Sony STR-DB925 Service Manual

– 73 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C813 1-126-022-11 ELECT 47uF 20% 16V
CC48 1-136-153-00 FILM 0.01uF 5% 50V
CC49 1-136-153-00 FILM 0.01uF 5% 50V
CC98 1-136-153-00 FILM 0.01uF 5% 50V
CC99 1-136-153-00 FILM 0.01uF 5% 50V
< CONNECTOR >
CNP751 1-779-978-11 PIN, CONNECTOR 3P
* CNP801 1-564-243-11 PIN, CONNECTOR 6P
* CNP802 1-564-104-00 PIN, CONNECTOR (B3P-VH) 3P
CNP805 1-784-923-11 PIN, CONNECTOR 7P
CNP806 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
CNS651 1-784-806-11 HOUSING,CONNECTOR(PC BOARD)13P
< DIODE >
D501 8-719-911-19 DIODE 1SS119
D502 8-719-109-51 DIODE RD2.0ES-B2
D503 8-719-109-51 DIODE RD2.0ES-B2
D504 8-719-911-19 DIODE 1SS119
D505 8-719-911-19 DIODE 1SS119
D506 8-719-911-19 DIODE 1SS119
D545 8-719-911-19 DIODE 1SS119
D546 8-719-911-19 DIODE 1SS119
D547 8-719-911-19 DIODE 1SS119
D548 8-719-911-19 DIODE 1SS119
D549 8-719-911-19 DIODE 1SS119
D551 8-719-911-19 DIODE 1SS119
D552 8-719-109-51 DIODE RD2.0ES-B2
D553 8-719-109-51 DIODE RD2.0ES-B2
D554 8-719-911-19 DIODE 1SS119
D555 8-719-911-19 DIODE 1SS119
D556 8-719-911-19 DIODE 1SS119
D601 8-719-911-19 DIODE 1SS119
D602 8-719-109-51 DIODE RD2.0ES-B2
D603 8-719-109-51 DIODE RD2.0ES-B2
D604 8-719-911-19 DIODE 1SS119
D608 8-719-911-19 DIODE 1SS119
D801 8-719-302-37 DIODE RBV-602
D802 8-719-024-99 DIODE 11ES2-NTA2B
D803 8-719-024-99 DIODE 11ES2-NTA2B
D804 8-719-024-99 DIODE 11ES2-NTA2B
D805 8-719-024-99 DIODE 11ES2-NTA2B
D806 8-719-160-26 DIODE RD5.6F-B2
D807 8-719-934-22 DIODE HZS30-2L
< GROUND TERMINAL >
* EB701 1-537-738-21 TERMINAL, EARTH
* EB702 1-537-738-21 TERMINAL, EARTH
< FUSE >
! F801 1-532-506-51 FUSE, TIME-LAG (6.3A/250V)
! F802 1-532-506-51 FUSE, TIME-LAG (6.3A/250V)
! F803 1-532-504-51 FUSE, TIME-LAG (4A/250V)
! F804 1-532-504-51 FUSE, TIME-LAG (4A/250V)
< FUSE HOLDER >
FH801 1-533-293-11 FUSE HOLDER
FH802 1-533-293-11 FUSE HOLDER
FH803 1-533-293-11 FUSE HOLDER
FH804 1-533-293-11 FUSE HOLDER
FH851 1-533-293-11 FUSE HOLDER
FH852 1-533-293-11 FUSE HOLDER
FH853 1-533-293-11 FUSE HOLDER
FH854 1-533-293-11 FUSE HOLDER
< IC >
IC809 8-759-708-05 IC NJM78L05A
< COIL >
L501 1-411-906-11 COIL, AIR-CORE
L551 1-411-906-11 COIL, AIR-CORE
< TRANSISTOR >
Q504 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q508 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q509 8-729-281-53 TRANSISTOR 2SC1815-GR
Q510 8-729-900-63 TRANSISTOR DTA124ES
Q511 8-729-900-63 TRANSISTOR DTA124ES
Q546 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q547 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q548 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q549 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q554 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q558 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q559 8-729-281-53 TRANSISTOR 2SC1815-GR
Q560 8-729-900-63 TRANSISTOR DTA124ES
Q561 8-729-900-63 TRANSISTOR DTA124ES
Q596 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q601 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q604 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q608 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q613 8-729-281-53 TRANSISTOR 2SC1815-GR
Q616 8-729-900-36 TRANSISTOR DTC124ES
Q801 8-729-026-68 TRANSISTOR 2SD2525(TP)
< RESISTOR >
R521 1-249-422-11 CARBON 2.7K 5% 1/4W F
R522 1-249-433-11 CARBON 22K 5% 1/4W
R523 1-249-414-11 CARBON 560 5% 1/4W F
! R524 1-249-408-11 CARBON 180 5% 1/4W F
! R525 1-249-408-11 CARBON 180 5% 1/4W F
! R526 1-233-352-41 ENCAPSULATED COMPONENT
R527 1-247-850-11 CARBON 6.2K 5% 1/4W
R528 1-249-419-11 CARBON 1.5K 5% 1/4W F
R529 1-247-866-11 CARBON 30K 5% 1/4W
R530 1-249-422-11 CARBON 2.7K 5% 1/4W F
R531 1-249-433-11 CARBON 22K 5% 1/4W
R532 1-249-437-11 CARBON 47K 5% 1/4W
! R533 1-249-393-11 CARBON 10 5% 1/4W F
! R534 1-249-389-11 CARBON 4.7 5% 1/4W F
R535 1-249-431-11 CARBON 15K 5% 1/4W
AMP
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
