Sony STR-DB795 - Page 83

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
83
STR-DB795
< RESISTOR >
R954 1-249-417-11 CARBON 1K 5% 1/4W
R955 1-249-415-11 CARBON 680 5% 1/4W
R956 1-249-429-11 CARBON 10K 5% 1/4W
R957 1-249-415-11 CARBON 680 5% 1/4W
R958 1-249-429-11 CARBON 10K 5% 1/4W
R959 1-249-429-11 CARBON 10K 5% 1/4W
0R960 1-214-816-00 METAL 10 1% 1/2W F
0R961 1-214-816-00 METAL 10 1% 1/2W F
R962 1-249-429-11 CARBON 10K 5% 1/4W
R963 1-247-847-91 CARBON 4.7K 5% 1/4W
R964 1-247-887-00 CARBON 220K 5% 1/4W
R965 1-249-401-11 CARBON 47 5% 1/4W
************************************************************
A-1054-338-A DIGITAL BOARD, COMPLETE (AEP, UK)
A-1055-433-A DIGITAL BOARD, COMPLETE (SP, MY)
A-1070-832-A DIGITAL BOARD, COMPLETE (TW, KR)
A-1070-859-A DIGITAL BOARD, COMPLETE (AUS)
***********************
< CAPACITOR >
C1100 1-164-222-11 CERAMIC CHIP 0.22uF 25V
C1101 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1102 1-112-128-11 CAP, ELECT 47uF
C1103 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1104 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1105 1-112-128-11 CAP, ELECT 47uF
C1106 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1107 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1108 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1109 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C1110 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C1111 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1112 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1113 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1114 1-162-905-11 CERAMIC CHIP 1PF 0.25PF 50V
C1115 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C1116 1-112-115-11 CAP, ELECT 1000uF
C1117 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1118 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C1119 1-112-144-11 CAP, ELECT 22uF
C1120 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1121 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1122 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1123 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1124 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1126 1-112-143-11 CAP, ELECT 10uF
C1127 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1129 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C1130 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1131 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1132 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1151 1-112-144-11 CAP, ELECT 22uF
C1152 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1153 1-162-905-11 CERAMIC CHIP 1PF 0.25PF 50V
C1154 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C1201 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1202 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1203 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1204 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1205 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1206 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1207 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1208 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1209 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1210 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1211 1-112-119-11 CAP, ELECT 470uF
C1212 1-112-119-11 CAP, ELECT 470uF
C1213 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1214 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1216 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1218 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1219 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1220 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1221 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(AEP, UK)
C1227 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1230 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1231 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1233 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1234 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C1235 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C1309 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1310 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1311 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1312 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1401 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1402 1-112-128-11 CAP, ELECT 47uF
C1403 1-112-143-11 CAP, ELECT 10uF
C1404 1-112-142-11 CAP, ELECT 4.7uF
C1405 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C1406 1-112-142-11 CAP, ELECT 4.7uF
C1407 1-112-143-11 CAP, ELECT 10uF
C1408 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C1409 1-112-128-11 CAP, ELECT 47uF
C1410 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1411 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1412 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1413 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1414 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C1415 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C1416 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1417 1-112-084-11 CAP, ELECT 470uF
C1418 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1501 1-112-118-11 CAP, ELECT 330uF
C1502 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1503 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1504 1-112-122-11 CAP, ELECT 220uF
C1505 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1506 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1507 1-112-143-11 CAP, ELECT 10uF
C1508 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1509 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1510 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1511 1-164-156-11 CERAMIC CHIP 0.1uF 25V
DIGITAL
DC2
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
