– 80 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
F-VIDEO
R134 1-249-411-11 CARBON 330 5% 1/4W
R135 1-249-411-11 CARBON 330 5% 1/4W
R161 1-249-385-11 CARBON 2.2 5% 1/6W F
R162 1-249-421-11 CARBON 2.2K 5% 1/4W F
R163 1-249-421-11 CARBON 2.2K 5% 1/4W F
R164 1-249-411-11 CARBON 330 5% 1/4W
R165 1-249-429-11 CARBON 10K 5% 1/4W
R179 1-249-411-11 CARBON 330 5% 1/4W
R180 1-249-393-11 CARBON 10 5% 1/4W F
R181 1-249-429-11 CARBON 10K 5% 1/4W
R182 1-249-425-11 CARBON 4.7K 5% 1/4W F
R183 1-249-429-11 CARBON 10K 5% 1/4W
R184 1-249-429-11 CARBON 10K 5% 1/4W
R185 1-249-425-11 CARBON 4.7K 5% 1/4W F
R186 1-249-429-11 CARBON 10K 5% 1/4W
R187 1-249-417-11 CARBON 1K 5% 1/4W F
R188 1-249-429-11 CARBON 10K 5% 1/4W
R189 1-247-772-00 CARBON 3.6 5% 1/4W
R190 1-249-441-11 CARBON 100K 5% 1/4W
R191 1-247-807-31 CARBON 100 5% 1/4W
R192 1-249-383-11 CARBON 1.5 5% 1/6W F
R193 1-247-807-31 CARBON 100 5% 1/4W
R194 1-247-807-31 CARBON 100 5% 1/4W
R195 1-247-807-31 CARBON 100 5% 1/4W
R196 1-247-807-31 CARBON 100 5% 1/4W
R197 1-249-441-11 CARBON 100K 5% 1/4W
R198 1-249-429-11 CARBON 10K 5% 1/4W
R199 1-249-429-11 CARBON 10K 5% 1/4W
RR24 1-249-429-11 CARBON 10K 5% 1/4W
< VIBRATOR >
X101 1-577-082-11 VIBRATOR, CERAMIC (4MHz)
X180 1-767-938-21 VIBRATOR, CERAMIC (7.28MHz)
**************************************************************
* 1-670-021-11 F-VIDEO BOARD
*************
< CAPACITOR >
C299 1-164-159-11 CERAMIC 0.1uF 50V
CC14 1-162-282-31 CERAMIC 100PF 10% 50V
CC64 1-162-282-31 CERAMIC 100PF 10% 50V
< CONNECTOR >
CNP307 1-564-723-11 PIN, CONNECTOR (SMALL TYPE) 7P
< GROUND TERMINAL >
* EB201 1-537-738-21 TERMINAL, EARTH
< JACK >
J298 1-784-808-11 TERMINAL, S (VIDEO 3 INPUT S-VIDEO)
J299 1-779-798-11 JACK, PIN (BLOCK) (L TYPE) 3P
(VIDEO 3 INPUT AUDIO/VIDEO)
< RESISTOR >
R297 1-247-804-11 CARBON 75 5% 1/4W
R298 1-247-804-11 CARBON 75 5% 1/4W
R299 1-247-804-11 CARBON 75 5% 1/4W
R321 1-249-417-11 CARBON 1K 5% 1/4W F
R371 1-249-417-11 CARBON 1K 5% 1/4W F
**************************************************************
* 1-670-006-11 H.P BOARD
*********
< JACK >
J701 1-568-519-41 JACK, LARGE TYPE (PHONES)
**************************************************************
* A-4414-095-A INPUT BOARD, COMPLETE
*********************
< CAPACITOR >
C301 1-126-045-11 ELECT 2.2uF 20% 50V
C303 1-126-101-11 ELECT 100uF 20% 16V
C304 1-125-896-91 MYLAR 0.0091uF 5% 50V
C305 1-136-159-00 FILM 0.033uF 5% 50V
C306 1-126-045-11 ELECT 2.2uF 20% 50V
C307 1-162-282-31 CERAMIC 100PF 10% 50V
C308 1-162-286-31 CERAMIC 220PF 10% 50V
C310 1-162-294-31 CERAMIC 0.001uF 10% 50V
C311 1-126-233-11 ELECT 22uF 20% 50V
C351 1-126-045-11 ELECT 2.2uF 20% 50V
C353 1-126-101-11 ELECT 100uF 20% 16V
C354 1-125-896-91 MYLAR 0.0091uF 5% 50V
C355 1-136-159-00 FILM 0.033uF 5% 50V
C356 1-126-045-11 ELECT 2.2uF 20% 50V
C357 1-162-282-31 CERAMIC 100PF 10% 50V
C358 1-162-286-31 CERAMIC 220PF 10% 50V
C360 1-162-294-31 CERAMIC 0.001uF 10% 50V
C361 1-126-233-11 ELECT 22uF 20% 50V
C387 1-126-022-11 ELECT 47uF 20% 16V
C388 1-126-052-11 ELECT 100uF 20% 16V
C389 1-126-052-11 ELECT 100uF 20% 16V
C392 1-126-022-11 ELECT 47uF 20% 16V
C393 1-162-294-31 CERAMIC 0.001uF 10% 50V
C394 1-126-022-11 ELECT 47uF 20% 16V
C395 1-162-282-31 CERAMIC 100PF 10% 50V
C396 1-126-022-11 ELECT 47uF 20% 16V
C398 1-162-294-31 CERAMIC 0.001uF 10% 50V
C399 1-162-282-31 CERAMIC 100PF 10% 50V
C401 1-126-233-11 ELECT 22uF 20% 50V
C402 1-126-233-11 ELECT 22uF 20% 50V
C403 1-126-233-11 ELECT 22uF 20% 50V
C404 1-162-199-31 CERAMIC 10PF 5% 50V
C405 1-162-199-31 CERAMIC 10PF 5% 50V
C406 1-162-199-31 CERAMIC 10PF 5% 50V
C407 1-126-233-11 ELECT 22uF 20% 50V
C408 1-126-233-11 ELECT 22uF 20% 50V
C409 1-126-233-11 ELECT 22uF 20% 50V
H.PDISPLAY INPUT
