Sony STR-DN1060 - Page 129

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DN860/DN1060
129
JR123 1-216-296-11 SHORT CHIP 0
JR124 1-216-296-11 SHORT CHIP 0
JR125 1-216-296-11 SHORT CHIP 0
JR126 1-216-296-11 SHORT CHIP 0
JR127 1-216-296-11 SHORT CHIP 0
JR128 1-216-296-11 SHORT CHIP 0
JR129 1-216-296-11 SHORT CHIP 0
JR130 1-216-296-11 SHORT CHIP 0
JR131 1-216-296-11 SHORT CHIP 0
< COIL >
L1101 1-481-781-21 INDUCTOR 47uH
< FLOURESCENT INDICATOR TUBE >
ND1100 1-811-724-11 VACUUM FLOURESCENT DISPLAY
< TRANSISTOR >
Q1101 6-552-713-01 TR QS5W2TR
Q1102 6-553-266-01 TR 2PD601ART
< RESISTOR >
R1113 1-216-797-11 METAL CHIP 10 5% 1/10W
R1114 1-216-839-11 METAL CHIP 33K 5% 1/10W
R1115 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1116 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1117 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1118 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1119 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1121 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1122 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1123 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1124 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1125 1-218-866-11 METAL CHIP 6.2K 0.5% 1/10W
R1126 1-216-842-11 METAL CHIP 56K 5% 1/10W
R1127 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R1128 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1129 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1130 1-250-616-11 METAL CHIP 1K 1% 1/10W
R1131 1-250-624-11 METAL CHIP 2.2K 1% 1/10W
R1132 1-250-632-11 METAL CHIP 4.7K 1% 1/10W
R1133 1-250-624-11 METAL CHIP 2.2K 1% 1/10W
R1134 1-250-624-11 METAL CHIP 2.2K 1% 1/10W
R1135 1-250-616-11 METAL CHIP 1K 1% 1/10W
R1136 1-250-592-11 METAL CHIP 100 1% 1/10W
R1137 1-250-592-11 METAL CHIP 100 1% 1/10W
R1138 1-250-652-11 METAL CHIP 33K 1% 1/10W
R1139 1-249-429-11 CARBON 10K 5% 1/4W
R1140 1-250-612-11 METAL CHIP 680 1% 1/10W
R1141 1-257-172-91 METAL CHIP 100 5% 1/3W
R1142 1-250-640-11 METAL CHIP 10K 1% 1/10W
R1143 1-250-600-11 METAL CHIP 220 1% 1/10W
R1144 1-250-664-11 METAL CHIP 100K 1% 1/10W
R1145 1-250-640-11 METAL CHIP 10K 1% 1/10W
R1146 1-250-648-11 METAL CHIP 22K 1% 1/10W
R1147 1-250-640-11 METAL CHIP 10K 1% 1/10W
R1148 1-250-648-11 METAL CHIP 22K 1% 1/10W
R1151 1-249-429-11 CARBON 10K 5% 1/4W
R1154 1-216-809-11 METAL CHIP 100 5% 1/10W
R1158 1-216-809-11 METAL CHIP 100 5% 1/10W
C1130 1-118-369-11 CERAMIC CHIP 0.022uF 10% 50V
C1131 1-124-635-00 ELECT 220uF 20% 6.3V
C1132 1-114-811-11 CERAMIC CHIP 0.0033uF 10% 50V
C1133 1-114-811-11 CERAMIC CHIP 0.0033uF 10% 50V
C1134 1-114-811-11 CERAMIC CHIP 0.0033uF 10% 50V
C1135 1-114-811-11 CERAMIC CHIP 0.0033uF 10% 50V
C1136 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C1137 1-126-795-11 ELECT 10uF 20% 50V
C1138 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C1139 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C1142 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C1143 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
< CONNECTOR >
CN1102 1-779-295-41 CONNECTOR, FFC (LIF (NON-ZIF)) 27P
CN1103 1-779-275-41 CONNECTOR, FFC (LIF (NON-ZIF)) 7P
< DIODE >
D1105 6-502-968-01 DI DZ2J062M0L
D1106 6-500-400-01 DIODE BAV99-215
D1107 6-500-400-01 DIODE BAV99-215
D1108 6-500-424-01 DIODE SLI-325DCT31W
< ROTARY ENCODER >
EN1100 1-418-817-21 ENCODER, ROTARY (INPUT SELECTOR)
EN1101 1-418-725-41 ENCODER, ROTARY (12 TYPE)
(MASTER VOLUME)
< FERRITE BEAD >
FB1100 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB1101 1-469-152-11 FERRITE, EMI (SMD) (2012)
< IC >
IC1100 6-600-768-01 IC PNA4823M03S0 (
)
IC1101 8-759-701-01 IC NJM2904M
< JUMPER RESISTOR >
JR100 1-216-296-11 SHORT CHIP 0
JR101 1-216-296-11 SHORT CHIP 0
JR102 1-216-296-11 SHORT CHIP 0
JR103 1-216-296-11 SHORT CHIP 0
JR104 1-216-296-11 SHORT CHIP 0
JR105 1-216-296-11 SHORT CHIP 0
JR106 1-216-864-11 SHORT CHIP 0
JR107 1-216-296-11 SHORT CHIP 0
JR108 1-216-296-11 SHORT CHIP 0
JR109 1-216-864-11 SHORT CHIP 0
JR110 1-216-296-11 SHORT CHIP 0
JR111 1-216-296-11 SHORT CHIP 0
JR112 1-216-864-11 SHORT CHIP 0
JR113 1-216-296-11 SHORT CHIP 0
JR114 1-216-296-11 SHORT CHIP 0
JR115 1-216-296-11 SHORT CHIP 0
JR116 1-216-296-11 SHORT CHIP 0
JR117 1-216-296-11 SHORT CHIP 0
JR118 1-216-296-11 SHORT CHIP 0
JR119 1-216-296-11 SHORT CHIP 0
JR120 1-216-296-11 SHORT CHIP 0
JR121 1-216-296-11 SHORT CHIP 0
JR122 1-216-296-11 SHORT CHIP 0
DISPLAY
