Sony STR-DN1060 - Page 130

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DN860/DN1060
130
R1159 1-216-809-11 METAL CHIP 100 5% 1/10W
R1160 1-216-809-11 METAL CHIP 100 5% 1/10W
R1161 1-216-809-11 METAL CHIP 100 5% 1/10W
R1162 1-216-864-11 SHORT CHIP 0 (DN860)
R1164 1-216-864-11 SHORT CHIP 0 (DN1060)
R1165 1-216-864-11 SHORT CHIP 0 (DN860)
R1166 1-216-864-11 SHORT CHIP 0
R1172 1-216-864-11 SHORT CHIP 0
< SWITCH >
S1101 1-762-875-21 SWITCH, TACTILE (PURE DIRECT)
S1
102 1-762-875-21 SWITCH, TACTILE (DIMMER)
S1103 1-762-875-21 SWITCH, TACTILE (DISPLAY MODE) (DN860) /
(ZONE POWER) (DN1060)
S1104 1-762-875-21 SWITCH, TACTILE (SLEEP) (DN860) /
(ZONE SELECT) (DN1060)
S1105 1-762-875-21 SWITCH, TACTILE (SOUND OPTIMIZER)
(DN860) / (DISPLAY MODE) (DN1060)
S1108 1-762-875-21 SWITCH, TACTILE (A.F.D./2CH)
S1109 1-762-875-21 SWITCH, TACTILE (MOVIE)
S1110 1-762-875-21 SWITCH, TACTILE (MUSIC)
< TRANSFORMER >
T1100 1-443-645-11 TRANSFORMER, DC CONVERTER
*************************************************************
A-2060-601-A FRONTJACK BOARD, COMPLETE
**************************
< CAPACITOR >
C1150 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C1151 1-126-176-11 ELECT 220uF 20% 10V
* C1152 1-118-360-11 CERAMIC CHIP 0.1uF 10% 25V
C1154 1-116-743-11 CERAMIC CHIP 0.22uF 10% 16V
< CONNECTOR >
CN1104 1-564-721-11 PIN, CONNECTOR (SMALL TYPE) 5P
CN1106 1-819-866-11 USB CONNECTOR (A) ( DC5V 1A MAX)
< DIODE >
D1126 6-502-968-01 DI DZ2J062M0L
D1129 6-500-400-01 DIODE BAV99-215
D1130 6-500-400-01 DIODE BAV99-215
< JACK >
J1100 1-822-453-11 SMALL TYPE JACK (3.5MM) (AUTO CAL MIC)
< JUMPER RESISTOR >
JR200 1-216-296-11 SHORT CHIP 0
JR201 1-216-296-11 SHORT CHIP 0
< RESISTOR >
R1190 1-216-864-11 SHORT CHIP 0
R1191 1-216-864-11 SHORT CHIP 0
R1192 1-216-864-11 SHORT CHIP 0
R1193 1-216-809-11 METAL CHIP 100 5% 1/10W
*************************************************************
A-2060-589-A FRONT HDMI BOARD, COMPLETE (DN1060)
***************************
< CAPACITOR >
* C4020 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C4021 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C4022 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C4044 1-118-036-11 CERAMIC CHIP 0.1uF 10% 50V
C4045 1-118-036-11 CERAMIC CHIP 0.1uF 10% 50V
< CONNECTOR >
CN4000 1-843-670-11 HDMI CONNECTOR
((VIDEO 2 IN) HDMI MHL DC5V 1A MAX)
CN4040 1-580-756-21 PIN, CONNECTOR (SMD) 7P
* CN4060 1-842-680-11 HDMI CONNECTOR
< FERRITE BEAD >
FB4000 1-482-231-11 INDUCTOR, FERRITE BEAD
FB4003 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB4004 1-460-516-21 INDUCTOR, FERRITE BEADS (1005)
< IC >
IC4020 6-721-119-01 IC TCA9517DGKR
< RESISTOR >
R4001 1-218-990-81 SHORT CHIP 0
R4020 1-218-973-11 METAL CHIP 47K 5% 1/16W
R4021 1-218-990-81 SHORT CHIP 0
R4022 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R4023 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R4040 1-218-990-81 SHORT CHIP 0
R4042 1-218-990-81 SHORT CHIP 0
R4044 1-218-990-81 SHORT CHIP 0
R4045 1-218-990-81 SHORT CHIP 0
*************************************************************
HP BOARD
*********
< CAPACITOR >
C1160 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
C1161 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
C1162 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
< JACK >
J1101 1-822-967-12 JACK (PHONES)
*************************************************************
A-2060-593-A MAIN BOARD, COMPLETE (DN1060: US, CND)
A-2060-607-A MAIN BOARD, COMPLETE (DN860: US, CND)
A-2064-333-A MAIN BOARD, COMPLETE
(DN1060: AEP, UK, AUS)
A-2064-356-A MAIN BOARD, COMPLETE
(DN860: AEP, UK, AUS, TW)
*****************
7-685-646-71 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C910 1-118-119-91 CERAMIC CHIP 0.47uF 10% 100V
C911 1-118-119-91 CERAMIC CHIP 0.47uF 10% 100V
C912 1-126-943-11 ELECT 2200uF 20% 25V
(DN860)
DISPLAY FRONT HDMI HP MAINFRONTJACK
