38
STR-DE875/DE975
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
51 4-232-237-01 FOOT (DIA. 30)
52 4-233-263-01 SUB MOLD (DE9)
53 A-4476-056-A MAIN BOARD, COMPLETE (DE975:US)
53 A-4476-158-A MAIN BOARD, COMPLETE (DE875:US)
53 A-4476-165-A MAIN BOARD, COMPLETE (DE875:CND)
53 A-4476-168-A MAIN BOARD, COMPLETE
(DE875:AEP,UK,E,MY,SP,CH,AUS)
53 A-4476-186-A MAIN BOARD, COMPLETE (DE975:CND)
54 3-905-609-01 SCREW (TRANSISTOR)
55 4-232-574-01 BOARD HOLDER
56 A-4476-069-A VIDEO BOARD, COMPLETE (DE975)
56 A-4476-162-A VIDEO BOARD, COMPLETE (DE875)
57 1-773-007-11 WIRE (FLAT TYPE) (15 CORE) (DE875)
57 1-773-041-11 WIRE (FLAT TYPE) (17 CORE) (DE975)
58 A-4476-062-A DIGITAL BOARD, COMPLETE (DE975:US)
58 A-4476-163-A DIGITAL BOARD, COMPLETE (DE875:US)
58 A-4476-166-A DIGITAL BOARD, COMPLETE (DE875:CND)
58 A-4476-171-A DIGITAL BOARD, COMPLETE (DE875:AUS)
58 A-4476-175-A DIGITAL BOARD, COMPLETE (DE875:MY,SP,CH)
58 A-4476-180-A DIGITAL BOARD, COMPLETE (DE875:E)
58 A-4476-187-A DIGITAL BOARD, COMPLETE (DE975:CND)
58 A-4476-189-A DIGITAL BOARD, COMPLETE (DE875:AEP,UK)
59 1-693-539-21 TUNER UNIT (DE875:US,CND/DE975)
59 1-693-540-21 TUNER UNIT (DE875:AEP,UK,E,MY,SP,CH,AUS)
60 1-773-002-11 WIRE (FLAT TYPE) (15 CORE)
61 1-769-907-11 WIRE (FLAT TYPE) (9 CORE) (DE875)
61 1-773-004-11 WIRE (FLAT TYPE) (15 CORE) (DE975)
62 A-4476-058-A S-VIDEO BOARD, COMPLETE (DE975)
62 A-4476-159-A S-VIDEO BOARD, COMPLETE
(DE875:US,CND,E)
62 A-4476-776-A S-VIDEO BOARD, COMPLETE
(DE875:AEP,UK,MY,SP,CH,AUS)
63 A-4476-072-A STANDBY BOARD, COMPLETE
(DE875:US,CND/DE975)
63 A-4476-170-A STANDBY BAORD, COMPLETE (DE875:AUS)
63 A-4476-174-A STANDBY BOARD, COMPLETE
(DE875:AEP,UK,MY,SP)
63 A-4476-177-A STANDBY BOARD, COMPLETE (DE875:CH)
63 A-4476-179-A STANDBY BOARD, COMPLETE (DE875:E)
64 1-680-597-11 SPEAKER BOARD
* 65 3-703-244-00 BUSHING (2104), CORD
66 4-232-578-01 BACK PANEL (DE9)(DE975:US)
66 4-232-578-11 BACK PANEL (DE9)(DE975:CND)
66 4-233-045-01 BACK PANEL (DE8)(DE875:US)
66 4-233-045-11 BACK PANEL (DE8)(DE875:CND)
66 4-233-045-21 BACK PANEL (DE8)(DE875:AUS)
66 4-233-045-31 BACK PANEL (DE8)(DE875:MY,SP)
66 4-233-045-41 BACK PANEL (DE8)(DE875:CH)
66 4-233-045-51 BACK PANEL (DE8)(DE875:E)
66 4-233-045-61 BACK PANEL (DE8)(DE875:AEP)
66 4-233-045-71 BACK PANEL (DE8)(DE875:UK)
67 4-956-370-02 BAND, PLUG FIXED (DE875:AUS,UK)
0 68 1-696-847-11 CORD, POWER (DE875:AUS)
0 68 1-777-071-21 CORD, POWER (DE875:AEP,UK,E,MY,SP)
0 68 1-783-205-11 CORD, POWER (DE875:CH)
0 68 1-783-820-11 CORD, POWER (DE875:CND,US/DE975)
69 X-4953-448-1 FOOT ASSY
70 3-701-748-00 CLAMP
0 71 1-569-008-21 ADAPTOR, CONVERSION 2P (DE875:E)
72 1-680-590-11 2ND AUDIO BOARD (DE975)
73 1-680-589-11 AC SELECT BOARD (DE875:E)
0 T901 1-435-944-11 POWER TRANSFORMER (DE875:E)
0 T901 1-435-942-11 TRANSFORMER, POWER
(DE875:AEP,UK,MY,SP,CH)
0 T901 1-435-943-11 TRANSFORMER, POWER (DE875:AUS)
0 T901 1-435-945-11 TRANSFORMER, POWER(DE875:US/DE975:US)
0 T901 1-435-946-11 TRANSFORMER, POWER
(DE875:CND/DE975:CND)
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
#2 7-685-645-79 SCREW +BVTP 3X6 TYPE2 N-S
#3 7-685-880-09 SCREW +BVTT 4X6 (S)
#4 7-685-871-01 SCREW +BVTT 3X6 (S)
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
