Sony STR-DE597 - Electrical Parts List

44
STR-DE597
SECTION 6
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
AC SELECT BOARD (E2)
****************
< CONNECTOR >
* CNP910 1-564-687-11 PIN, CONNECTOR (3.96mm PITCH) 3P (E2)
< SWITCH >
0S901 1-571-437-21 SWITCH, POWER VOLTAGE CHANGE
(VOLTAGE SELECTOR) (E2)
*************************************************************
BRIDGEABLE BOARD
*****************
< CONNECTOR >
* CN906 1-564-104-00 PIN, CONNECTOR (3.96mm PITCH) 3P
* CN908 1-564-242-00 PIN, CONNECTOR (3.96mm PITCH) 5P
< DIODE >
D818 8-719-991-33 DIODE 1SS133T-77
< TRANSISTOR >
Q809 8-729-119-79 TRANSISTOR 2SC2785-FEK
< RESISTOR >
R824 1-247-847-11 CARBON 4.7K 5% 1/4W
R830 1-249-404-00 CARBON 82 5% 1/4W
R831 1-249-404-00 CARBON 82 5% 1/4W
(CND)
< RELAY >
RY801 1-755-013-11 RELAY (EXCEPT CND)
RY802 1-755-494-11 RELAY (CND)
RY803 1-755-494-11 RELAY (CND)
*************************************************************
A-4750-663-A DIGITAL BOARD, COMPLETE (US,CND)
A-4750-722-A DIGITAL BOARD, COMPLETE (AEP,UK)
A-4750-809-A DIGITAL BOARD, COMPLETE (SP,MY)
A-4750-834-A DIGITAL BOARD, COMPLETE (AUS)
A-4750-840-A DIGITAL BOARD, COMPLETE (E2)
A-4752-713-A DIGITAL BOARD, COMPLETE (KR)
A-4753-052-A DIGITAL BOARD, COMPLETE (AR)
***********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C1001 1-126-925-11 ELECT 470uF 20% 10V
C1002 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1003 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
(US,CND,E2)
C1003 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
(EXCEPT US,CND,E2)
C1021 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1022 1-126-925-11 ELECT 470uF 20% 10V
C1031 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1032 1-126-925-11 ELECT 470uF 20% 10V
C1063 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(AEP,UK)
C1064 1-126-204-11 ELECT CHIP 47uF 20% 16V
(AEP,UK)
C1100 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1102 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1103 1-126-204-11 ELECT CHIP 47uF 20% 16V
C1107 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1108 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1118 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1119 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1120 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1121 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1122 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1123 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1124 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1126 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C1129 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1130 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1137 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1138 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1139 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1140 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1141 1-164-156-11 CERAMIC CHIP 0.1uF 25V
DIGITAL
•Abbreviation
CND : Canadian model
E2 : AC 120 V area in E model
AUS: Australian model
SP : Singapore model
MY : Malaysia model
AR : Argentina model
KR : Korea model
BRIDGEABLE
AC SELECT
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
When indicating parts by reference
number, please include the board.
