Sony STR-DN1050 - Page 81

STR-DN1050
81
Pin No. Pin Name I/O Description
158 NO_USE
O
Not used
159 NO_USE
O
Not used
160 NO_USE
O
Not used
161 MHL1_PCONT
O
MHL1 Power Control
162 MHL_PCONT
O
MHL Power Control
163 MHL_OVC
I
MHL: Overcurrent Detection
164 SPARTA_INT
I
HDMI device interrupt port
165 SPARTA_RST
O
HDMI device reset control port
166 MHL1_OVC
I
MHL1 Over Current detection
167 HDMI_SCK
O
Sparta/HDMI: Communication Line - I2C SCK
168 HDMI_SDA
I/O
HDMI: Communication Line - I2C SDA for HDMI-Rx, HDMI-Tx, EDID device
169 P60
O
UCOM Mode setting terminal
170 ADC_INT
I
Interrupt status signal input from ADC
171 ADC_SDA
I/O
ADC: Communication Line I2C SDA
172 ADC_SCK
O
ADC: Communication Line I2C SCK
173 VCC
-
Power supply pin (+3.3V)
174 ADC_RST
O
ADC reset signal output terminal
175 ADC_PWRDown
O
ADC power down
176 VSS
-
Ground terminal
