Sony STR-DB925 Service Manual

– 78 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R1249 1-216-073-00 METAL CHIP 10K 5% 1/10W
R1250 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1251 1-216-073-00 METAL CHIP 10K 5% 1/10W
R1252 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R1253 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R1254 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R1255 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R1256 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R1257 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R1258 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R1259 1-216-073-00 METAL CHIP 10K 5% 1/10W
R1260 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1261 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R1262 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R1263 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R1264 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R1265 1-216-049-91 RES,CHIP 1K 5% 1/10W
R1266 1-216-049-91 RES,CHIP 1K 5% 1/10W
R1267 1-216-073-00 METAL CHIP 10K 5% 1/10W
R1268 1-216-073-00 METAL CHIP 10K 5% 1/10W
R1269 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1270 1-216-025-91 RES,CHIP 100 5% 1/10W
R1271 1-216-073-00 METAL CHIP 10K 5% 1/10W
R1272 1-216-049-91 RES,CHIP 1K 5% 1/10W
R1273 1-216-073-00 METAL CHIP 10K 5% 1/10W
R1274 1-216-073-00 METAL CHIP 10K 5% 1/10W
R1275 1-216-025-91 RES,CHIP 100 5% 1/10W
R1276 1-216-025-91 RES,CHIP 100 5% 1/10W
R1277 1-216-025-91 RES,CHIP 100 5% 1/10W
R1278 1-216-025-91 RES,CHIP 100 5% 1/10W
R1279 1-216-025-91 RES,CHIP 100 5% 1/10W
R1280 1-216-025-91 RES,CHIP 100 5% 1/10W
R1281 1-216-295-91 SHORT 0
R1284 1-216-295-91 SHORT 0
R1285 1-216-073-00 METAL CHIP 10K 5% 1/10W
R1286 1-216-028-00 METAL CHIP 130 5% 1/10W
R1287 1-216-097-91 RES,CHIP 100K 5% 1/10W
R1301 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1302 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1303 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1304 1-216-025-91 RES,CHIP 100 5% 1/10W
R1305 1-216-025-91 RES,CHIP 100 5% 1/10W
R1306 1-216-041-00 METAL CHIP 470 5% 1/10W
R1307 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1308 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R1309 1-216-025-91 RES,CHIP 100 5% 1/10W
R1310 1-216-121-91 RES,CHIP 1M 5% 1/10W
R1311 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R1312 1-216-025-91 RES,CHIP 100 5% 1/10W
R1313 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R1314 1-216-295-91 SHORT 0
R1315 1-216-295-91 SHORT 0
R1316 1-216-295-91 SHORT 0
R1317 1-216-295-91 SHORT 0
R1318 1-216-295-91 SHORT 0
! R1319 1-215-884-11 METAL OXIDE 47 5% 2W F
R1320 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R1321 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R1322 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R1323 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R1324 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R1325 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R1326 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R1327 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R1328 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R1329 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R1330 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R1401 1-216-025-91 RES,CHIP 100 5% 1/10W
R1402 1-216-025-91 RES,CHIP 100 5% 1/10W
R1403 1-216-025-91 RES,CHIP 100 5% 1/10W
R1404 1-216-097-91 RES,CHIP 100K 5% 1/10W
R1405 1-216-025-91 RES,CHIP 100 5% 1/10W
R1406 1-216-073-00 METAL CHIP 10K 5% 1/10W
R1407 1-216-295-91 SHORT 0
R1408 1-216-025-91 RES,CHIP 100 5% 1/10W
R1409 1-216-025-91 RES,CHIP 100 5% 1/10W
R1410 1-216-295-91 SHORT 0
< VIBRATOR >
X1101 1-567-970-11 VIBRATOR, CRYSTAL (24.576MHz)
X1201 1-577-082-11 VIBRATOR, CERAMIC (4MHz)
X1301 1-767-949-21 VIBRATOR, CERAMIC (49.152MHz)
**************************************************************
* A-4414-097-A DISPLAY BOARD, COMPLETE
***********************
* 4-921-941-01 CUSHION (FL)
* 4-990-797-01 HOLDER (FL)
< CAPACITOR >
C101 1-126-786-11 ELECT 47uF 20% 16V
C102 1-162-306-11 CERAMIC 0.01uF 20% 16V
C103 1-162-306-11 CERAMIC 0.01uF 20% 16V
C104 1-126-795-11 ELECT 10uF 20% 50V
C105 1-104-905-11 CAPACITOR 0.22F 5.5V
C106 1-164-159-11 CERAMIC 0.1uF 50V
C107 1-164-159-11 CERAMIC 0.1uF 50V
C108 1-164-159-11 CERAMIC 0.1uF 50V
C109 1-164-159-11 CERAMIC 0.1uF 50V
C110 1-164-159-11 CERAMIC 0.1uF 50V
C111 1-164-159-11 CERAMIC 0.1uF 50V
C112 1-164-159-11 CERAMIC 0.1uF 50V
C115 1-164-159-11 CERAMIC 0.1uF 50V
C117 1-164-159-11 CERAMIC 0.1uF 50V
C119 1-126-786-11 ELECT 47uF 20% 16V
C121 1-126-786-11 ELECT 47uF 20% 16V
C123 1-164-159-11 CERAMIC 0.1uF 50V
C124 1-162-294-11 CERAMIC 1000PF 10% 50V
C180 1-164-159-11 CERAMIC 0.1uF 50V
C181 1-136-177-00 CERAMIC 0.1uF 5% 50V
C182 1-164-159-11 CERAMIC 0.1uF 50V
C183 1-126-916-11 ELECT 1000uF 20% 6.3V
C184 1-126-795-11 ELECT 10uF 20% 50V
DISPLAY
DIGITAL
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
