Sony STR-DB925 Service Manual

– 79 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C185 1-162-306-11 CERAMIC 0.01uF 20% 16V
C186 1-162-306-11 CERAMIC 0.01uF 20% 16V
C191 1-164-159-11 CERAMIC 0.1uF 50V
C192 1-107-818-11 ELECT 1uF 5.5V
< CONNECTOR >
CNP105 1-564-510-11 PLUG, CONNECTOR 7P
CNP109 1-784-919-11 CONNECTOR, PC BOARD (PLUG) 5P
CNP110 1-784-919-11 CONNECTOR, PC BOARD (PLUG) 5P
CNS102 1-770-553-11 CONNECTOR, BOARD TO BOARD 11P
CNS103 1-784-772-11 CONNECTOR, FFC 11P
CNS104 1-784-743-11 CONNECTOR, FFC 21P
CNS107 1-770-397-11 HOUSING, CONNECTOR(PC BOARD)4P
CNS108 1-770-553-11 CONNECTOR, BOARD TO BOARD 11P
< DIODE >
D102 8-719-024-99 DIODE 11ES2-NTA2B
D103 8-719-911-19 DIODE 1SS119
D108 8-719-046-39 DIODE SEL5821A-TH15 (SOUND FIELD)
D109 8-719-313-45 DIODE SEL6810A-TH10 (VIDEO1)
D110 8-719-313-45 DIODE SEL6810A-TH10 (VIDEO2)
D111 8-719-313-45 DIODE SEL6810A-TH10 (VIDEO3)
D112 8-719-313-45 DIODE SEL6810A-TH10 (DVD)
D113 8-719-313-45 DIODE SEL6810A-TH10 (TV/LD)
D114 8-719-313-45 DIODE SEL6810A-TH10 (TAPE)
D115 8-719-313-45 DIODE SEL6810A-TH10 (MD/DAT)
D116 8-719-313-45 DIODE SEL6810A-TH10 (CD)
D117 8-719-313-45 DIODE SEL6810A-TH10 (TUNER)
D118 8-719-313-45 DIODE SEL6810A-TH10 (PHONO)
D119 8-719-046-39 DIODE SEL5821A-TH15 (BASS BOOST)
D122 8-719-046-39 DIODE SEL5821A-TH15 (EQ)
D180 8-719-911-19 DIODE 1SS119
D181 8-719-911-19 DIODE 1SS119
D182 8-719-911-19 DIODE 1SS119
D183 8-719-911-19 DIODE 1SS119
D184 8-719-059-14 DIODE SID313BP-TP19
D185 8-719-059-14 DIODE SID313BP-TP19
D186 8-719-059-14 DIODE SID313BP-TP19
< FLUORESCENT INDICATOR >
FL101 1-517-781-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC101 8-759-459-83 IC NJL55H400A
IC102 8-759-535-50 IC MB90553PF-G-121-BND
IC103 8-759-962-08 IC BA6208
IC104 8-759-463-11 IC MSC1162AGS-BK
IC105 8-759-389-51 IC MSC1164GS-KR1
IC180 8-759-927-72 IC TL1591CP
IC181 8-759-545-07 IC TMP87C447U-4A06
< COIL >
L101 1-410-509-11 INDUCTOR 10uH
L150 1-408-080-00 INDUCTOR 100uH
< TRANSISTOR >
Q101 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q102 8-729-900-36 TRANSISTOR DTC124ES
Q103 8-729-900-36 TRANSISTOR DTC124ES
Q104 8-729-900-36 TRANSISTOR DTC124ES
Q105 8-729-900-36 TRANSISTOR DTC124ES
Q106 8-729-900-36 TRANSISTOR DTC124ES
Q107 8-729-900-36 TRANSISTOR DTC124ES
Q108 8-729-900-36 TRANSISTOR DTC124ES
Q109 8-729-900-36 TRANSISTOR DTC124ES
Q110 8-729-900-36 TRANSISTOR DTC124ES
Q111 8-729-900-36 TRANSISTOR DTC124ES
Q112 8-729-900-36 TRANSISTOR DTC124ES
Q113 8-729-900-36 TRANSISTOR DTC124ES
Q114 8-729-900-36 TRANSISTOR DTC124ES
Q115 8-729-900-36 TRANSISTOR DTC124ES
Q116 8-729-900-36 TRANSISTOR DTC124ES
Q117 8-729-900-36 TRANSISTOR DTC124ES
Q118 8-729-900-36 TRANSISTOR DTC124ES
Q119 8-729-900-36 TRANSISTOR DTC124ES
Q120 8-729-900-36 TRANSISTOR DTC124ES
Q122 8-729-900-36 TRANSISTOR DTC124ES
Q180 8-729-620-05 TRANSISTOR 2SC2603-EF
Q181 8-729-900-36 TRANSISTOR DTC124ES
Q182 8-729-620-05 TRANSISTOR 2SC2603-EF
Q184 8-729-801-93 TRANSISTOR 2SD1387
Q185 8-729-801-93 TRANSISTOR 2SD1387
< RESISTOR >
R103 1-249-437-11 CARBON 47K 5% 1/4W
R104 1-249-429-11 CARBON 10K 5% 1/4W
R105 1-249-393-11 CARBON 10 5% 1/4W F
R106 1-249-437-11 CARBON 47K 5% 1/4W
R107 1-249-433-11 CARBON 22K 5% 1/4W
R108 1-249-441-11 CARBON 100K 5% 1/4W
R109 1-249-441-11 CARBON 100K 5% 1/4W
R111 1-247-772-00 CARBON 3.6 5% 1/4W
R114 1-249-419-11 CARBON 1.5K 5% 1/4W F
R115 1-249-385-11 CARBON 2.2 5% 1/6W F
R116 1-249-429-11 CARBON 10K 5% 1/4W
R117 1-249-433-11 CARBON 22K 5% 1/4W
R118 1-249-433-11 CARBON 22K 5% 1/4W
R119 1-249-417-11 CARBON 1K 5% 1/4W F
R120 1-249-417-11 CARBON 1K 5% 1/4W F
R121 1-249-417-11 CARBON 1K 5% 1/4W F
R122 1-249-429-11 CARBON 10K 5% 1/4W
R123 1-249-417-11 CARBON 1K 5% 1/4W F
R125 1-249-425-11 CARBON 4.7K 5% 1/4W F
R126 1-249-425-11 CARBON 4.7K 5% 1/4W F
R127 1-249-425-11 CARBON 4.7K 5% 1/4W F
R128 1-249-425-11 CARBON 4.7K 5% 1/4W F
R129 1-249-417-11 CARBON 1K 5% 1/4W F
R130 1-249-425-11 CARBON 4.7K 5% 1/4W F
R131 1-249-425-11 CARBON 4.7K 5% 1/4W F
R132 1-249-425-11 CARBON 4.7K 5% 1/4W F
R133 1-249-411-11 CARBON 330 5% 1/4W
DISPLAY
