Sony STR-DN1060 - Main Board Components

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DN860/DN1060
131
C913 1-126-942-61 ELECT 1000uF 20% 25V
(DN860)
C930 1-165-946-11 ELECT (BLOCK) 6800uF 20% 71V
(DN860)
C931 1-165-946-11 ELECT (BLOCK) 6800uF 20% 71V
(DN860)
C932 1-112-111-11 ELECT 100uF 20% 100V
(DN1060)
C933 1-112-111-11 ELECT 100uF 20% 100V
(DN1060)
C934 1-165-554-91 CERAMIC CHIP 0.1uF 10% 100V
C935 1-165-554-91 CERAMIC CHIP 0.1uF 10% 100V
C936 1-118-476-11 ELECT (BLOCK) 8200uF 20% 71V
(DN1060)
C937 1-118-476-11 ELECT (BLOCK) 8200uF 20% 71V
(DN1060)
C983 1-128-560-11 ELECT 22uF 20% 100V
(DN860)
C984 1-128-560-11 ELECT 22uF 20% 100V
(DN860)
C985 1-112-092-11 ELECT 1000uF 20% 25V
(DN1060)
C986 1-112-093-11 ELECT 2200uF 20% 25V
(DN1060)
* C1202 1-116-738-11 CERAMIC CHIP 1uF 10% 6.3V
* C1204 1-116-738-11 CERAMIC CHIP 1uF 10% 6.3V
* C1206 1-116-719-11 CERAMIC CHIP 10uF 10% 6.3V
C1208 1-162-909-11 CERAMIC CHIP 4PF 0.25PF 50V
C1209 1-116-173-91 CERAMIC CHIP 0.0022uF 5% 50V
C1210 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
* C1211 1-116-735-11 CERAMIC CHIP 1uF 10% 16V
C1212 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C1213 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C1214 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C1215 1-118-435-11 CERAMIC CHIP 47PF 5% 50V
C1216 1-118-435-11 CERAMIC CHIP 47PF 5% 50V
C1217 1-126-947-11 ELECT 47uF 20% 35V
C1218 1-118-435-11 CERAMIC CHIP 47PF 5% 50V
C1219 1-162-909-11 CERAMIC CHIP 4PF 0.25PF 50V
C1220 1-118-397-11 CERAMIC CHIP 0.0033uF 10% 50V
C1221 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C1222 1-118-388-11 CERAMIC CHIP 0.047uF 10% 25V
C1223 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
* C1224 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
(DN1060)
* C1225 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
(DN1060)
* C1226 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
(DN1060)
C1227 1-118-373-11 CERAMIC CHIP 0.01uF 10% 50V
(DN1060)
C1228 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
(DN1060)
C1229 1-118-373-11 CERAMIC CHIP 0.01uF 10% 50V
(DN1060)
C1230 1-164-870-11 CERAMIC CHIP 68PF 5% 50V
C1232 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
(DN1060)
C1233 1-118-373-11 CERAMIC CHIP 0.01uF 10% 50V
(DN1060)
C1234 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
(DN1060)
C1235 1-126-947-11 ELECT 47uF 20% 35V
(DN1060)
C1236 1-118-350-11 CERAMIC CHIP 22PF 5% 50V
(DN1060)
C1237 1-118-350-11 CERAMIC CHIP 22PF 5% 50V
(DN1060)
C1238 1-118-350-11 CERAMIC CHIP 22PF 5% 50V
(DN1060)
C1240 1-126-947-11 ELECT 47uF 20% 35V
* C1243 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C1244 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C1250 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C1270 1-126-925-91 ELECT 470uF 20% 10V
(DN1060)
C1271 1-118-373-11 CERAMIC CHIP 0.01uF 10% 50V
(DN1060)
C1272 1-126-925-91 ELECT 470uF 20% 10V
(DN1060)
C1273 1-118-373-11 CERAMIC CHIP 0.01uF 10% 50V
(DN1060)
C1274 1-126-925-91 ELECT 470uF 20% 10V
(DN1060)
C1275 1-118-373-11 CERAMIC CHIP 0.01uF 10% 50V
(DN1060)
C1280 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C1283 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
* C1290 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C1291 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C1292 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C1301 1-126-964-11 ELECT 10uF 20% 50V
C1310 1-112-080-11 ELECT 470uF 20% 10V
(DN1060)
C1310 1-126-925-91 ELECT 470uF 20% 10V
(DN860)
C1311 1-112-080-11 ELECT 470uF 20% 10V
(DN1060)
C1311 1-126-925-91 ELECT 470uF 20% 10V
(DN860)
C1320 1-112-079-11 ELECT 220uF 20% 10V
(DN1060)
C1320 1-126-923-91 ELECT 220uF 20% 10V
(DN860)
C1322 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C1323
1-112-079-11 ELECT 220uF 20% 10V
(DN1060)
C1323 1-126-923-91 ELECT 220uF 20% 10V
(DN860)
C1325 1-126-964-11 ELECT 10uF 20% 50V
C1350 1-114-507-11 CERAMIC CHIP 1uF 10% 50V
C1351 1-112-084-11 ELECT 470uF 20% 16V
(DN1060)
C1351 1-126-935-11 ELECT 470uF 20% 16V
(DN860)
C1352 1-114-507-11 CERAMIC CHIP 1uF 10% 50V
C1353 1-112-084-11 ELECT 470uF 20% 16V
(DN1060)
C1353 1-126-935-11 ELECT 470uF 20% 16V
(DN860)
C1354 1-100-155-91 CERAMIC CHIP 470PF 5% 100V
C1355 1-100-155-91 CERAMIC CHIP 470PF 5% 100V
C1357 1-114-507-11 CERAMIC CHIP 1uF 10% 50V
C1358 1-100-155-91 CERAMIC CHIP 470PF 5% 100V
C1359 1-112-084-11 ELECT 470uF 20% 16V
(DN1060)
MAIN
