– 74 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R539 1-249-427-11 CARBON 6.8K 5% 1/4W F
R540 1-249-417-11 CARBON 1K 5% 1/4W F
R541 1-249-429-11 CARBON 10K 5% 1/4W
R542 1-249-429-11 CARBON 10K 5% 1/4W
R547 1-249-425-11 CARBON 4.7K 5% 1/4W F
R548 1-249-429-11 CARBON 10K 5% 1/4W
! R549 1-249-407-11 CARBON 150 5% 1/4W F
R555 1-247-881-00 CARBON 120K 5% 1/4W
R556 1-247-881-00 CARBON 120K 5% 1/4W
R571 1-249-422-11 CARBON 2.7K 5% 1/4W F
R572 1-249-433-11 CARBON 22K 5% 1/4W
R573 1-249-414-11 CARBON 560 5% 1/4W F
! R574 1-249-408-11 CARBON 180 5% 1/4W F
! R575 1-249-408-11 CARBON 180 5% 1/4W F
! R576 1-233-352-41 ENCAPSULATED COMPONENT
R577 1-247-850-11 CARBON 6.2K 5% 1/4W
R578 1-249-419-11 CARBON 1.5K 5% 1/4W F
R579 1-247-866-11 CARBON 30K 5% 1/4W
R580 1-249-422-11 CARBON 2.7K 5% 1/4W F
R581 1-249-433-11 CARBON 22K 5% 1/4W
R582 1-249-437-11 CARBON 47K 5% 1/4W
! R583 1-249-393-11 CARBON 10 5% 1/4W F
! R584 1-249-389-11 CARBON 4.7 5% 1/4W F
R585 1-249-431-11 CARBON 15K 5% 1/4W
R586 1-249-429-11 CARBON 10K 5% 1/4W
R587 1-249-425-11 CARBON 4.7K 5% 1/4W F
! R588 1-249-393-11 CARBON 10 5% 1/4W F
R621 1-249-422-11 CARBON 2.7K 5% 1/4W F
R622 1-247-880-00 CARBON 120K 5% 1/4W
! R623 1-249-414-11 CARBON 560 5% 1/4W F
! R624 1-249-408-11 CARBON 180 5% 1/4W F
! R625 1-249-408-11 CARBON 180 5% 1/4W F
! R626 1-233-352-41 ENCAPSULATED COMPONENT
R627 1-247-850-11 CARBON 6.2K 5% 1/4W
R628 1-249-419-11 CARBON 1.5K 5% 1/4W F
R632 1-249-437-11 CARBON 47K 5% 1/4W
R633 1-249-393-11 CARBON 10 5% 1/4W F
! R642 1-215-887-00 METAL OXIDE 470 5% 2W F
R643 1-249-441-11 CARBON 100K 5% 1/4W
R650 1-249-425-11 CARBON 4.7K 5% 1/4W F
R657 1-249-429-11 CARBON 10K 5% 1/4W
! R658 1-249-393-11 CARBON 10 5% 1/4W F
R672 1-249-433-11 CARBON 22K 5% 1/4W
! R739 1-215-868-00 METAL OXIDE 680 5% 1W F
! R789 1-215-868-00 METAL OXIDE 680 5% 1W F
R801 1-247-843-11 CARBON 3.3K 5% 1/4W
! R802 1-249-401-11 CARBON 47 5% 1/4W F
! RR48 1-249-393-11 CARBON 10 5% 1/4W F
! RR49 1-249-393-11 CARBON 10 5% 1/4W F
! RR98 1-249-393-11 CARBON 10 5% 1/4W F
! RR99 1-249-393-11 CARBON 10 5% 1/4W F
< RELAY >
RY501 1-515-920-11 RELAY (24V)
RY502 1-515-920-11 RELAY (24V)
RY602 1-515-793-11 RELAY
< TERMINAL >
TM501 1-694-429-21 TERMINAL BOARD (SP)(SPEAKERS FRONT)
**************************************************************
* 1-670-001-11 AUDIO BOARD
***********
< CAPACITOR >
C396 1-126-022-11 ELECT 47uF 20% 16V
C397 1-126-022-11 ELECT 47uF 20% 16V
C398 1-162-282-31 CERAMIC 100PF 10% 50V
C399 1-162-294-31 CERAMIC 0.001uF 10% 50V
CC08 1-162-282-31 CERAMIC 100PF 10% 50V
CC09 1-162-282-31 CERAMIC 100PF 10% 50V
CC10 1-162-282-31 CERAMIC 100PF 10% 50V
CC11 1-162-282-31 CERAMIC 100PF 10% 50V
CC12 1-162-282-31 CERAMIC 100PF 10% 50V
CC13 1-162-282-31 CERAMIC 100PF 10% 50V
CC58 1-162-282-31 CERAMIC 100PF 10% 50V
CC59 1-162-282-31 CERAMIC 100PF 10% 50V
CC60 1-162-282-31 CERAMIC 100PF 10% 50V
CC61 1-162-282-31 CERAMIC 100PF 10% 50V
CC62 1-162-282-31 CERAMIC 100PF 10% 50V
CC63 1-162-282-31 CERAMIC 100PF 10% 50V
< CONNECTOR >
CNJ701 1-774-136-11 CONNECTOR, ROUND TYPE 6P
CNS351 1-784-729-11 CONNECTOR, FFC 7P
< IC >
IC303 8-759-805-14 IC LC7822
< JACK >
J304 1-784-920-11 JACK, PIN 6P (VIDEO2 AUDIO IN/
VIDEO1 AUDIO OUT/VIDEO1 AUDIO IN)
J305 1-784-920-11 JACK, PIN 6P (TV/LD AUDIO IN/
DVD AUDIO IN/VIDEO2 AUDIO OUT)
< RESISTOR >
R315 1-249-417-11 CARBON 1K 5% 1/4W F
R316 1-249-417-11 CARBON 1K 5% 1/4W F
R317 1-249-417-11 CARBON 1K 5% 1/4W F
R318 1-249-417-11 CARBON 1K 5% 1/4W F
R319 1-249-417-11 CARBON 1K 5% 1/4W F
R320 1-249-417-11 CARBON 1K 5% 1/4W F
R365 1-249-417-11 CARBON 1K 5% 1/4W F
R366 1-249-417-11 CARBON 1K 5% 1/4W F
R367 1-249-417-11 CARBON 1K 5% 1/4W F
R368 1-249-417-11 CARBON 1K 5% 1/4W F
R369 1-249-417-11 CARBON 1K 5% 1/4W F
R370 1-249-417-11 CARBON 1K 5% 1/4W F
R394 1-249-397-11 CARBON 22 5% 1/4W F
R395 1-249-397-11 CARBON 22 5% 1/4W F
R398 1-249-417-11 CARBON 1K 5% 1/4W F
R399 1-249-425-11 CARBON 4.7K 5% 1/4W F
**************************************************************
AUDIO
AMP
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
