Sony STR-DN1050 - Page 79

STR-DN1050
79
Pin No. Pin Name I/O Description
54 VCC
-
Power supply pin (+3.3V)
55 NO_USE
O
Not used
56 NO_USE
O
Not used
57 INITX
I
Video Micom reset port
58 NW_SPI_DIN
I
NETWORK SPI Data In
59 NW_SPI_DOUT
O
NETWORK SPI Data Out
60 NW_SPI_CLK
O
NETWORK SPI Clock
61 NO_USE
O
Not used
62 NO_USE
O
Not used
63 NO_USE
O
Not used
64 NO_USE
O
Not used
65 NO_USE
O
Not used
66 NW_SPI_REQ
I
NETWORK SPI Request
67 NO_USE
O
Not used
68 NW_SPI_READY
I
NETWORK SPI Ready
69 NO_USE
O
Not used
70 NO_USE
O
Not used
71 NO_USE
O
Not used
72 NO_USE
O
Not used
73 USB_PCONT
O
USB regulator control signal output terminal
74 USB_OVC
I
USB over current signal input terminal
75 NO_USE
O
Not used
76 NO_USE
O
Not used
77 NO_USE
O
Not used
78 1.8V_PCONT
O
HDMI ADV 18V CONT
79 NO_USE
O
Not used
80 NO_USE
O
Not used
81 NFC_SPI_CLK
O
NFC SPI Clock from Host CPU
82 NFC_RFDET
I
NFC RF Detect Signal
83 NO_USE
O
Not used
84 MD1
-
UCOM Mode setting terminal
85 MD0
-
UCOM Mode setting terminal
86 X0
-
Clock signal output (4MHz)
87 X1
-
Clock signal output (4MHz)
88
VSS
-
Ground terminal
89 VCC
-
Power supply pin (+3.3V)
90 UPDATE_LED
O
USB Update: USB Update LED Control / NW Update LED Control
91 NO_USE
O
Not used
92 COM_DET
I
Component detect signal input terminal
93 NON_LPCM
O
HDMI: Non LPCM Stream Info Line Notifi cation
94 NO_USE
O
Not used
95 NO_USE
O
Not used
96 NO_USE
O
Not used
97 MU_RST
I/O
USB Update: USB Update Main Micom Reset
98 MU_MD0
I/O
USB Update: USB Update Main Micom MD0 Select
99 BT_PCONT
O
Bluetooth: Power control for BT device
100 BT_VURX_BTTX
I
Bluetooth: UART Rx on Video uCOM from BT device
101 BT_VUTX_BTRX
O
Bluetooth: UART Tx on Video uCOM to BT device
102 NO_USE
O
Not used
103 VUCTSIN_BTRTS
I
Bluetooth: CTS on Video uCOM
104 VURTSOUT_BTCTS
O
Bluetooth: RTS on Video uCOM
105 BT_RST
O
Bluetooth: RESET for BT device
106 AVCC
-
Analog power supply pin for A/D converter
107 AVRH
-
Standard power supply pin for A/D converter
