– 82 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
Q302 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q303 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q304 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q352 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q353 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q354 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q501 8-729-900-36 TRANSISTOR DTC124ES
Q503 8-729-900-63 TRANSISTOR DTA124ES
< RESISTOR >
R301 1-249-401-11 CARBON 47 5% 1/4W F
R302 1-249-441-11 CARBON 100K 5% 1/4W
R303 1-249-440-11 CARBON 82K 5% 1/4W
R304 1-249-408-11 CARBON 180 5% 1/4W F
R305 1-249-428-11 CARBON 8.2K 5% 1/4W F
R306 1-249-441-11 CARBON 100K 5% 1/4W
R307 1-247-807-31 CARBON 100 5% 1/4W
R308 1-249-441-11 CARBON 100K 5% 1/4W
R309 1-249-413-11 CARBON 470 5% 1/4W F
R310 1-249-417-11 CARBON 1K 5% 1/4W F
R311 1-249-417-11 CARBON 1K 5% 1/4W F
R312 1-249-417-11 CARBON 1K 5% 1/4W F
R313 1-249-417-11 CARBON 1K 5% 1/4W F
R314 1-249-417-11 CARBON 1K 5% 1/4W F
R315 1-249-437-11 CARBON 47K 5% 1/4W
R331 1-249-441-11 CARBON 100K 5% 1/4W
R335 1-249-437-11 CARBON 47K 5% 1/4W
R336 1-249-425-11 CARBON 4.7K 5% 1/4W F
R337 1-249-441-11 CARBON 100K 5% 1/4W
R338 1-249-417-11 CARBON 1K 5% 1/4W F
R339 1-249-417-11 CARBON 1K 5% 1/4W F
R340 1-249-417-11 CARBON 1K 5% 1/4W F
R341 1-249-417-11 CARBON 1K 5% 1/4W F
R342 1-249-417-11 CARBON 1K 5% 1/4W F
R343 1-249-417-11 CARBON 1K 5% 1/4W F
R344 1-247-807-31 CARBON 100 5% 1/4W
R345 1-247-807-31 CARBON 100 5% 1/4W
R346 1-249-397-11 CARBON 22 5% 1/4W F
R347 1-249-397-11 CARBON 22 5% 1/4W F
R351 1-249-401-11 CARBON 47 5% 1/4W F
R352 1-249-441-11 CARBON 100K 5% 1/4W
R353 1-249-440-11 CARBON 82K 5% 1/4W
R354 1-249-408-11 CARBON 180 5% 1/4W F
R355 1-249-428-11 CARBON 8.2K 5% 1/4W F
R356 1-249-441-11 CARBON 100K 5% 1/4W
R357 1-247-807-31 CARBON 100 5% 1/4W
R358 1-249-441-11 CARBON 100K 5% 1/4W
R359 1-249-413-11 CARBON 470 5% 1/4W F
R360 1-249-417-11 CARBON 1K 5% 1/4W F
R361 1-249-417-11 CARBON 1K 5% 1/4W F
R362 1-249-417-11 CARBON 1K 5% 1/4W F
R363 1-249-417-11 CARBON 1K 5% 1/4W F
R364 1-249-417-11 CARBON 1K 5% 1/4W F
R365 1-249-437-11 CARBON 47K 5% 1/4W
R381 1-249-441-11 CARBON 100K 5% 1/4W
R385 1-249-437-11 CARBON 47K 5% 1/4W
R387 1-249-410-11 CARBON 270 5% 1/4W F
R388 1-249-417-11 CARBON 1K 5% 1/4W F
R389 1-249-417-11 CARBON 1K 5% 1/4W F
R390 1-249-417-11 CARBON 1K 5% 1/4W F
R391 1-249-417-11 CARBON 1K 5% 1/4W F
R392 1-249-417-11 CARBON 1K 5% 1/4W F
R393 1-249-417-11 CARBON 1K 5% 1/4W F
R394 1-249-417-11 CARBON 1K 5% 1/4W F
R395 1-249-397-11 CARBON 22 5% 1/4W F
R396 1-249-417-11 CARBON 1K 5% 1/4W F
R397 1-249-425-11 CARBON 4.7K 5% 1/4W F
R398 1-249-397-11 CARBON 22 5% 1/4W F
R399 1-249-425-11 CARBON 4.7K 5% 1/4W F
R401 1-249-441-11 CARBON 100K 5% 1/4W
R402 1-249-441-11 CARBON 100K 5% 1/4W
R403 1-249-441-11 CARBON 100K 5% 1/4W
R404 1-249-431-11 CARBON 15K 5% 1/4W
R405 1-249-431-11 CARBON 15K 5% 1/4W
R406 1-249-431-11 CARBON 15K 5% 1/4W
R407 1-249-437-11 CARBON 47K 5% 1/4W
R408 1-249-437-11 CARBON 47K 5% 1/4W
R409 1-249-437-11 CARBON 47K 5% 1/4W
R451 1-249-441-11 CARBON 100K 5% 1/4W
R452 1-249-441-11 CARBON 100K 5% 1/4W
R453 1-249-441-11 CARBON 100K 5% 1/4W
R454 1-249-431-11 CARBON 15K 5% 1/4W
R455 1-249-431-11 CARBON 15K 5% 1/4W
R456 1-249-434-11 CARBON 27K 5% 1/4W
R457 1-249-437-11 CARBON 47K 5% 1/4W
R458 1-249-437-11 CARBON 47K 5% 1/4W
R459 1-249-437-11 CARBON 47K 5% 1/4W
R501 1-249-417-11 CARBON 1K 5% 1/4W F
R502 1-249-439-11 CARBON 68K 5% 1/4W
R503 1-249-439-11 CARBON 68K 5% 1/4W
R504 1-247-843-11 CARBON 3.3K 5% 1/4W
R551 1-249-417-11 CARBON 1K 5% 1/4W F
R552 1-249-439-11 CARBON 68K 5% 1/4W
R553 1-249-439-11 CARBON 68K 5% 1/4W
R554 1-247-843-11 CARBON 3.3K 5% 1/4W
R590 1-249-433-11 CARBON 22K 5% 1/4W
! R592 1-249-381-11 CARBON 1 5% 1/4W F
! R593 1-249-381-11 CARBON 1 5% 1/4W F
R594 1-249-425-11 CARBON 4.7K 5% 1/4W F
R601 1-249-417-11 CARBON 1K 5% 1/4W F
R602 1-249-439-11 CARBON 68K 5% 1/4W
R603 1-249-439-11 CARBON 68K 5% 1/4W
R604 1-247-843-11 CARBON 3.3K 5% 1/4W
R651 1-249-417-11 CARBON 1K 5% 1/4W F
R652 1-249-439-11 CARBON 68K 5% 1/4W
R653 1-249-439-11 CARBON 68K 5% 1/4W
R654 1-247-843-11 CARBON 3.3K 5% 1/4W
R655 1-249-409-11 CARBON 220 5% 1/4W F
R656 1-249-409-11 CARBON 220 5% 1/4W F
R690 1-249-433-11 CARBON 22K 5% 1/4W
R701 1-249-417-11 CARBON 1K 5% 1/4W F
R702 1-249-439-11 CARBON 68K 5% 1/4W
R703 1-249-439-11 CARBON 68K 5% 1/4W
R704 1-247-843-11 CARBON 3.3K 5% 1/4W
INPUT
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
