– 72 –
• SEMICONDUCTORS
In each case, u: µ , for example:
uA...: µ A..., uPA...: µ PA..., uPB...: µ PB...,
uPC...: µ PC..., uPD...: µ PD...
• CAPACITORS
uF : µ F
• COILS
uH : µ H
• Due to standardization, replacements in the parts list
may be different from the parts specified in the
diagrams or the components used on the set.
• -XX, -X mean standardized parts, so they may have
some difference from the original one.
• Items marked “*” are not stocked since they are
seldom required for routine service. Some delay
should be anticipated when ordering these items.
• RESISTORS
All resistors are in ohms
METAL: Metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F : nonflammable
SECTION 5
ELECTRICAL PARTS LIST
Note:
When indicating parts by reference
number, please include the board
name.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
AMP5.1 IN
* 1-670-022-11 5.1 IN BOARD
************
< CAPACITOR >
CC40 1-162-282-31 CERAMIC 100PF 10% 50V
CC41 1-162-282-31 CERAMIC 100PF 10% 50V
CC42 1-162-282-31 CERAMIC 100PF 10% 50V
CC45 1-162-282-31 CERAMIC 100PF 10% 50V
CC46 1-162-282-31 CERAMIC 100PF 10% 50V
CC47 1-162-282-31 CERAMIC 100PF 10% 50V
< JACK >
J430 1-784-983-11 JACK, PIN 6P (5.1/DVD INPUT)
< RESISTOR >
R430 1-249-417-11 CARBON 1K 5% 1/4W F
R431 1-249-417-11 CARBON 1K 5% 1/4W F
R432 1-249-417-11 CARBON 1K 5% 1/4W F
R480 1-249-417-11 CARBON 1K 5% 1/4W F
R481 1-249-417-11 CARBON 1K 5% 1/4W F
R482 1-249-417-11 CARBON 1K 5% 1/4W F
**************************************************************
* 1-669-998-11 AC BOARD
********
< CONNECTOR >
* CNP905 1-580-230-21 PIN, CONNECTOR (PC BOARD) 2P
CNP915 1-691-766-11 PLUG (MICRO CONNECTOR) 4P
CNV901 1-564-321-00 PIN, CONNECTOR 2P
* CNV902 1-565-792-11 PIN, CONNECTOR 2P
< DIODE >
D907 8-719-911-19 DIODE 1SS119
< BRACKET >
E7 4-924-906-31 BRACKET
E8 4-924-906-31 BRACKET
< FUSE >
! F901 1-532-504-51 FUSE, TIME-LAG (4A/250V)
! F903 1-532-464-51 FUSE, TIME-LAG (2.5A/250V)
< FUSE HOLDER >
FH901 1-533-399-31 HOLDER, FUSE
FH903 1-533-399-31 HOLDER, FUSE
FH951 1-533-399-31 HOLDER, FUSE
FH953 1-533-399-31 HOLDER, FUSE
< RELAY >
RY901 1-515-999-11 RELAY, POWER
< TRANSFORMER >
! T902 1-431-387-11 TRANSFORMER, POWER
**************************************************************
* A-4414-094-A AMP BOARD, COMPLETE
*******************
< CAPACITOR >
C505 1-126-101-11 ELECT 100uF 20% 16V
C520 1-126-022-11 ELECT 47uF 20% 16V
C521 1-107-597-11 CERAMIC 22PF 10% 500V
C522 1-107-597-11 CERAMIC 22PF 10% 500V
C523 1-162-286-31 CERAMIC 220PF 10% 50V
C524 1-126-059-11 ELECT 10uF 20% 50V
C525 1-136-157-00 FILM 0.022uF 5% 50V
C526 1-136-153-00 FILM 0.01uF 5% 50V
C570 1-126-022-11 ELECT 47uF 20% 16V
C571 1-107-597-11 CERAMIC 22PF 10% 500V
C572 1-107-597-11 CERAMIC 22PF 10% 500V
C573 1-162-286-31 CERAMIC 220PF 10% 50V
C574 1-126-059-11 ELECT 10uF 20% 50V
C575 1-136-157-00 FILM 0.022uF 5% 50V
C576 1-136-153-00 FILM 0.01uF 5% 50V
C590 1-124-472-11 ELECT 470uF 20% 10V
C598 1-126-233-11 ELECT 22uF 20% 50V
C620 1-126-022-11 ELECT 47uF 20% 16V
C621 1-107-597-11 CERAMIC 22PF 10% 500V
C622 1-107-597-11 CERAMIC 22PF 10% 500V
C623 1-162-286-31 CERAMIC 220PF 10% 50V
C625 1-136-157-00 FILM 0.022uF 5% 50V
C801 1-104-664-11 ELECT 47uF 20% 25V
C803 1-125-997-11 ELECT 12000uF 20% 63V
C804 1-125-997-11 ELECT 12000uF 20% 63V
C805 1-130-781-00 FILM 0.22uF 10% 100V
C806 1-130-781-00 FILM 0.22uF 10% 100V
C807 1-126-967-11 ELECT 47uF 20% 50V
C808 1-126-967-11 ELECT 47uF 20% 50V
C811 1-126-041-11 ELECT 2200uF 20% 35V
C812 1-126-105-11 ELECT 1000uF 20% 35V
AC
To Next Page
