50
STR-DE597
Ref. No. Part No. Description Remark
R175 1-249-393-11 CARBON 10 5% 1/4W
R198 1-249-381-11 CARBON 1 5% 1/4W
R199 1-249-381-11 CARBON 1 5% 1/4W
< ROTARY ENCODER >
RV102 1-418-725-41 ENCODER, ROTARY (12 TYPE)
(MASTER VOLUME)
< SWITCH >
S100 1-771-410-21 SWITCH, TACTILE (>)
S101 1-771-410-21 SWITCH, TACTILE (INPUT MODE)
S103 1-771-410-21 SWITCH, TACTILE (DVD)
S105 1-771-410-21 SWITCH, TACTILE (MD/TAPE)
S107 1-771-410-21 SWITCH, TACTILE (SA-CD/CD)
S109 1-771-410-21 SWITCH, TACTILE (TUNER FM/AM)
S110 1-771-410-21 SWITCH, TACTILE (MAIN MENU)
S111 1-771-410-21 SWITCH, TACTILE (ENTER)
S112 1-771-410-21 SWITCH, TACTILE (<)
S113 1-771-410-21 SWITCH, TACTILE (+)
S120 1-771-410-21 SWITCH, TACTILE (SURR BACK DECODING)
S121 1-771-410-21 SWITCH, TACTILE (MUSIC)
S122 1-771-410-21 SWITCH, TACTILE (MOVIE)
S123 1-771-410-21 SWITCH, TACTILE (A.F.D.)
S124 1-771-410-21 SWITCH, TACTILE (2CH)
S125 1-771-410-21 SWITCH, TACTILE (MULTI CH IN)
S130 1-771-410-21 SWITCH, TACTILE (–)
S132 1-771-410-21 SWITCH, TACTILE (VIDEO 2)
S134 1-771-410-21 SWITCH, TACTILE (VIDEO 1)
*************************************************************
HEADPHONE BOARD
*****************
< CAPACITOR >
C790 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CNP791 1-691-766-11 PLUG (MICRO CONNECTOR) 4P
< JACK >
J791 1-815-313-21 JACK (PHONES) (GOLD)...(GOLD)
J791 1-815-314-21 JACK (PHONES) (SILVER)...(BLACK,SILVER)
*************************************************************
A-4750-642-A MAIN BOARD, COMPLETE (US,CND,E2)
A-4750-713-A MAIN BOARD, COMPLETE (EXCEPT US,CND,E2)
*********************
< CAPACITOR >
C300 1-161-494-00 CERAMIC 0.022uF 25V
C310 1-161-494-00 CERAMIC 0.022uF 25V
C320 1-161-494-00 CERAMIC 0.022uF 25V
C330 1-161-494-00 CERAMIC 0.022uF 25V
C340 1-161-494-00 CERAMIC 0.022uF 25V
C350 1-161-494-00 CERAMIC 0.022uF 25V
C360 1-161-494-00 CERAMIC 0.022uF 25V
C400 1-128-825-11 CERAMIC 0.0022uF 5% 50V
C403 1-128-825-11 CERAMIC 0.0022uF 5% 50V
C408 1-126-963-11 ELECT 4.7uF 20% 50V
C409 1-126-963-11 ELECT 4.7uF 20% 50V
C444 1-128-825-11 CERAMIC 0.0022uF 5% 50V
C445 1-128-825-11 CERAMIC 0.0022uF 5% 50V
C458 1-126-963-11 ELECT 4.7uF 20% 50V
C459 1-126-963-11 ELECT 4.7uF 20% 50V
C464 1-164-159-11 CERAMIC 0.1uF 50V
C466 1-126-923-11 ELECT 220uF 20% 10V
C467 1-164-159-11 CERAMIC 0.1uF 50V
C468 1-128-809-11 CERAMIC 100PF 5% 50V
C469 1-128-809-11 CERAMIC 100PF 5% 50V
C470 1-128-809-11 CERAMIC 100PF 5% 50V
C471 1-126-963-11 ELECT 4.7uF 20% 50V
C472 1-126-963-11 ELECT 4.7uF 20% 50V
C481 1-126-963-11 ELECT 4.7uF 20% 50V
C482 1-126-963-11 ELECT 4.7uF 20% 50V
C483 1-126-963-11 ELECT 4.7uF 20% 50V
C484 1-126-963-11 ELECT 4.7uF 20% 50V
C485 1-126-963-11 ELECT 4.7uF 20% 50V
C486 1-126-963-11 ELECT 4.7uF 20% 50V
C488 1-164-159-11 CERAMIC 0.1uF 50V
C489 1-126-963-11 ELECT 4.7uF 20% 50V
C490 1-126-963-11 ELECT 4.7uF 20% 50V
C491 1-126-963-11 ELECT 4.7uF 20% 50V
C492 1-126-963-11 ELECT 4.7uF 20% 50V
C493 1-126-963-11 ELECT 4.7uF 20% 50V
C494 1-126-963-11 ELECT 4.7uF 20% 50V
C495 1-126-963-11 ELECT 4.7uF 20% 50V
C496 1-126-963-11 ELECT 4.7uF 20% 50V
C499 1-162-211-31 CERAMIC 33PF 5% 50V
C501 1-126-963-11 ELECT 4.7uF 20% 50V
C503 1-104-658-11 ELECT 100uF 20% 10V
C504 1-107-583-11 CERAMIC 3PF 0.25PF 500V
C505 1-102-978-00 CERAMIC 220PF 5% 50V
C506 1-107-616-11 CERAMIC 150PF 5% 500V
C507 1-128-809-11 CERAMIC 100PF 5% 50V
C510 1-126-947-11 ELECT 47uF 20% 35V
C511 1-136-157-00 FILM 0.022uF 5% 50V
C516 1-162-815-11 CERAMIC 47PF 5% 500V
C517 1-162-815-11 CERAMIC 47PF 5% 500V
C519 1-128-813-11 CERAMIC 220PF 5% 50V
C540 1-126-964-11 ELECT 10uF 20% 50V
C541 1-127-876-11 CERAMIC 0.01uF 10% 50V
C601 1-126-963-11 ELECT 4.7uF 20% 50V
C603 1-104-658-11 ELECT 100uF 20% 10V
C604 1-107-583-11 CERAMIC 3PF 0.25PF 500V
C605 1-102-233-00 CERAMIC 33PF 10% 500V
C606 1-128-809-11 CERAMIC 100PF 5% 50V
C607 1-128-809-11 CERAMIC 100PF 5% 50V
C610 1-126-947-11 ELECT 47uF 20% 35V
C611 1-136-157-00 FILM 0.022uF 5% 50V
C619 1-128-813-11 CERAMIC 220PF 5% 50V
C620 1-162-815-11 CERAMIC 47PF 5% 500V
C621 1-162-815-11 CERAMIC 47PF 5% 500V
C640 1-126-964-11 ELECT 10uF 20% 50V
C642 1-127-876-11 CERAMIC 0.01uF 10% 50V
C651 1-126-963-11 ELECT 4.7uF 20% 50V
C653 1-104-658-11 ELECT 100uF 20% 10V
C654 1-107-583-11 CERAMIC 3PF 0.25PF 500V
Ref. No. Part No. Description Remark
DISPLAY HEADPHONE MAIN
