Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DN860/DN1060
128
C1999 1-116-865-11 CERAMIC CHIP 10uF 10% 25V
C2000 1-118-036-11 CERAMIC CHIP 0.1uF 10% 50V
C2001 1-118-036-11 CERAMIC CHIP 0.1uF 10% 50V
C2002 1-118-036-11 CERAMIC CHIP 0.1uF 10% 50V
C2003 1-118-036-11 CERAMIC CHIP 0.1uF 10% 50V
< CONNECTOR >
CN1905 1-764-250-21 PIN, CONNECTOR (PC BOARD) 4P
CN1906 1-843-887-11 PIN, CONNECTOR (PC BOARD) 11P
CN1907 1-764-101-11 PIN, CONNECTOR (PC BOARD) 2P
< DIODE >
D906 6-502-398-01 DI SA10QA04
D1924 8-719-061-07 DIODE D5SBA60-F
D1925 6-502-398-01 DI SA10QA04
< FUSE >
0 F940 1-523-088-11 FUSE (5A/250V)
< FERRITE BEAD >
FB1901 1-469-324-21 INDUCTOR (EMI FERRITE) (2012)
FB1902 1-469-324-21 INDUCTOR (EMI FERRITE) (2012)
FB1903 1-469-324-21 INDUCTOR (EMI FERRITE) (2012)
FB1904 1-469-324-21 INDUCTOR (EMI FERRITE) (2012)
FB1905 1-469-324-21 INDUCTOR (EMI FERRITE) (2012)
FB1906 1-469-324-21 INDUCTOR (EMI FERRITE) (2012)
FB1907 1-469-324-21 INDUCTOR (EMI FERRITE) (2012)
< IC >
IC1906 (Not supplied) IC BD9D321EFJ-E2
IC1911 6-721-148-01 IC TPS54394 PWPR
IC1912 (Not supplied) IC TPS542941PWPR
IC1913 (Not supplied) IC TPS542941PWPR
IC1914 (Not supplied) IC BD9D321EFJ-E2
IC1915 (Not supplied) IC BD9D321EFJ-E2
< COIL >
L1914 1-460-358-11 INDUCTOR 2.2uH
L1917 1-460-358-11 INDUCTOR 2.2uH
L1919 1-460-358-11 INDUCTOR 2.2uH
L1920 1-460-358-11 INDUCTOR 2.2uH
L1921 1-460-358-11 INDUCTOR 2.2uH
L1925 1-460-358-11 INDUCTOR 2.2uH
L1929 1-460-358-11 INDUCTOR 2.2uH
* L1930 1-460-599-11 INDUCTOR 4.7uH
L1931 1-460-358-11 INDUCTOR 2.2uH
L1933 1-460-358-11 INDUCTOR 2.2uH
L1934 1-460-358-11 INDUCTOR 2.2uH
* L1935 1-460-599-11 INDUCTOR 4.7uH
* L1936 1-460-599-11 INDUCTOR 4.7uH
* L1937 1-460-599-11 INDUCTOR 4.7uH
* L1938 1-460-599-11 INDUCTOR 4.7uH
< RESISTOR >
R1900 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R1901 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R1902 1-208-923-11 METAL CHIP 33K 0.5% 1/16W
R1903 1-208-923-11 METAL CHIP 33K 0.5% 1/16W
R1904 1-208-703-11 METAL CHIP 6.8K 0.5% 1/16W
R1905 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R1906 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R1907 1-208-923-11 METAL CHIP 33K 0.5% 1/16W
R1908 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R1909 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R1910 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R1911 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R1912 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R1913 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R1914 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R1915 1-216-793-11 METAL CHIP 4.7 5% 1/10W
R1916 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1917 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1918 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1919 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1920 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1921 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1922 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R1923 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R1924 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R1925 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R1926 1-216-793-11 METAL CHIP 4.7 5% 1/10W
R1927 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1928 1-208-895-81 METAL CHIP 2.2K 0.5% 1/16W
R1932 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1933 1-208-715-11 METAL CHIP 22K 0.5% 1/16W
R1934 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R1935 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R1936 1-216-793-11 METAL CHIP 4.7 5% 1/10W
R1937 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1938 1-208-895-81 METAL CHIP 2.2K 0.5% 1/16W
R1973 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
R1974 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
R1975 1-208-895-81 METAL CHIP 2.2K 0.5% 1/16W
R1976 1-216-295-91 SHORT CHIP 0
R1977 1-216-295-91 SHORT CHIP 0
R1978 1-216-295-91 SHORT CHIP 0
R1979 1-216-295-91 SHORT CHIP 0
*************************************************************
A-2060-599-A DISPLAY BOARD, COMPLETE (DN1060)
A-2060-609-A DISPLAY BOARD, COMPLETE (DN860)
***********************
< CAPACITOR >
* C1114 1-116-723-11 CERAMIC CHIP 4.7uF 10% 10V
C1115 1-118-291-11 CERAMIC CHIP 100PF 5% 50V
C1116 1-115-871-11 ELECT 1uF 20% 50V
C1117 1-126-795-11 ELECT 10uF 20% 50V
C1118 1-126-514-11 ELECT 22uF 20% 16V
C1119 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C1120 1-126-514-11 ELECT 22uF 20% 16V
C1121 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C1122 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C1123 1-115-871-11 ELECT 1uF 20% 50V
C1124 1-126-382-11 ELECT 100uF 20% 16V
C1125 1-162-966-91 CERAMIC CHIP 0.0022uF 10% 50V
C1126 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C1127 1-119-943-91 ELECT 47uF 20% 50V
C1128 1-116-405-11 CERAMIC CHIP 0.01uF 10% 100V
C1129 1-162-968-91 CERAMIC CHIP 0.0047uF 10% 50V
DCDC DISPLAY
Note: IC1906, IC1912, IC1913, IC1914 and IC1915 on the DCDC
board cannot exchange with single. When these parts
on the DCDC board are damaged, exchange the entire
mounted board.
To Next Page
