Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
ROTARY
< CONNECTOR >
CNP803 1-564-320-00 PIN, CONNECTOR (B2P-VH) 2P
CNP809 1-779-977-11 PIN, CONNECTOR 6P
< DIODE >
D808 8-719-025-03 DIODE RBA-402-SL
D901 8-719-024-99 DIODE 11ES2-NTA2B
D902 8-719-024-99 DIODE 11ES2-NTA2B
D903 8-719-024-99 DIODE 11ES2-NTA2B
D904 8-719-024-99 DIODE 11ES2-NTA2B
D905 8-719-911-19 DIODE 1SS119
D906 8-719-911-19 DIODE 1SS119
< GROUND TERMINAL >
* EB900 1-537-738-21 TERMINAL, EARTH
< FUSE >
! F805 1-532-504-51 FUSE, TIME-LAG (4A/250V)
< FUSE HOLDER >
FH805 1-533-399-31 HOLDER, FUSE
FH855 1-533-399-31 HOLDER, FUSE
< IC >
IC801 8-759-231-53 IC TA7805S
IC802 8-759-445-59 IC BA033T
IC803 8-759-445-59 IC BA033T
IC901 8-759-333-83 IC NJM2103D
< TRANSISTOR >
Q901 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q902 8-729-026-68 TRANSISTOR 2SD2525(TP)
< RESISTOR >
R902 1-249-429-11 CARBON 10K 5% 1/4W
R903 1-249-425-11 CARBON 4.7K 5% 1/4W F
R904 1-249-417-11 CARBON 1K 5% 1/4W F
R905 1-249-428-11 CARBON 8.2K 5% 1/4W F
R906 1-249-421-11 CARBON 2.2K 5% 1/4W F
R908 1-249-433-11 CARBON 22K 5% 1/4W
R909 1-249-439-11 CARBON 68K 5% 1/4W
R910 1-249-437-11 CARBON 47K 5% 1/4W
R912 1-249-430-11 CARBON 12K 5% 1/4W
**************************************************************
* 1-670-023-11 ROTARY BOARD
************
< CONNECTOR >
CNS101 1-770-404-11 HOUSING,CONNECTOR(PC BOARD)11P
< DIODE >
D101 8-719-313-45 DIODE SEL6810A-TH10
< RESISTOR >
R101 1-249-411-11 CARBON 330 5% 1/4W
R102 1-249-411-11 CARBON 330 5% 1/4W
< VARIABLE RESISTOR >
RV101 1-467-808-11 ENCODER, ROTARY (FUNCTION)
< SWITCH >
S101 1-762-751-11 SWITCH, TACTILE (MODE)
S102 1-762-751-11 SWITCH, TACTILE (MUTING)
**************************************************************
* 1-670-004-11 S-VIDEO BOARD
*************
< CAPACITOR >
C251 1-136-165-00 FILM 0.1uF 5% 50V
C252 1-136-165-00 FILM 0.1uF 5% 50V
C253 1-126-964-11 ELECT 10uF 20% 50V
C254 1-136-165-00 FILM 0.1uF 5% 50V
C255 1-136-165-00 FILM 0.1uF 5% 50V
C256 1-126-964-11 ELECT 10uF 20% 50V
C257 1-136-165-00 FILM 0.1uF 5% 50V
C258 1-126-964-11 ELECT 10uF 20% 50V
C259 1-126-964-11 ELECT 10uF 20% 50V
C260 1-136-165-00 FILM 0.1uF 5% 50V
C261 1-104-664-11 ELECT 47uF 20% 16V
C262 1-164-159-11 CERAMIC 0.1uF 50V
C263 1-164-159-11 CERAMIC 0.1uF 50V
C264 1-104-664-11 ELECT 47uF 20% 16V
C265 1-164-159-11 CERAMIC 0.1uF 50V
C266 1-164-159-11 CERAMIC 0.1uF 50V
C267 1-162-290-31 CERAMIC 470PF 10% 50V
C268 1-162-290-31 CERAMIC 470PF 10% 50V
C269 1-162-290-31 CERAMIC 470PF 10% 50V
C270 1-162-290-31 CERAMIC 470PF 10% 50V
< CONNECTOR >
CNS251 1-784-770-11 CONNECTOR, FFC 9P
< DIODE >
D251 8-719-911-19 DIODE 1SS119
D252 8-719-911-19 DIODE 1SS119
< IC >
IC251 8-759-529-20 IC NJM2296D
IC252 8-759-529-20 IC NJM2296D
< JACK >
J251 1-537-943-11 TERMINAL, S (MONITOR S-VIDEO OUT)
J252 1-764-676-11 CONNECTOR (ROUND TYPE)
(VIDEO1 S-VIDEO OUT/VIDEO1 S-VIDEO IN)
J253 1-764-676-11 CONNECTOR (ROUND TYPE)
(TV/LD S-VIDEO IN/DVD S-VIDEO IN)
REG
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
S-VIDEO
