STR-DN860/DN1060
107
Pin No. Pin Name I/O Description
158 RG_SFLASH_CS O Rogue SPI Flash Update CS
159 RG_SFLASH_OE
O
Rogue SPI Flash Select Output Enable
160 RG_PCONT
O
Rogue Power Control
161 RG_TX_INT
I
Rogue TX Interrupt
162 RG_TX_RESET
O
Rogue TX Reset
163 RG_TX_SCL
O
Rogue TX I2C SCL
164 RG_TX_SDA I/O Rogue TX I2C SDA
165 MHL_PCONT0
O
MHL Power Control
166 SPARTA_INT
I
HDMI device interrupt port
167 SPARTA_RST
O
HDMI device reset control port
168 MHL0_OVC
I
MHL Over Current Detect
169 RESERVED
O
pull down for serial fl ash write mode
170 5VPWR_A
O
HDMI: 5V Power for HDMI-TX Device/HDMI 5V POWER OUT A
171 5VPWR_B
O
HDMI: 5V Power for HDMI-TX Device/HDMI 5V POWER OUT B
172 SW_+5V
I
HDMI 5V Power Detect
173 VCC
-
Power supply pin (+3.3V)
174 NON_LPCM I/O HDMI: Non LPCM Stream Info Line Notifi cation
175 HDMI_MUTE
O
HDMI: Audio Mute Request
176 VSS
-
Ground Terminal
