STR-DE875/DE975
SECTION 3
DIAGRAMS
3-1. CIRCUIT BOARDS LOCATION
VIDEO board
VIDEO 3 board
(DE975)
DIGITAL board
MAIN board
JOG board
DISPLAY board
HEADPHONE board
POWER SWITCH board
STANDBY board
SPEAKER board
S-VIDEO board
2 ND-AUDIO board
(DE975)
AC SELECT board
