Sony STR-DE875 - Electrical Parts List; 2 nd Audio and AC Select Board Parts

39
SECTION 5
ELECTRICAL PARTS LIST
STR-DE875/DE975
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
• Abbreviation
CND : Canadian model
MY : Malaysia model
SP : Singapore model
CH : Chinese model
AUS : Australian model
When indicating parts by reference number,
please include the board name.
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
1-680-590-11 2ND AUDIO BOARD (DE975)
***************
< CAPACITOR >
C711 1-126-965-11 ELECT 22uF 20.00% 50V
(DE975)
C712 1-126-965-11 ELECT 22uF 20.00% 50V
(DE975)
C713 1-127-880-11 CERAMIC 0.022uF 10% 50V
(DE975)
C714 1-127-880-11 CERAMIC 0.022uF 10% 50V
(DE975)
C715 1-164-159-11 CERAMIC 0.1uF 50V
(DE975)
C761 1-126-965-11 ELECT 22uF 20.00% 50V
(DE975)
C762 1-126-965-11 ELECT 22uF 20.00% 50V
(DE975)
C763 1-127-880-11 CERAMIC 0.022uF 10% 50V
(DE975)
C765 1-164-159-11 CERAMIC 0.1uF 50V
(DE975)
< CONNECTOR >
CN816 1-784-041-11 CONNECTOR, BOARD TO BOARD 9P (DE975)
< DIODE >
D781 8-719-911-19 DIODE 1SS133T-72 (DE975)
< IC >
IC761 8-759-710-59 IC NJM4580D-D (DE975)
< JACK >
J761 1-815-432-11 JACK, PIN 2P (2ND ROOM R/L)(DE975)
< TRANSISTOR >
Q781 8-729-119-79 TRANSISTOR 2SC2785TP-FEK (DE975)
< RESISTOR >
R711 1-247-887-00 CARBON 220K 5% 1/4W
(DE975)
R712 1-247-887-00 CARBON 220K 5% 1/4W
(DE975)
R713 1-249-441-11 CARBON 100K 5% 1/4W
(DE975)
R714 1-247-807-31 CARBON 100 5% 1/4W
(DE975)
R715 1-249-425-11 CARBON 4.7K 5% 1/4W F
(DE975)
R761 1-247-887-00 CARBON 220K 5% 1/4W
(DE975)
R762 1-247-887-00 CARBON 220K 5% 1/4W
(DE975)
R763 1-249-441-11 CARBON 100K 5% 1/4W
(DE975)
R764 1-247-807-31 CARBON 100 5% 1/4W
(DE975)
R765 1-249-425-11 CARBON 4.7K 5% 1/4W F
(DE975)
R781 1-249-437-11 CARBON 47K 5% 1/4W
(DE975)
0R783 1-249-393-11 CARBON 10 5% 1/4W F
(DE975)
< RELAY >
RY761 1-515-622-11 RELAY (DE975)
************************************************************
1-680-589-11 AC SELECT BOARD (DE875:E)
***************
< CONNECTOR >
CNP907 1-568-106-11 PIN, CONNECTOR 4P (DE875:E)
* CNP910 1-564-687-11 PIN, CONNECTOR 3P (DE875:E)
< FUSE >
0F904 1-532-464-11 FUSE (TUBE TYPE) (TIME LAG) (2.5A 50V)
(DE875:E)
< FUSE HOLDER >
FH904 1-533-399-11 HOLDER, FUSE
2ND AUDIO
AC SELECT
