCUIT
4 to 16 DECODER
&
LATCH CIRCUIT
2VSS
3TRIM
4TRIM
5TRIM
6OUT
7VRGND
9VRIN
8NC
11CS1
10NC
14NC
1NC
12GND
13CLK
26 TRIM
25 TRIM
24 TRIM
23 OUT
22 VRGND
20 VRIN
21 NC
28 NC
18 CS2
19 NC
15 NC
17 LAT
16 DATA
26 VDD
MAIN
VOLUME
0- –95dB/
0.5dB STEP
MAIN
VOLUME
0- –95dB/
0.5dB STEP

Sony STR-DB795 Specifications

General

Dimensions (WxDxH)	430 x 401 x 161 mm
Power requirements	230V, 50/60Hz
Supported radio bands	FM, MW
Radio Data System (RDS)	Yes
I/O ports	5.1 Analogue Input - 1.0 Audio Input - 3.0 Audio Input Front - 1 AV, S-Video Audio Output - 1.0 Control A1 / A1 II Digital Input: coaxial - 1.0 Digital Input: optical - 4.0 Digital Output: optical - 1.0 Headphone Output Monitor Output (Picture): FBAS - 1.0 Monitor Output (Picture): S-Video - 1.0 Phono Input Speaker Selector A S-Video Input - 4.0 S-Video Output - 1.0 Video Input - 5.0 Video Output - 2.0
Connectivity technology	Wired
Frequency range	20 - 20000 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	290 W

Weight and Dimensions

Weight	12500 g
