Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DN1050
120
R978 1-208-711-11 METAL CHIP 15K 0.5% 1/16W
R979 1-218-892-11 METAL CHIP 75K 0.5% 1/10W
R981 1-208-713-11 METAL CHIP 18K 0.5% 1/16W
R1930 1-218-965-11 METAL CHIP 10K 5% 1/16W
< RELAY >
0 RY951 1-755-541-11 RELAY
< TRANSFORMER >
0 T902 1-697-234-21 POWER TRANSFORMER (SUB)
(EXCEPT US, CND)
0 T902 1-697-267-21 POWER TRANSFORMER (SUB) (US, CND)
*************************************************************
TUNER1AMF BOARD (US, CND)
TUNER1AMPR BOARD (EXCEPT US, CND)
******************
< CAPACITOR >
C101 1-100-155-91 CERAMIC CHIP 470PF 5% 100V
C102 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
C103 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
C105 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
C106 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C107 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C108 1-116-729-11 CERAMIC CHIP 2.2uF 20% 10V
C109 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C110 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C111 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
C112 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
< CONNECTOR >
CN101 1-779-277-11 CONNECTOR, FFC (LIF (NON-ZIF)) 9P
* CN103 1-506-680-11 PLUG, CONNECTOR (2.5MM) 3P (ANTENNA AM)
CN104 1-780-920-11 TERMINAL (FMAMF) (US, CND)
(ANTENNA FM 75Ω COAXIAL)
< DIODE >
D101 6-501-579-01 DIODE MC2837
D102 6-501-579-01 DIODE MC2837
D103 6-501-579-01 DIODE MC2837
< FILTER >
FL101 1-236-711-21 FILTER, BAND PASS (US, CND)
< IC >
IC101 6-717-980-01 IC RZ5B801-0001E2 (US, CND)
IC101 6-717-981-01 IC RZ5B801-0002E2 (EXCEPT US, CND)
IC102 6-715-134-01 IC MM3404A33URE
< JUMPER RESISTOR >
JR101 1-216-864-11 SHORT CHIP 0
JR102 1-216-296-11 SHORT CHIP 0
JR105 1-216-296-11 SHORT CHIP 0
JR106 1-216-864-11 SHORT CHIP 0
JR109 1-216-296-11 SHORT CHIP 0
JR112 1-216-296-11 SHORT CHIP 0
< COIL >
L101 1-457-998-11 COIL, AM ANTENNA
L103 1-414-576-41 INDUCTOR 47nH
L104 1-481-330-21 INDUCTOR 220nH
L105 1-481-523-11 INDUCTOR 4.7uH
< RESISTOR >
R101 1-216-809-11 METAL CHIP 100 5% 1/10W
R103 1-216-801-11 METAL CHIP 22 5% 1/10W
R104 1-216-864-11 SHORT CHIP 0
R105 1-216-801-11 METAL CHIP 22 5% 1/10W
R106 1-216-809-11 METAL CHIP 100 5% 1/10W
R107 1-216-809-11 METAL CHIP 100 5% 1/10W
R108 1-216-296-11 SHORT CHIP 0
R109 1-216-864-11 SHORT CHIP 0
R110 1-216-833-11 METAL CHIP 10K 5% 1/10W
R113 1-216-833-11 METAL CHIP 10K 5% 1/10W
< VIBRATOR >
X101 1-767-317-11 VIBRATOR, CRYSTAL (32.768kHz)
*************************************************************
MISCELLANEOUS
**************
57 1-828-412-61 WIRE (FLAT TYPE) (29 CORE)
60 1-500-082-11 CLAMP, SLEEVE FERRITE
61 1-848-318-11 HDMI CABLE
62 1-828-308-61 WIRE (FLAT TYPE) (9 CORE)
63 1-828-167-61 WIRE (FLAT TYPE) (8 CORE)
64 8-989-470-05 RC-S801/A5 (WW)
65 1-490-558-72 BLUETOOTH MODULE
66 1-828-201-61 WIRE (FLAT TYPE) (14 CORE)
101 1-500-082-11 CLAMP, SLEEVE FERRITE (US, CND)
101 1-500-386-11 FILTER, CLAMP (FERRITE CORE)
(EXCEPT US, CND)
102 1-828-240-61 WIRE (FLAT TYPE) (22 CORE)
103 1-828-360-61 WIRE (FLAT TYPE) (19 CORE)
104 A-1989-890-A NETWORK BOARD, COMPLETE (for SERVICE)
151 1-828-311-61 WIRE (FLAT TYPE) (9 CORE)
152 A-1846-561-A TUNER1AMPR ASSY (EXCEPT US, CND)
152 A-1846-564-A TUNER1AMF ASSY (US, CND)
153 1-500-082-11 CLAMP, SLEEVE FERRITE
0 157 1-777-071-83 CORD, POWER (AEP)
0 157 1-833-566-21 POWER-SUPPLY CORD (AUS)
0 157 1-837-308-11 CORD, POWER-SUPPLY (US, CND)
0 157 1-839-999-21 POWER-SUPPLY CORD (UK)
Q550 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q551 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q600 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q601 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q650 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q651 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q700 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q701 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q750 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q751 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q800 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q801 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q850 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q851 6-702-391-01 TRANSISTOR MP1620-OPY-MK
STANDBY TUNER1
Note: If wire (fl at type) is replaced, install it after bending it in the
same form as that before replacement.
* Replacement of Q550, Q551, Q600, Q601, Q650, Q651, Q700,
Q701, Q750, Q751, Q800, Q801, Q850 and Q851 on the MAIN
board used in this unit requires L type screw driver.
To Next Page
