STR-DN860/DN1060
105
Pin No. Pin Name I/O Description
51 FL_LAT O Latch signal output for FL DISPLAY DRIVER IC
52 C - Power supply stabilization capacity pin
53 VSS - Ground Terminal
54 VCC - Power supply pin (+3.3V)
55 EVOL_DATA O I2C data output to electrical volume
56 EVOL_CLK O I2C clock signal output to the electrical volume
57
INITX - Micom reset port
58 POWER_KEY I Power switch input terminal
59 FL_DATA O Serial data output for FL DISPLAY DRIVER IC
60 FL_CLK O Clock signal output for FL DISPLAY DRIVER IC
61 STANDBY_LED O Standby LED
62 PURE_DIRECT_LED O Pure Direct LED
63 P_CONT3 O Power Control for MTK
64 ZONE_SELECT I “ZONE SELECT” key input and interrupt
65 V_SEL_SW2 O Composite video output signal switch
66 NFC_RFDET I NFC RF Detect Interrupt and Input
67 NFC_IRQ I NFC wireless data reception signal
68 NFC_SDA I/O NFC I2C data input/output
69 NFC_SCL O NFC I2C clock signal
70 V_COM_MUTE O Component Video Mute
71 V_SEL_MUTE O Composite Video Mute
72 SL_SR_RY O Relay drive signal (for surround) output terminal “H”: relay on
73 POWER_RY O Relay drive signal (for main power) output terminal “H”: relay on
74 FUSE_DET I Fuse open detect signal input
75 AC CUT I AC Off detection signal input
76 PROTECT I Protect detection signal input terminal
77 BT_TX_MUTE O BT TX Rate Converter Mute
78 HP_RY O Relay drive signal (for headphone) output terminal “H”: relay on
79 BRIDGEABLE_RY O Relay drive signal (for power supply) output terminal “H”: relay on
80 SBL_SBR_RY O Relay drive signal (for surround back) output terminal “H”: relay on
81
ZONE2_PREOUT_
SW_RY
O Relay drive signal (for subwoofer and zone2 preout) output terminal “H”: relay on
82 FRONT_SPK_RY O Relay drive signal (for front) output terminal “H”: relay on
83 C_RY O Relay drive signal (for center) output terminal “H”: relay on
84 MD1 - UCOM Mode setting terminal
85 MD0 - UCOM Mode setting terminal
86 X0 (CLOCK IN) - Clock signal output (4MHz)
87 X1 - Clock signal output (4MHz)
88 VSS - Ground terminal
89 VCC - Power supply pin (+3.3V)
90 INPUT_JOG I Function encoder signal input
91 AD_KEY1 I Key signal input (A/D port)
92 AD_KEY2 I Key signal input (A/D port)
93 VOLUME_JOG I MASTER VOLUME encoder signal input
94 LIMITTER I Limiter signal input
95 TEMP_SENSOR2 I Thermal detection signal input from the thermal sensor
96 TEMP_SENSOR1 I Thermal detection signal input from the thermal sensor
97 TEMP_SENSOR3 I Thermal detection signal input from the thermal sensor
98 MTK_TEMP_SENSOR I MTK Temperature Sensor (AD)
99 NC - Not used
100 FS_RATE I I2S Fs Rate detect
101
JITTER_REMOVER_
M0
O NW/DSD Multiplier Select M0
102
JITTER_REMOVER_
M1
O NW/DSD Multiplier Select M1
103 DSP_SFLASH_HOLD O Hold signal output to the serial ash
