Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DN1050
119
RR15 1-249-393-11 CARBON 10 5% 1/4W
RR17 1-249-393-11 CARBON 10 5% 1/4W
RR18 1-249-393-11 CARBON 10 5% 1/4W
< RELAY >
RY301 1-755-696-11 RELAY
RY302 1-755-307-21 RELAY
RY350 1-755-307-21 RELAY
RY355 1-755-307-21 RELAY
RY360 1-755-307-21 RELAY
RY365 1-755-307-21 RELAY
RY920 1-755-593-11 RELAY
RY921 1-755-307-21 RELAY
< TERMINAL >
TB501 1-854-007-11 TERMINAL BOARD, SPEAKER 6P
(SPEAKERS IMPEDANCE USE 6-16Ω
FRONT A L/R /CENTER)
TB502 1-854-006-11 TERMINAL BOARD, SPEAKER 4P
(SPEAKERS IMPEDANCE USE 6-16Ω
SURROUND L/R)
TB503 1-854-006-11 TERMINAL BOARD, SPEAKER 4P
(SPEAKERS
IMPEDANCE USE 6-16Ω
SURROUND
BACK/ BI-AMP/ FRONT HIGH/ FRONT B/
ZONE 2 L/R)
< THERMISTOR >
0 TH251 1-804-045-11 THERMISTOR
0 TH252 1-804-045-11 THERMISTOR
*************************************************************
A-1989-183-A POWER KEY BOARD, COMPLETE
**************************
< DIODE >
D110 8-719-057-29 DIODE SML78423C-TP15
< TRANSISTOR >
Q110 6-553-266-01 TR 2PD601ART
Q111 6-553-266-01 TR 2PD601ART
< RESISTOR >
R173 1-250-640-11 METAL CHIP 10K 1% 1/10W
R174 1-250-624-11 METAL CHIP 2.2K 1% 1/10W
R175 1-250-592-11 METAL CHIP 100 1% 1/10W
R176 1-250-584-11 METAL CHIP 47 1% 1/10W
R178 1-250-664-11 METAL CHIP 100K 1% 1/10W
R179 1-250-664-11 METAL CHIP 100K 1% 1/10W
R180 1-250-640-11 METAL CHIP 10K 1% 1/10W
R181 1-250-624-11 METAL CHIP 2.2K 1% 1/10W
R182 1-250-632-11 METAL CHIP 4.7K 1% 1/10W
R183 1-250-648-11 METAL CHIP 22K 1% 1/10W
< SWITCH >
S111 1-762-875-21 SWITCH, TACTILE (TUNER PRESET +)
S112 1-762-875-21 SWITCH, TACTILE (TUNER PRESET -)
S113 1-762-875-21 SWITCH, TACTILE
(CONNECTION
PAIRING BLUETOOTH)
S114 1-762-875-21 SWITCH, TACTILE (SPEAKERS)
S115 1-762-875-21 SWITCH, TACTILE (]/1)
*************************************************************
A-1989-180-A STANDBY BOARD, COMPLETE (US, CND)
A-1989-205-A STANDBY BOARD, COMPLETE
(EXCEPT US, CND)
***********************
< CAPACITOR >
C960 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C961 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C962 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C963 1-126-936-11 ELECT 3300uF 20% 16V
C969 1-126-960-11 ELECT 1uF 20% 50V
C971 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C975 1-116-716-11 CERAMIC CHIP 10uF 10% 16V
C976 1-116-716-11 CERAMIC CHIP 10uF 10% 16V
C977 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C978 1-114-802-11 CERAMIC CHIP 0.0033uF 10% 50V
C979 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C980 1-114-802-11 CERAMIC CHIP 0.0033uF 10% 50V
C981 1-116-713-11 CERAMIC CHIP 22uF 20% 10V
C982 1-116-713-11 CERAMIC CHIP 22uF 20% 10V
< CONNECTOR >
* CNP901 1-793-660-11 PIN, CONNECTOR (PC BOARD) 3P
* CNP902 1-580-689-11 PIN, CONNECTOR (PC BOARD) 4P
< DIODE >
D901 8-719-053-18 DIODE 1SR154-400TE-25
D902 8-719-053-18 DIODE 1SR154-400TE-25
D903 8-719-053-18 DIODE 1SR154-400TE-25
D904 8-719-053-18 DIODE 1SR154-400TE-25
D905 6-500-514-01 DIODE BAV70
D991 6-502-961-01 DI DA2J10100L
< FUSE HOLDER >
FH901 1-533-217-41 HOLDER, FUSE
FH902 1-533-217-41 HOLDER, FUSE
< IC >
IC902 (Not supplied) IC RT7237ALGSP
< JUMPER >
JS901 1-211-950-11 SHORT CHIP 0
< COIL >
L910 1-457-995-11 INDUCTOR 10uH
L911 1-460-402-11 COMMON MODE CHOKE COIL
< TRANSISTOR >
Q951 6-553-266-01 TR 2PD601ART
Q952 6-553-266-01 TR 2PD601ART
< RESISTOR >
R960 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R961 1-216-833-11 METAL CHIP 10K 5% 1/10W
R963 1-216-833-11 METAL CHIP 10K 5% 1/10W
R971 1-249-395-11 CARBON 15 5% 1/4W
R972 1-249-394-11 CARBON 12 5% 1/4W
R973 1-216-841-11 METAL CHIP 47K 5% 1/10W
R974 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
MAIN POWER KEY STANDBY
Note: IC902 on the STANDBY board cannot exchange with
single. When this part on the STANDBY board is damaged,
exchange the entire mounted board.
To Next Page
