Pin No. Pin Name I/O Description
104 DSP_RESET O System reset signal output to the DSP “L” reset
105 DSP_CS O Chip select signal output to DSP
106 DSP_MISO I Serial data input from the serial fl ash and DSP
107 DSP_MOSI O Serial data output to the serial fl ash and DSP
108 DSP_SPICLK O Serial data transfer clock signal output to the serial fl ash and DSP
109 DSP_INT - Interrupt status signal input from DSP (Not Used)
110 DIR_INT I Interrupt status signal input from digital audio interface receiver
111 DIR_CKST I Clock selection signal input from the digital audio interface receiver
112 DIR_SIGNAL I Audio serial data input from the digital audio interface receiver
113 DIR_XMODE O Reset signal output to the digital audio interface receiver
114 AVCC - A/D converter analog power supply pin
115 AVSS - A/D converter analog ground pin
116 AVRL - A/D converter analog reference voltage input pin
117 AVRH - A/D converter analog reference voltage input pin
118 DIR_CSB O Chip enable signal output to the digital audio interface receiver
119 DIR_SO O Serial data output to digital audio interface receiver
120 DIR_SCK O Serial clock output to digital audio interface receiver.
121 DIR_SI I Serial data input from digital audio interface receiver
122 DIR_NPCMF I SPDIF / IIS NPCM signal input from digital audio interface receiver / HDMI receiver
123 NET_HDMI_SEL O Audio selection between NETWORK and HDMI block
124
FLASH_CLK/PWR_
LED
I/O Power on/standby/Update LED control port
125 SO O Serial data output terminal (use for Firmware Flash Program)
126 SI I Serial data input terminal (use for Firmware Flash Program)
127 DIR_ERRF I SPDIF / IIS Error signal input from digital audio interface receiver / HDMI receiver
128 DAC_IIC_SDA O IIC data output to D/A converter.
129 DAC_IIC_SCL O IIC clock output to D/A converter.
130 DAC_ZERO_DATA I Input signal from DAC when 0 Data
131 VCC - Power supply pin (+3.3V)
132 VSS - Ground terminal
133 VCC - Power supply pin (+3.3V)
134 TRSTX (NC) O J-TAG test reset input
135 TCK O J-TAG test clock input
136 TDI O J-TAG test data input
137 TMS O J-TAG test mode state input/output
138 TDO O J-TAG debug data output
139
BT_TX_RATECON_
RST
O BT TX Rate Converter Reset
140 TUNER_RDS_SIGNAL I RDS data signal input (for destination that support RDS only)
141 TUNER_CE O Tuner IC enable port.
142 TUNER_MOSI I/O I2C data output to the tuner
143 TUNER_CLK O I2C clock signal output to the tuner
144 MHL_PCONT1 O MHL Power Control
145 MHL1_OVC I MHL Over Current Detect
146 HDMI_SW_SDA O HDMI Switcher SDA
147 HDMI_SW_SCK O HDMI Switcher SCL
148 RG_RX_INT I Rogue RX Interrupt
149 RG_RX_RESET O Rogue Rx Reset
150 HDMI_SDA I/O Sparta/HDMI I2C SDA
151 HDMI_SCL O Sparta/HDMI I2C SCL
152 RG_SFLASH_SEL O Rogue SPI Flash Update Select
153 RG_FLASH_SPI_SOMI I Rogue SPI Flash Update Data In
154 RG_FLASH_SPI_SIMO O Rogue SPI Flash Update Data Out
155 RG_FLASH_SPI_SCK O Rogue SPI Flash Update Clock
156 VCC - Power supply pin (+3.3V)
157 VSS - Ground Terminal
