Sony STR-DB795 - Page 88

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
88
STR-DB795
C1011 1-127-888-11 CERAMIC 0.1uF 10% 50V
C1012 1-127-888-11 CERAMIC 0.1uF 10% 50V
C1013 1-127-888-11 CERAMIC 0.1uF 10% 50V
C1014 1-126-796-11 ELECT 22uF 20% 50V
C1015 1-128-813-11 CERAMIC 220PF 5% 50V
C1016 1-128-813-11 CERAMIC 220PF 5% 50V
C1017 1-128-813-11 CERAMIC 220PF 5% 50V
C1018 1-128-813-11 CERAMIC 220PF 5% 50V
C1019 1-128-813-11 CERAMIC 220PF 5% 50V
C1020 1-128-813-11 CERAMIC 220PF 5% 50V
C1021 1-128-813-11 CERAMIC 220PF 5% 50V
C1022 1-128-813-11 CERAMIC 220PF 5% 50V
C1023 1-128-813-11 CERAMIC 220PF 5% 50V
C1024 1-128-813-11 CERAMIC 220PF 5% 50V
C1025 1-128-813-11 CERAMIC 220PF 5% 50V
C1026 1-128-813-11 CERAMIC 220PF 5% 50V
C1027 1-127-888-11 CERAMIC 0.1uF 10% 50V
C1031 1-127-888-11 CERAMIC 0.1uF 10% 50V
C1051 1-126-786-11 ELECT 47uF 20% 16V
C1071 1-126-786-11 ELECT 47uF 20% 16V
< CONNECTOR >
CN1001 1-784-753-11 CONNECTOR, FFC 31P
< DIODE >
D1031 8-719-084-07 LED SEL5E20CTP15
(MULTI CHANNEL DECOCING)
D1071 8-719-068-28 DIODE HZ6.8BP-TK
< FLUORESCENT INDICATOR >
FL1603 1-518-966-11 VOCUUM FLUORESENT DISPLAYS
< IC >
IC1001 6-701-729-01 IC PT6315
IC1006 8-759-243-51 IC TC74ACT08P
IC1051 6-600-349-31 IC NJL24H400A
< TRANSISTOR >
Q1031 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q1032 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
JW1014 1-247-807-31 CARBON 100 5% 1/4W
JW1015 1-247-807-31 CARBON 100 5% 1/4W
R1004 1-249-437-11 CARBON 47K 5% 1/4W
R1005 1-249-440-11 CARBON 82K 5% 1/4W
R1009 1-249-437-11 CARBON 47K 5% 1/4W
0R1011 1-249-381-11 CARBON 1 5% 1/4W F
0R1012 1-249-381-11 CARBON 1 5% 1/4W F
R1031 1-249-409-11 CARBON 220 5% 1/4W
R1032 1-249-429-11 CARBON 10K 5% 1/4W
R1033 1-249-402-11 CARBON 56 5% 1/4W
R1035 1-249-429-11 CARBON 10K 5% 1/4W
R1036 1-247-847-91 CARBON 4.7K 5% 1/4W
R1037 1-247-847-91 CARBON 4.7K 5% 1/4W
R1042 1-249-417-11 CARBON 1K 5% 1/4W
R1043 1-249-421-11 CARBON 2.2K 5% 1/4W
R1044 1-249-421-11 CARBON 2.2K 5% 1/4W
R1045 1-247-847-91 CARBON 4.7K 5% 1/4W
R1046 1-249-429-11 CARBON 10K 5% 1/4W
R1047 1-247-863-11 CARBON 22K 5% 1/4W
R1052 1-249-417-11 CARBON 1K 5% 1/4W
R1053 1-249-421-11 CARBON 2.2K 5% 1/4W
R1054 1-249-421-11 CARBON 2.2K 5% 1/4W
R1055 1-247-847-91 CARBON 4.7K 5% 1/4W
R1056 1-249-429-11 CARBON 10K 5% 1/4W
R1058 1-249-393-11 CARBON 10 5% 1/4W
R1059 1-247-807-31 CARBON 100 5% 1/4W
< VARIABLE RESISTOR >
RV1051 1-467-808-21 ENCODER, ROTARY (MENU)
RV1052 1-467-808-21 ENCODER, ROTARY (-/+)
< SWITCH >
S1041 1-762-875-21 SWITCH, KEYBOARD (INPUT MODE)
S1042 1-762-875-21 SWITCH, KEYBOARD (DISPLAY)
S1043 1-762-875-21 SWITCH, KEYBOARD (MUSIC)
S1044 1-762-875-21 SWITCH, KEYBOARD (MOVIE)
S1045 1-762-875-21 SWITCH, KEYBOARD (A.F.D.)
S1046 1-762-875-21 SWITCH, KEYBOARD (2CH)
S1047 1-762-875-21 SWITCH, KEYBOARD (SURR BACK DECODING)
S1050 1-762-875-21 SWITCH, KEYBOARD (I/1)
S1051 1-762-875-21 SWITCH, KEYBOARD (TUNING +)
S1052 1-762-875-21 SWITCH, KEYBOARD (TUNING −)
S1053 1-762-875-21 SWITCH, KEYBOARD (PRESET TUNING +)
S1054 1-762-875-21 SWITCH, KEYBOARD (PRESET TUNING −)
S1056 1-762-875-21 SWITCH, KEYBOARD (MAIN MENU)
S1057 1-762-875-21 SWITCH, KEYBOARD (SPEAKERS)
S1065 1-762-875-21 SWITCH, KEYBOARD (MEMORY ENTER)
************************************************************
FUN BOARD
**********
< VARIABLE RESISTOR >
RV1061 1-467-808-21 ENCODER, ROTARY (INPUT SELECTOR)
************************************************************
HP-V3 BOARD
************
< CAPACITOR >
C1081 1-127-888-11 CERAMIC 0.1uF 10% 50V
C1088 1-127-888-11 CERAMIC 0.1uF 10% 50V
C1089 1-127-888-11 CERAMIC 0.1uF 10% 50V
C1096 1-127-888-11 CERAMIC 0.1uF 10% 50V
C1097 1-127-868-11 CERAMIC 2200PF 10% 50V
C1098 1-127-868-11 CERAMIC 2200PF 10% 50V
< CONNECTOR >
CN1081 1-784-922-11 PIN, CONNECTOR 5P
CN1091 1-784-925-11 PIN, CONNECTOR 10P
HP-V3
FUNDISPLAY
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
